CLS02
TOSHIBA Schottky Barrier Diode
CLS02
Switching-Mode Power Supply (Secondary-Rectification)
Applications (Low Voltage)
DC/DC Converter Applications
•
•
•
•
Forward voltage: V
FM
= 0.55 V (max)
5.5
±
0.1
Unit: mm
4
±
0.2
1.5
±
0.1
②
0.6
±
0.1
Suitable for compact assembly due to small surface-mount package:
“L−FLAT
TM
” (Toshiba package name)
1.2
±
0.1
1.8
±
0.1
①
0 ~ 0.03
2.7
±
0.2
Characteristics
Repetitive peak reverse voltage
Average forward current
Non-repetitive peak surge current
Junction temperature
Storage temperature range
Symbol
V
RRM
I
F (AV)
I
FSM
T
j
T
stg
Rating
40
10 (Note.1)
100 (50 Hz)
−40~125
−40~150
Unit
2.85
±
0.2
V
A
A
°C
°C
①
ANODE
②
CATHODE
JEDEC
JEITA
TOSHIBA
⎯
⎯
3-4F1A
Note1: Tℓ
=
75°C
Rectangular waveform (α
=
180°), V
R
=
20 V
Weight: 0.15 g (typ.)
Note2: Using continuously under heavy loads (e.g. the application of high
temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating
conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Symbol
V
FM (1)
Peak forward voltage
V
FM (2)
V
FM (3)
Peak repetitive reverse current
Junction capacitance
I
RRM (1)
I
RRM (2)
C
j
Test Condition
I
FM
=
3.0 A (pulse test)
I
FM
=
5.0 A (pulse test)
I
FM
=
10 A (pulse test)
V
RRM
=
5 V (pulse test)
V
RRM
=
40 V (pulse test)
V
R
=
10 V, f
=
1.0 MHz
Device mounted on a glass-epoxy
board
(board size: 50 mm
×
50 mm)
(board thickness: 1.6 t)
(soldering land)
Cathode 5.7 mm × 6.2 mm
Anode
4.5 mm × 3.4 mm
⎯
Min
⎯
⎯
⎯
⎯
⎯
⎯
Typ.
0.36
0.41
0.5
4.0
0.03
420
Max
⎯
⎯
0.55
⎯
1.0
⎯
μA
mA
pF
V
Unit
Thermal resistance
(junction to ambient)
R
th (j-a)
⎯
⎯
100
°C/W
Thermal resistance
(junction to lead)
R
th (j-ℓ)
⎯
⎯
5
°C/W
1
2007-11-06
3.2
±
0.2
4.2
±
0.2
Absolute Maximum Ratings
(Ta = 25°C)
0.8
±
0.2
Repetitive peak reverse voltage: V
RRM
= 40 V
8.2
±
0.2
Average forward current: I
F (AV)
= 10 A
CLS02
Marking
Abbreviation Code
S02
Part No.
CLS02
Standard Soldering Pad
Unit: mm
5.9
2.5
1.8
2.6
4.8
Handling Precautions
1)
Schottky barrier diodes have reverse current characteristics compared to other diodes. There is a possibility
that SBD will cause thermal runaway when used under high-temperature or high-voltage conditions. Be sure
to take forward and reverse loss into consideration during design.
The absolute maximum ratings, are rated values that must not be exceeded during operation, even for an
instant. The following are the general derating methods that we recommend for when designing a circuit
incorporating this device.
V
RRM
: Use this rating with reference to (1) above. V
RRM
has a temperature coefficient of 0.1%/°C. Take
this temperature coefficient into account when designing a device for operation at low
temperatures.
I
F (AV)
: We recommend that the worst case current be no greater than 80% of the maximum rating of I
F
(AV)
and that T
j
be below 100°C. When using this device, take the margin into consideration by
using an allowable Tamax-I
F (AV)
curve.
I
FSM
:
This rating specifies the non-repetitive peak current. This applies only to abnormal operation,
which seldom occurs during the lifespan of the device.
Derate this rating when using the device in order to ensure high reliability. We recommend that
the device be used at a T
j
of below 100°C.
2)
T
j
:
3)
Thermal resistance between junction and ambient fluctuates depending on the mounting condition of the
device. When using the device, design the circuit board and soldering land size to match the appropriate
thermal resistance value.
Refer to the databook on Rectifiers for further information.
