MKP4PCM22.50.47/10/400VDCREEL18/360 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> MKP4PCM22.50.47/10/400VDCREEL18/360

MKP4PCM22.50.47/10/400VDCREEL18/360: DescriptionFilm Capacitor, Polypropylene, 400V, 10% +Tol, 10% -Tol, 0.47uF, Through Hole Mount, RADIAL LEADED; CategoryPassive components capacitor; File Size73KB，3 Pages; ManufacturerWIMA; Websitehttps://www.wima.de/; Environmental Compliance

Download Datasheet Parametric View All

MKP4PCM22.50.47/10/400VDCREEL18/360 Overview

Film Capacitor, Polypropylene, 400V, 10% +Tol, 10% -Tol, 0.47uF, Through Hole Mount, RADIAL LEADED

MKP4PCM22.50.47/10/400VDCREEL18/360 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	2035425805
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	0.47 µF
Capacitor type	FILM CAPACITOR
dielectric materials	POLYPROPYLENE
JESD-609 code	e3
Installation features	THROUGH HOLE MOUNT
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	TR, 13 INCH
positive tolerance	10%
Rated (AC) voltage (URac)	220 V
Rated (DC) voltage (URdc)	400 V
Guideline	IEC60384-16
surface mount	NO
Terminal surface	Tin (Sn)
Terminal shape	WIRE

Preview

Download Datasheet

View All

WIMA MKP 4

Metallisierte Polypropylen-Kondensa-

toren für erhöhte Anforderungen

Niedrigster Verlustfaktor.

Konstant negativer TKc.

Niedrige dielektrische Absorption: geeignet für

„sample-and-hold“-Schaltungen.

Für Anwendun-

gen im Bereich hoher Frequenzen.

Hohe Kapazi-

tätswerte z.B. für Lautsprecherweichen.

Gegurtet

lieferbar bis einschl. Bauform 15 x 26 x 31,5/RM 27,5.

Metallized polypropylene capacitors

for stringent requirements

Extremely low dissipation factor.

Constantly neg-

ative TKc.

Low dielectric absorption: suitable for

„sample and hold“ circuits.

Suitable for applications

in high frequencies.

High capacitance values e.g. for

frequency dividing in loudspeakers.

Available taped

and reeled up to and incl. case size 15x26x31.5/PCM 27.5.

Technische Angaben

Dielektrikum:

Polypropylen-Folie.

Beläge:

Aluminium, aufmetallisiert.

Umhüllung:

Flammhemmendes Kunststoffgehäuse, UL 94 V–0.

Farbe: Rot. Aufdruck: Schwarz. Epoxidharzverguß: Rot.

Temperaturbereich:

–55

)

C bis +100

)

Prüfungen:

Nach IEC 60384-16 bzw.

EN 131 200.

Prüfklasse:

55/100/56 nach IEC.

Isolationswerte

bei +20° C:

C 0,33

mF:

1 10

MV (Mittelwert: 5 10

MV).

C > 0,33

mF:

30 000 s (MV

mF)

(Mittelwert: 100 000 s).

Nach IEC 60384-16 und EN 131 200.

Meßspannung: 100 V/1 min.

Kapazitätstoleranzen:

20 %,

10 %,

5 %.

Impulsbelastung:

„

Technical Data

Dielectric:

Polypropylene film.

Capacitor electrodes:

Vacuum-deposited aluminium.

Encapsulation:

Flame retardent plastic case, UL 94 V–0.

Colour: Red. Marking: Black. Epoxy resin seal: Red.

Temperature range:

–55

)

C to +100

)

Test specification:

In accordance with IEC 60384-16

and EN 131 200.

Test category:

55/100/56 in accordance with IEC.

Insulation resistance

at +20 ° C:

C 0.33

mF:

1 x 10

MV (mean value: 5 x 10

MV).

C > 0.33

mF:

30 000 sec (MV x

mF)

(mean value: 100 000 sec).

In accordance with IEC 60384-16 and EN 131 200.

Measuring voltage: 100 V/1 min.

Capacitance tolerances:

20 %,

10 %,

5 %.

Maximum pulse rise time:

Capacitance

pF/mF

1000 . . . 6800

0.01 . . . 0.022

0.033 . . . 0.068

0.1 . . . 0.22

0.33 . . . 0.68

1.0 . . . 2.2

3.3 . . . 4.7

6.8 . . . 10

15 . . . 22

Pulse rise time V/msec

max. operation/test

100 VDC 250 VDC 400 VDC 630 VDC 1000 VDC

55/550

45/450

25/250

15/150

10/100

7.5/75

6/60

4/40

3.5/35

55/550

45/450

25/250

15/150

10/100

7.5/75

6/60

5/50

55/550

45/450

30/300

17/170

13/130

9/90

8/80

6/60

60/600

50/500

35/350

20/200

15/150

11/110

9/90

8.5/85

65/650

55/550

40/400

22/220

18/180

13/130

C-Wert

pF/mF

1000 . . . 6800

0,01 . . . 0,022

0,033 . . . 0,068

0,1 . . . 0,22

0,33 . . . 0,68

1,0 . . . 2,2

3,3 . . . 4,7

6,8 . . . 10

15 . . . 22

100 V-

55/550

45/450

25/250

15/150

10/100

7,5/75

6/60

4/40

3,5/35

Flankensteilheit V/ms

max. Betrieb/Prüfung

250 V- 400 V- 630 V-

55/550

45/450

25/250

15/150

10/100

7,5/75

6/60

5/50

55/550

45/450

30/300

17/170

13/130

9/90

8/80

6/60

60/600

50/500

35/350

20/200

15/150

11/110

9/90

8,5/85

1000 V-

65/650

55/550

40/400

22/220

18/180

13/130

bei vollem Spannungshub.

Verlustfaktoren

bei +20

)

C: tan

for pulses equal to the rated voltage.

Dissipation factors

at +20

)

C: tan

Gemessen bei C

1 kHz

10 kHz

100 kHz

0,1

0,4 10

-3

0,6 10

-3

2,5 10

-3

„

1,0

C > 1,0

1,0 10

-3

–

„

at f

1 kHz

10 kHz

100 kHz

0.1

0.4 x 10

-3

0.6 x 10

-3

2.5 x 10

-3

1.0

C > 1.0

1.0 x 10

-3

–

0,5 10

-3

0,8 10

-3

–

0.5 x 10

-3

0.8 x 10

-3

–

Prüfspannung:

1,6 U

, 2 s.

Schwingen:

6 h bei 10 . . . 2000 Hz und 0,75 mm Auslenkung

bzw. 10 g nach IEC 60068-2-6.

Unterdruck:

1 kPa = 10 mbar nach IEC 60068-2-13.

Stoßtest:

4000 Stöße mit 390 m/s

nach IEC 60068-2-29.

Dielektrische Absorption:

0,05 %.

Spannungsderating:

Die zulässige Spannung vermindert sich

gegenüber der Nennspannung bei Gleichspannungsbetrieb ab

+85) C, bei Wechselspannungsbetrieb ab +75) C um 1,35 %

je 1 K.

Kurven siehe Seite 7.

Test voltage:

1.6 U

, 2 sec.

Vibration:

6 hours at 10 . . . 2000 Hz and 0.75 mm displacement

amplitude or 10 g in accordance with IEC 60068-2-6.

Low air density:

1 kPa = 10 mbar in accordance with IEC

60068-2-13.

Bump test:

4000 bumps at 390 m/sec

in accord. with IEC 60068-2-29.

Dielectric absorption:

0.05 %.

Voltage derating:

A voltage derating factor of 1.35 % per K

must be applied from +85° C for DC voltages and from +75 ° C

for AC voltages.

Graphs see page 7.

01-04
