H
Applications
●
●
●
●
●
Min.
Thru-Hole
SMD
TTL / CMOS
1.0V
1.2V
1.8V
2.5V
3.3V
5.0V
20KHz
Max.
160MHz
CPU , Graphics , Multimedia A / V clocks
MPEG / DVD / HDTV clocks
Laser engine pixel / set - top clocks
OC-3 , OC-12 , OC-48 and OC-192 clocks
SONET / SDH / ATM clocks
●
●
●
●
Fast Ethernet and Gigabit Ethernet clocks
NTSC / PAL encoder / decoder clocks
PLL / synthesizer clocks
Fibre channel and ADSL clocks
General Specifications
[ TA = +25°C , V
DD
= at specified voltage , Load : 15 pF ]
Model
Input Voltage ( V
DD
)
+ 1.0V D.C.±5%
code is " 1 "
+ 1.2V D.C.±5%
code is " 12 "
"
H
" series
+ 1.8V D.C.±5%
code is " 18 "
1.8 MHz ~ 60 MHz
CMOS
TTL
CMOS
CMOS
+ 2.5V D.C.±5%
code is " 25 "
0.3 MHz ~ 125 MHz
CMOS
+ 3.3 V D.C.±5%
code is " 3 "
20KHz ~ 130 MHz
T T L / CMOS
2.4 V ( min. )
0.9 V ( min. )
1.08 V ( min. )
1.62 V ( min. )
2.25 V ( min. )
2.97 V ( min. )
0.4 V ( max. )
0.1 V ( max. )
0.12 V ( max. )
0.18 V ( max. )
0.25 V ( max. )
0.33 V ( max. )
+ 5.0V D.C.±10%
code is " 5 "
20 KHz ~ 160 MHz
T T L / CMOS
2.4 V ( min. )
4.5 V ( min. )
0.4 V ( max. )
0.5 V ( max. )
Frequency Range
Output Wave Form
Output Logic High " 1 "
CMOS
TTL
Output Logic Low " 0 "
CMOS
Frequency Stability over
Operating Temperature Range
Frequency Stability
(1)
Codes
± 25 ppm
± 50 ppm
± 100 ppm
If non-standard , please enter the
desired stability after the " C " or "
I
"
For example :
Commercial ( -10°C
to +70°C
)
A
B
C
" C20 " ±20 ppm over -10°C to +70°C ;
"
I20
" ± 20 ppm over -40°C to +85°C
Industrial (
-40°C to +85°C
)
D
E
F
TTL
Output Load
CMOS
Rise Time ( Tr )
Fall Time ( Tf )
TTL
CMOS
TTL
Duty Cycle
CMOS
Start -Up Time (Ts)
Current Consumption
Storage Temperature
Aging
2 ~ 10 (LS) T T L gates
15 pF typical; 30 pF load for frequencies up to 70 MHz ; Contact Mercury for 50 pF load
10 n sec.(max.) ; 3 n sec.(typical) . Measured between 0.4V
DC
↔
2.4V
DC
( RL=390Ω ; CL = 15pF )
10 n sec.(max.) ; 3 n sec.(typical) . Measured between 10% to 90% wave form ( CL=15pF )
40% (min.) , 60%(max.) Measured at +1.4V
40% (min.) , 60%(max.) Measured at 50% of wave form [ 50% ± 5% is also available , add " S " at the end of the part number
10 m sec. (max.) ; 5 m sec. (typical)
10 ~ 45 mA ( frequency dependent )
- 50°C to 100°C
±5 ppm per year (max.)
Output is high impedance when " 0 " is applied to pin 1 .
Tri-State Option.
Disable time is 150 n sec. max.
Add " T " in part number for Tri-State option
Mercury
www .mercury-crystal.com
■Taiwan
: Tel (886)-2-2406-2779 / sales-tw@mercury-crystal.com
■U.S.A:
Tel: (1)-909-466-0427 / sales-us@mercury-crystal.com
■China:
Tel: (86)-512-5763-8100 / sales-cn@mecxtal.com
