BAW 56S H6327

Description
diodes - general purpose, power, switching AF digital transistor
Categorysemiconductor    Discrete semiconductor
File Size149KB,12 Pages
ManufacturerInfineon
Websitehttp://www.infineon.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

BAW 56S H6327 Overview

diodes - general purpose, power, switching AF digital transistor

BAW 56S H6327 Parametric

Parameter NameAttribute value
ManufactureInfine
Product CategoryDiodes - General Purpose, Power, Switching
RoHSYes
PackagingReel
Factory Pack Quantity3000
BAW56...
Silicon Switching Diode
For high-speed switching applications
Common anode configuration
BAW56S / U: For orientation in reel see
package information below
Pb-free (RoHS compliant) package
1)
Qualified according AEC Q101
BAW56
BAW56W
!
BAW56S
BAW56U
$
#
, "
"
, !
,
,
,
,


!
Type
BAW56
BAW56S
BAW56U
BAW56W
1
Pb-containing
Package
SOT23
SOT363
SC74
SOT323
Configuration
common anode
double common anode
double common anode
common anode
Marking
A1s
A1s
A1s
A1s
package may be available upon special request
1
2007-09-19

BAW 56S H6327 Related Products

BAW 56S H6327 BAW 56U E6433 BAW 56U E6327
Description diodes - general purpose, power, switching AF digital transistor diodes - general purpose, power, switching silicon switch diode for HI-speed diodes - general purpose, power, switching silicon switch diode
Manufacture Infine Infine Infine
Product Category Diodes - General Purpose, Power, Switching Diodes - General Purpose, Power, Switching Diodes - General Purpose, Power, Switching
RoHS Yes Yes Yes
Packaging Reel Reel Reel
Factory Pack Quantity 3000 10000 3000
Produc - Switching Diodes Switching Diodes
Peak Reverse Voltage - 85 V 85 V
Forward Continuous Curre - 0.2 A 0.2 A
Max Surge Curre - 4.5 A 4.5 A
Configurati - Double Dual Common Anode Double Dual Common Anode
Recovery Time - 4 ns 4 ns
Forward Voltage D - 1.25 V 1.25 V
Maximum Reverse Leakage Curre - 0.15 uA 0.15 uA
Operating Temperature Range - + 150 C + 150 C
Mounting Style - SMD/SMT SMD/SMT
Package / Case - SC-74-6 SC-74-6
Maximum Operating Temperature - + 150 C + 150 C
Minimum Operating Temperature - - 65 C - 65 C
