DRAWING NO.
PART NUMBER
27-9008
ITEM 1
NUT
ITEM 2
BODY
ITEM 3
LABEL
ITEM 4
CONTACT
ITEM 5
INSULATOR
DELRIN
27-9008
REVISIONS
01
OFFICIAL RELEASE
08-18-09
L
L
T
H
2009.09.0
8 09:33:27
+08'00'
ZINC
BRASS
SELF ADHESIVE BRASS
NICKEL PLATED NICKEL PLATED PE
GOLD PLATED
D
D
3
1
2
5
±1%
4
O
8.3
C
50
C
REF
O
14.5
25.3
u
0.5
CONTROLLED DOCUMENT
P/N
B
27-9008
Rev
01
Rel'd Date
SEP 14,09
B
NOTES:
1. IMPEDANCE: 50 OHMS NOMINAL
2. FREQUENCY RANGE: 0-1 GHz
3. RECOMMENDED TEMPERATURE RANGE: -55
TO +85
±1%))
THIS DRAWING TO BE INTERPRETED
PER ANSI Y 14.5M - 1994
4. FURTHER TECHNICAL DETAIL: REFER TO EMERSON DOCUMENT P/N 27-0000
A
5. LABLE: GREEN BACKGROUND GRAY WORDS (50
COMPANY CONFIDENTIAL
TOLERANCE UNLESS DRAWN BY
OTHERWISE SPECIFIED
LINDA.WU
DECIMALS
X
X.X
X.XX
ANGLES
mm
CHECKED BY
DATE
08-18-09
DATE
TITLE
A
Connectivity
Solutions
CP88T50 BNC(M) 50TERM, NO CHAIN
SHEET
1 OF 1
DRAWING NO.
SIZE
+
0.5
-
+
0.2
-
+
0.1
-
+
0.5
v
-
08-18-09
APPROVED BY DATE
LINDA.WU
THOMAS
08-18-09
U/M
mm
THIS DRAWING WAS PRODUCED BY COMPUTER,
DO NOT SCALE DRAWING OR UPDATE MANUALLY.
27-9008
1
C
5
4
3
2
