SMAJ5930B-TP: Descriptionzener diodes 1.5W 16v; Categorysemiconductor Discrete semiconductor; File Size378KB，5 Pages; ManufacturerMCC; Websitehttp://www.mccsemi.com; Environmental Compliance

Download Datasheet Parametric Compare View All

SMAJ5930B-TP Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SMAJ5930B-TP	-	-	View	Buy Now

SMAJ5930B-TP Overview

zener diodes 1.5W 16v

SMAJ5930B-TP Parametric

Parameter Name	Attribute value
Manufacture	Micro Commercial Components (MCC)
Product Category	Zener Diodes
RoHS	Yes
Zener Voltage	16 V
Voltage Tolerance	5 %
Power Dissipati	1.5 W
Maximum Reverse Leakage Curre	500 nA
Maximum Zener Impedance	10 Ohms
Maximum Operating Temperature	+ 150 C
Configurati	Single
Mounting Style	SMD/SMT
Package / Case	DO-214AC
Packaging	Reel
Minimum Operating Temperature	- 65 C
Factory Pack Quantity	7500

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

SMAJ5918B

THRU

SMAJ5942B

1.5 Watt

Zener Diode

5.1 to 51 Volts

•

Features

•

Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates

Compliant. See ordering information)

Low Zener Impedance

Low Regulation Factor

– tolerance:

f5%

For Surface Mount Applications

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0

and MSL rating 1

Maximum Ratings

•

Junction Temperature: 150

Storage Temperature: -65 to +175

1.5 Watt DC Power Dissipation (T

)

Thermal Resistance Junction to

Lead: 50

Forward Voltage @ 200mA: 1.5 Volts

DO-214AC

(SMAJ)( LEAD FRAME)

DIMENSIONS

INCHES

MIN

.079

.050

.002

---

.030

.065

.189

.157

.090

MIN

2.00

1.27

.05

---

.76

1.65

4.80

4.00

2.25

DIM

MAX

.096

.064

.008

.02

.060

.091

.220

.181

.115

MAX

2.44

1.63

.20

.51

1.52

2.32

5.59

4.60

2.92

NOTE

SUGGESTED SOLDER

PAD LAYOUT

0.085 ”

MA X

0.058 ” MI N

Note:

High Temperature Solder Exemptions Applied, see EU Directive Annex 7.

0.05

MI N

Revision:

www.mccsemi.com

1 of 5

2008/02/01
