CMOS Oscillator -55+125°C
Specifications
MCSO2: 10.0kHz ~ 20.0MHz
MCSO2H:
20.0
~ 225MHz
MCSO2
Parameters
Frequency range:
10.0kHz ~ 225MHz
Supply voltage (V
DD
):
+5.0V (±5%)
+3.3V (±5%)
+2.5V (±5%)
+1.8V (±5%)
Product
MCSO2
See table
CMOS
Option
Codes
V
W
Z
T
specify
A
B
C
5.00
±0.01
Frequency stability*:
3.20
±0.01
±100ppm
±50ppm
tighter stabilities on request
1.70
(max)
Operating temperature range:
0 to +70°C
-40 to +85°C
-55 to +125°C
SOLDER PAD LAYOUT
Storage temperature range:
-65 to +125°C
Supply current:
Driving ability:
Load:
Logic levels:
1
4
2
3
1.60
4
3
1.00
1.60
1
2.35
2
1.00
1.50 2.70 1.50
TOP VIEW
3pF min, 47pF max
‘0’ level = +0.4V max
‘1’ level = V
DD
-0.5V min
5ms max
Start up time:
Features
Waveform symmetry:
40:60 max @ 50%V
DD
Rise / fall times:
7ns max (≤20MHz, 15pF, 20~80%V
P-P
)
3ns max (>20MHz, 15pF, 10~90%V
P-P
)
150ns max@ 32.768kHz
Enable / disable function:
None (pad 1 NC)
Active* (control via pad 1)
* not available under 500kHz
Shock resistance:
5,000G, 0.3ms, ½ sine
Vibration resistance:
20G rms 10.0 ~ 2,000Hz
Soldering condition:
260°C, 10 sec max
Terminations:
Gold plated pads
Tinned Ag/Cu/Zn
Military temperature range -55+125°C option
Excellent shock & vibration resistance
Enable / disable tristate option (>500kHz)
Wide frequency range available
Optional tinned pads (Ag/Cu/Zn)
E
T
Enable / Disable Function
Input (pad 1)
Open
‘1’ level
‘0’ level
Reaction time <1μs
Output (pad 3)
Enabled
Enabled
No clock
Standard.
Optional - Please specify required code(s) when ordering
Supply current
Freq / Supply
1.8/2.5V
3.3V
1mA
4mA
5mA
30mA
5.0V
2mA
6mA
7mA
40mA
32kHz
300μA
2mA
≤10MHz
3mA
>10 ~ 20MHz
25mA
>20 ~ 160MHz
Maximum values, no load.
* Frequency stability is inclusive of calibration @ 25°C, operating temperature range, sup-
ply voltage change, load change and ageing over 10 years (1 year for stability option T).
Ordering Information
Product name + option codes + frequency
eg:
MCSO2/CE 10.0MHz
5V ±100ppm -55 to +125°C Enable / disable
For frequencies
20.0MHz
add an 'H' to the product name
eg:
MCSO2HW/TB 32.0MHz
2.5V ±50ppm -40 to +85°C no E/D
Option code X (eg MCSO2/X) denotes a custom specification.
Packed in trays (128pcs/tray) or T&R 250 ~ 1,000pcs/reel
A 47nF ceramic capacitor must be connected between GND and V
DD
Tel:
+44 1460 256 100
30 Mar 2017
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
