8D Series
Presentation
Since the early 80’s, SOURIAU is a major supplier of 38999 Series III, the screw-coupled version of MIL-C-38999.
Present on the main international programs, Souriau has developed a range of products that meet the performance
required in extreme environments. This product family is in accordance with MIL-DTL-38999 Series III, EN 3645,
CECC (standard for bronze shell), ... and also meets many customers’ standards (Rolls Royce, ABS, BACC, ...)
This evolution of MIL-C-38999 allows:
►
A high contact density up to 128 contacts #22D
►
A quick screw coupling with self locking mechanism
►
High resistance to harsh environments (vibration, 200°C)
Always at the cutting edge of innovation, Souriau’s teams have continuously improved this range of connectors:
►
Composite version in the 90’s (Its choice is recommended wherever weight is critical)
►
Titanium version for weight saving and very high and mechanical resistance
►
Today SOURIAU remains innovative with cadmium free and RoHS solutions.
In 2009 Souriau was the first to be QPL qualified for Zinc Nickel plating.
