ALUMINUM ELECTROLYTIC CAPACITORS
HZ
Ultra Low Impedance,
For PC motherboard
series
Lower impedance than HN series.
Compliant to the RoHS directive (2002/95/EC).
HZ
Specifications
ltem
Category Temperature
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
–25 to +105˚C
6.3 to 16V
470 to 3300µF
±
20% (120Hz, 20˚C)
Low
Impedance
HN
Performance Characteristics
After 2 minutes' application of rated voltage, leakage current is less than 0.03CV
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF
Rated voltage (V)
6.3
10
16
120Hz 20˚C
120Hz
Stability at Low Temperature
tan
δ
(MAX.)
Rated voltage (V)
Impedance ratio ZT / Z20 (MAX.) Z—25˚C / Z+20˚C
0.22
6.3
3
0.19
10
3
0.16
16
3
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20
˚C
after D.C. bias plus
rated ripple current is applied for 2000 hours at 105˚C,
the peak voltage shall not exceed the rated voltage.
Printed with gold color letter on black sleeve.
Capacitance change
tan
δ
Leakage current
Within
±30%
of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Marking
Radial Lead Type
φd
Sleeve (P.E.T.)
Type numbering system (Example : 6.3V 1800µF)
1
2
3
4
5
6
7
8
9 10 11 12
UH Z 0 J 1 8 2 MPM
Size code
P
±0.5
φD
+
0.5 MAX.
Configuration
Capacitance tolerance (±20%)
Rated capacitance (1800µF)
L+
1.5MAX.
Pressure relief vent
15
MIN
4
MIN
Rated voltage (6.3V)
(mm)
φD
P
φd
8
3.5
0.6
10
5.0
0.6
Configuration
φ
D
8
⋅
10
Series name
Type
Pb-free leadwire
Pb-free PET sleeve
PM
Standard Ratings
V (Code)
Cap. (µF)
470
680
820
1000
1200
1500
1800
2200
2700
3300
Co
Item
de
Case size
φD ×
L
(mm)
6.3 (0J)
Impedance
Rated ripple
(mΩ) MAX.
(mArms)
20˚C / 100kHz 105˚C / 100kHz
Case size
φD ×
L
(mm)
10 (1A)
Impedance
Rated ripple
(mΩ) MAX.
(mArms)
20˚C / 100kHz 105˚C / 100kHz
471
681
821
102
122
152
182
222
272
332
8
×
15
10
×
12.5
8
×
15
10
×
12.5
8
×
20
10
×
16
10
×
16
8
×
20
10
×
16
10
×
20
10
×
20
10
×
25
10
×
12.5
10
×
12.5
10
×
12.5
10
×
16
8
×
20
10
×
16
10
×
16
8
×
20
10
×
20
10
×
25
12
12
12
10
9
10
10
9
7
6.5
2288
2280
2280
2960
2880
2960
2960
2880
3770
4140
14
12
14
12
9
10
10
9
10
7
7
6.5
2210
2280
2210
2280
2880
2960
2960
2880
2960
3770
3770
4690
16 (1C)
Impedance
Case size
Rated ripple
(mΩ) MAX.
φD ×
L
(mArms)
20˚C / 100kHz 105˚C / 100kHz
(mm)
10× 12.5
12
2280
10× 12.5
12
2280
8× 20
9
2880
10× 16
10
2960
10× 16
10
2960
10× 16
10
2960
8× 20
9
2880
10× 20
7
3770
10× 20
7
3770
10× 20
10× 25
7
6.5
3770
4140
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
: In this case,
n
will be put at 12th digit of type numbering system.
: In this case,
c
will be put at 12th digit of type numbering system.
: In this case,
.
will be put at 12th digit of type numbering system.
CAT.8100Z
