Philips Semiconductors
Product specification
Rectifier diodes
ultrafast
FEATURES
• Low forward volt drop
• Fast switching
• Soft recovery characteristic
• High thermal cycling performance
• Low thermal resistance
BYV29 series
SYMBOL
QUICK REFERENCE DATA
V
R
= 300 V/ 400 V/ 500 V
k
1
a
2
V
F
≤
1.03 V
I
F(AV)
= 9 A
t
rr
≤
60 ns
GENERAL DESCRIPTION
Ultra-fast, epitaxial rectifier diodes
intended for use as output rectifiers
in high frequency switched mode
power supplies.
The BYV29 series is supplied in the
conventional
leaded
SOD59
(TO220AC) package.
PINNING
PIN
1
2
tab
DESCRIPTION
cathode
anode
cathode
SOD59 (TO220AC)
tab
1
2
LIMITING VALUES
Limiting values in accordance with the Absolute Maximum System (IEC 134).
SYMBOL
V
RRM
V
RWM
V
R
I
F(AV)
I
FRM
I
FSM
PARAMETER
Peak repetitive reverse voltage
Crest working reverse voltage
Continuous reverse voltage
square wave;
δ
= 0.5;
T
mb
≤
123 ˚C
Repetitive peak forward current t = 25
µs; δ
= 0.5;
T
mb
≤
123 ˚C
Non-repetitive peak forward
t = 10 ms
current.
t = 8.3 ms
sinusoidal; with reapplied
V
RRM(max)
Storage temperature
Operating junction temperature
Average forward current
1
CONDITIONS
BYV29
-
-
-
-
-
-
-
-40
-
MIN.
-300
300
300
300
MAX.
-400
400
400
400
9
18
100
110
150
150
-500
500
500
500
UNIT
V
V
V
A
A
A
A
˚C
˚C
T
stg
T
j
THERMAL RESISTANCES
SYMBOL
R
th j-mb
R
th j-a
PARAMETER
Thermal resistance junction to
mounting base
Thermal resistance junction to
ambient
CONDITIONS
MIN.
-
in free air.
-
TYP.
-
60
MAX.
2.5
-
UNIT
K/W
K/W
1
Neglecting switching and reverse current losses.
September 1998
1
Rev 1.300
Philips Semiconductors
Product specification
Rectifier diodes
ultrafast
ELECTRICAL CHARACTERISTICS
T
j
= 25 ˚C unless otherwise stated
SYMBOL
V
F
I
R
Q
s
t
rr
I
rrm
V
fr
PARAMETER
Forward voltage
Reverse current
Reverse recovery charge
Reverse recovery time
Peak reverse recovery current
Forward recovery voltage
CONDITIONS
I
F
= 8 A; T
j
= 150˚C
I
F
= 8 A
I
F
= 20 A
V
R
= V
RRM
V
R
= V
RRM
; T
j
= 100 ˚C
I
F
= 2 A to V
R
≥
30 V;
dI
F
/dt = 20 A/µs
I
F
= 1 A to V
R
≥
30 V;
dI
F
/dt = 100 A/µs
I
F
= 10 A to V
R
≥
30 V;
dI
F
/dt = 50 A/µs; T
j
= 100˚C
I
F
= 10 A; dI
F
/dt = 10 A/µs
MIN.
-
-
-
-
-
-
-
-
-
BYV29 series
TYP.
0.90
1.05
1.20
2.0
0.1
40
50
4.0
2.5
MAX.
1.03
1.25
1.40
50
0.35
60
60
5.5
-
UNIT
V
V
V
µA
mA
nC
ns
A
V
I
dI
F
dt
F
15
PF / W
Vo = 0.8900 V
Rs = 0.0190 Ohms
BYV29
Tmb(max) / C
D = 1.0
112.5
t
0.5
rr
time
10
0.2
0.1
5
t
p
T
t
125
Q
I
R
I
s
10%
100%
I
t
p
137.5
D=
rrm
T
0
0
5
IF(AV) / A
10
150
15
Fig.1. Definition of t
rr
, Q
s
and I
rrm
Fig.3. Maximum forward dissipation P
F
= f(I
F(AV)
);
square wave where I
F(AV)
=I
F(RMS)
x
√
D.
BYV29
Tmb(max) / C
120
a = 1.57
1.9
2.2
8
2.8
4
6
4
135
140
145
150
10
130
125
I
F
12
10
PF / W
Vo = 0.89V
Rs = 0.019 Ohms
time
VF
V
VF
time
fr
2
0
0
2
4
IF(AV) / A
6
8
Fig.2. Definition of V
fr
Fig.4. Maximum forward dissipation P
F
= f(I
F(AV)
);
sinusoidal current waveform where a = form
factor = I
F(RMS)
/ I
F(AV)
.
September 1998
2
Rev 1.300
Philips Semiconductors
Product specification
Rectifier diodes
ultrafast
BYV29 series
1000
trr / ns
30
IF / A
Tj=150 C
BYW29
IF=10 A
100
1A
20
Tj=25 C
typ
max
10
Tj = 25 C
Tj = 100C
1
1
10
dIF/dt (A/us)
100
10
0
0
0.5
1
VF / V
1.5
2
Fig.5. Maximum t
rr
at T
j
= 25˚C and 100˚C
Fig.7. Typical and maximum forward characteristic
I
F
= f(V
F
); parameter T
j
Qs / nC
10
Irrm / A
IF=10A
1000
1
IF=1A
100
IF = 10 A
2A
0.1
10
0.01
1
Tj = 25 C
Tj = 100C
10
-dIF/dt (A/us)
100
1
1.0
10
-dIF/dt (A/us)
100
Fig.6. Maximum I
rrm
at T
j
= 25˚C and 100˚C.
Fig.8. Maximum Q
s
at T
j
= 25˚C
10
Transient thermal impedance, Zth j-mb (K/W)
1
0.1
0.01
P
D
t
p
D=
t
p
T
t
0.001
1us
T
10us
100us 1ms
10ms 100ms
1s
pulse width, tp (s)
BYV29
10s
Fig.9. Transient thermal impedance Z
th j-mb
= f(t
p
)
September 1998
3
Rev 1.300
Philips Semiconductors
Product specification
Rectifier diodes
ultrafast
MECHANICAL DATA
Dimensions in mm
Net Mass: 2 g
BYV29 series
4,5
max
10,3
max
1,3
3,7
2,8
5,9
min
3,0 max
not tinned
3,0
15,8
max
13,5
min
1,3
max
1
(2x)
2
0,9 max (2x)
0,6
2,4
5,08
Fig.10. SOD59 (TO220AC). pin 1 connected to mounting base.
