MBR2035CT - MBR20200CT
20.0 AMPS. Schottky Barrier Rectifiers
TO-220AB
Features
Plastic material used carriers Underwriters
Laboratory Classification 94V-0
Metal silicon junction, majority carrier conduction
Low power loss, high efficiency
High current capability, low forward voltage drop
High surge capability
For use in low voltage, high frequency inverters,
free wheeling, and polarity protection applications
Guard-ring for overvoltage protection
High temperature soldering guaranteed:
260℃/10 seconds, 0.25"(6.35mm) from case
Green compound with suffix "G" on packing
code & prefix "G" on datecode
Mechanical Data
Cases: JEDEC TO-220AB molded plastic
Terminals: Pure tin plated, lead free, solderable
per MIL-STD-750, Method 2026
Polarity: As marked
Mounting position:Any
Mounting torque: 5 in. - lbs, max
Weight: 1.88 grams
Ordering Information(example)
Part No.
MBR2035CT
Package
Packing
Packing code
C0
Packing code
(Green)
C0G
TO-220AB 50 / TUBE
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Parameter
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Repetitive Forward Current
(Rated VR, Square Wave, 20KHz)
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Peak Repetitive Reverse Surge Current (Note 1)
Maximum Instantaneous Forward Voltage at: (Note 2)
IF=10A, T
A
=25℃
IF=10A, T
A
=125℃
IF=20A, T
A
=25℃
IF=20A, T
A
=125℃
Maximum Instantaneous Reverse Current @ T
A
=25
℃
at Rated DC Blocking Voltage
@ T
A
=125
℃
Voltage Rate of Change (Rated V
R
)
Typical Junction Capacitance
Typical Thermal Resistance Per Leg
Operating Temperature Range
Storage Temperature Range
Note 1: 2.0uS Pulse Width, f=1.0KHz
Note 2: Pulse Test : 300uS Pulse Width, 1% Duty Cycle
MBR
Symbol 2035
CT
V
RRM
35
V
RMS
V
DC
I
F(AV)
I
FRM
I
FSM
I
RRM
24
35
MBR
2045
CT
45
31
45
MBR
2050
CT
50
35
50
MBR
2060
CT
60
42
60
20
20
MBR
2090
CT
90
63
90
MBR MBR MBR
20100 20150 20200
CT
CT
CT
100
150
200
70
100
105
150
140
200
Units
V
V
V
A
A
A
150
1.0
-
0.80
0.70
0.95
0.85
0.1
15
400
1.0
- 65 to + 150
- 65 to + 175
10
10000
320
2.0
O
0.5
0.85
0.75
0.95
0.85
5
0.99
0.87
1.23
1.10
A
V
F
0.57
0.84
0.72
V
I
R
dV/dt
Cj
R
θJC
T
J
T
STG
mA
0.15
mA
V/uS
pF
C/W
O
O
C
C
Version:J12
RATINGS AND CHARACTERISTIC CURVES (MBR2035CT THRU MBR20200CT)
FIG.1- FORWARD CURRENT DERATING CURVE
24
20
16
12
8
4
0
0
50
100
150
CASE TEMPERATURE (
o
C)
RESISTIVE OR
INDUCTIVELOAD
WITH HEATSINK
PEAK FORWARD SURGE CURRENT (A)
150
125
100
75
50
25
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
8.3ms Single Half Sine Wave
JEDEC Method
FIG. 2- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT PER LEG
AVERAGE FORWARD
A
CURRENT (A)
FIG. 3- TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS PER LEG
100
FIG. 4- TYPICAL REVERSE CHARACTERISTICS
PER LEG
100
INSTANTANEOUS FORWARD CURRENT (A)
10
TA=125℃
TA=25℃
INSTANTANEOUS REVERSE CURRENT (mA)
10
TA=125℃
1
1
MBR2035CT-2045CT
MBR2050CT-2060CT
MBR20100CT
MBR20150CT-200CT
Pulse Width=300us
1% Duty Cycle
0.01
0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
FORWARD VOLTAGE (V)
FIG. 5- TYPICAL JUNCTION CAPACITANCE
PER LEG
1
1.1 1.2
0.1
TA=75℃
0.1
0.01
TA=25℃
MBR2035CT-2045CT
MBR2050CT-20100CT
MBR20150CT-20200CT
0
20
40
60
80
100
120
140
0.001
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
FIG. 6- TYPICAL TRANSIENT THERMAL IMPEDANCE
PER LEG
10000
JUNCTION CAPACITANCE (pF)
A
100
TA=25℃
f=1.0MHz
Vsig=50mVp-p
TRANSIENT THERMAL
IMPEDANCE (℃/W)
MBR2035CT-2045CT
MBR2050CT-20200CT
10
1000
1
100
0.1
0.1
10
100
0.01
0.1
1
10
100
T-PULSE DURATION. (sec)
1
REVERSE VOLTAGE (V)
Version:J12
