VFD Module GU-800 series
GU256X32-800B
256x32 dot VFD module.
Non built-in font type.
Specifications
Parameter
Power Supply Voltage
Symbol
VCC
Min.
4.75
Typ.
5.00
Max.
5.25
Unit
VDC
Condition
-
Parallel(CMOS), Synchronous Serial (CMOS)
Parameter
Logic Input Voltage
H
L
Logic Output Voltage
H
L
Reset Input Voltage
H
L
Power Supply Current
Power Consumption
Symbol
Min.
4.0
-
4.7
-
4.0
-
-
-
-
Typ.
-
-
-
-
-
-
750
600
3.75
Max.
-
1.0
-
0.3
-
0.6
900
750
4.5
Unit
VDC
Condition
VIH
VIL
VOH
VOL
VRH
VRL
ICC
VDC
VDC
VDC
mA
W
All dots ON
All dots OFF
All dots ON
Description
Pin No. Parallel Parallel
#1
#2
1 D7
D7
3 D6
D6
5 D5
D5
7 D4
D4
9 D3
D3
11 D2
D2
13 D1
D1
15 D0
D0
17 WR
R/W
19 C/D
C/D
21 RD
ENCK
23 CSS
CSS
25 FRP
FRP
Serial
NC
NC
NC
NC
NC
NC
TXD
RXD
NC
C/D
SCK
CSS
FRP
Description
Pin No. All
2
4
6
8
10
12
14
16
18
20
22
24
26
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
RESET
Parameter
Luminance
Color of illumination
250 cd/m
2
Min.
Green (Blue-Green)
Pin No. Signal
1 VCC
2 Test
3 GND
Parameter
Operating Temperature
Storage Temperature
Operating Humidity
Vibration (Non operation)
Shock (non-operating)
-40 ~ +85 degrees celsius
-40 ~ +85 degrees celsius
20 ~ 80% R.H. (non-condensing)
10-55-10Hz, all amplitude 1mm, 30 minutes, X-Y-Z
539m/s
2
(55G) 10ms
None
Parameter
Number of Dots
Display Area
Dot Size (X x Y)
Dot Pitch (X x Y)
166.25 mm x 20.65 mm
0.5 mm x 0.5 mm
0.65 mm x 0.65 mm
Parameter
High-speed interface
Control command
2 Graphic Layers support
Scroll function
AND/OR/EXOR
etc.
Leaflet contents, and specifitaions and external appearance of products, may change without notice.
Please confirm product details in the specification.
(C)Copyright NORITAKE ITRON CORP.
'14/11
