Hi-Voltage Metallized Polyester
Film Capacitors
F
EATURES
•
•
•
Good self-healing properties
Non-inductive construction
Flame retardant epoxy resin coating
(In compliance with UL 94V-0)
HMPE
Series
(Radial Dipped)
MERITEK
S
PECIFICATIONS
1. Operating temperature:
2. Capacitance range:
3. Capacitance tolerance:
4. Rated voltage:
5. Dissipation factor:
6. Insulation resistance:
-40
o
C to +85
o
C
0.0022μF to 0.22μF
±5%(J), ±10%(K), ±20%(M)
1000VDC, 1250VDC
1.0% max. at 1KHz, 25
o
C
>30000MΩ (C
≤
0.33μF)
>10000MΩ
μF
(C > 0.33μF)
are constructed with metallized polyester
film dielectric, tinned copper leads, and epoxy resin
coating. They are suitable for DC and pulse circuits
at medium and high voltages
.
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
101
100
---
---
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
HMPE
HMPE
682
K
3A
105
1000
1
106
10
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
Rated Voltage
CODE
3A
1000V
3B
1250V
Dimensions in millimeters (mm)
RV
DIM.
CAP(μF)
0. 0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
W
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
30.0
30.0
30.0
30.0
H
10.0
10.0
12.0
12.5
14.0
14.0
15.0
15.0
15.0
15.5
16.0
17.0
18.0
18.0
18.0
18.0
18.0
18.5
19.5
20.5
22.5
21.0
22.0
23.0
24.5
1000VDC
T
6.5
6.5
6.5
6.5
7.0
7.0
8.0
8.0
8.0
8.0
9.0
9.5
10.0
10.0
10.0
10.0
9.0
10.0
11.0
11.5
12.0
10.5
11.5
12.5
14.0
P
16.0
16.0
16.0
16.0
16.0
16.0
16.0
16.0
16.0
16.0
16.0
16.0
16.0
21.0
21.0
21.0
21.0
21.0
21.0
21.0
21.0
26.0
26.0
26.0
26.0
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
W
20.0
20.0
20.0
20.0
20.0
20.0
20.0
25.0
25.0
25.0
25.0
25.0
25.0
30.0
30.0
30.0
30.0
35.0
35.0
35.0
H
11.0
10.5
12.0
12.5
12.5
14.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.5
16.0
16.5
18.0
18.0
18.5
19.0
1250VDC
T
6.5
6.5
6.5
6.5
7.0
7.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.5
9.0
9.0
9.0
9.5
10.5
P
16.0
16.0
16.0
16.0
16.0
16.0
16.0
21.0
21.0
21.0
21.0
21.0
21.0
26.0
26.0
26.0
26.0
31.0
31.0
31.0
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
Custom sizes and lead spacing available upon request
Custom values and tolerances available upon request
Specifications are
subject to change without notice.
rev.6a
