BA7609F-E2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> BA7609F-E2

BA7609F-E2: Descriptionvideo ics 4.5-5.5V 12.5ma 50ns; CategoryAnalog mixed-signal IC The signal circuit; File Size395KB，11 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BA7609F-E2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BA7609F-E2	-	-	View	Buy Now

BA7609F-E2 Overview

video ics 4.5-5.5V 12.5ma 50ns

BA7609F-E2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SOIC
package instruction	LSOP, SOP16,.25
Contacts	16
Reach Compliance Code	compli
Analog Integrated Circuits - Other Types	AUDIO/VIDEO SWITCH
JESD-30 code	R-PDSO-G16
JESD-609 code	e2
length	10 mm
Number of channels	2
Number of functions	3
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	LSOP
Encapsulate equivalent code	SOP16,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE
Peak Reflow Temperature (Celsius)	260
power supply	5 V
Certification status	Not Qualified
Maximum seat height	1.6 mm
Maximum supply current (Isup)	20 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal surface	Tin/Copper (Sn/Cu)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	10
width	4.4 mm

Preview

Download Datasheet

View All

High-Performance Video Signal Switchers

Triple-circuit

Video Switchers

BA7602F,BA7603F,BA7606F,BA7606FS,BA7607F,BA7609F,BA7627FV

No.11066EAT02

●Description

These video switching ICs, which contain two or three 2-input circuits, were developed for switching TV, DVD, and other

video signals. Input pin formats can be selected from bias mode (R=20 kΩ), sync-tip mode, and pedestal clamp mode.

Having a large dynamic range and broad frequency characteristics, these switches are suited to a wide range of applications

from audio signals to video signals.

●Features

1) Contain three 2-input, 1-output switch circuits

2) Power supply voltage (4.5~5.5 V)

3) Low power consumption

4) Good frequency characteristics

5) Large dynamic range

6) Bias input (BA7602F)

Sync-tip clamp input (BA7603F)

Pedestal clamp input (BA7606F, BA7606FS)

Bias input + sync-tip clamp input (BA7607F, BA7609F, BA7627FV)

7) Large input impedance (Typ.20kΩ)

8) Fast switching speed (Typ. 50ns)

●Applications

For switching TV, DVD, and Other video signals

●Line

up matrix

Part No.

BA7602F

BA7603F

BA7606F

BA7606FS

BA7607F

BA7609F

BA7627FV

Circuit current

(mA)

14.0

13.0

15.0

12.5

Built-in circuit

2 in 3 circuits

Input type

Bias

Clamp

Pedestal

Clamp

Clamp 2

Bias1

Clamp 1

Bias 2

Clamp 2

Bias1

Distortion

(%)

－

0.007

Maximum

output level

P-P

)

3.1

2.9

2.6

3.0

Package

SOP16

SOP16/

SSOP-A16

SOP16

SSOP-B16

www.rohm.com

1/10

2011.03 - Rev.A

BA7609F-E2 Related Products

	BA7609F-E2	BA7627FV-E2	BA7606F-E2	BA7606FS-E2	BA7602F-E2	BA7606FE2	BA7607F-E2	BA7603F-E2
Description	video ics 4.5-5.5V 12.5ma 50ns	video ics video signal switch 16pin	video ics 4.5-5.5V 15ma 50ns	video ics 4.5-5.5V 15ma 50ns	video ics 4.5-5.5V 14ma 50ns	SPECIALTY CONSUMER CIRCUIT, PDSO16, SOP-16	IC video signal switchers 16sop	video signal converter
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	LSOP, SOP16,.25	LSSOP, TSSOP16,.25	LSOP,	SSOP, SOP16,.25,32	LSOP, SOP16,.25	LSOP,	LSOP, SOP16,.25	LSOP, SOP16,.25
Reach Compliance Code	compli	compli	compliant	compliant	compliant	unknown	compliant	compliant
JESD-30 code	R-PDSO-G16	R-PDSO-G16	R-PDSO-G16	R-PDSO-G16	R-PDSO-G16	R-PDSO-G16	R-PDSO-G16	R-PDSO-G16
Number of terminals	16	16	16	16	16	16	16	16
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LSOP	LSSOP	LSOP	SSOP	LSOP	LSOP	LSOP	LSOP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	SMALL OUTLINE, LOW PROFILE	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, LOW PROFILE	SMALL OUTLINE, LOW PROFILE	SMALL OUTLINE, LOW PROFILE	SMALL OUTLINE, LOW PROFILE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	1.27 mm	0.65 mm	1.27 mm	0.8 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maker	ROHM Semiconductor	-	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor	-
Parts packaging code	SOIC	SOIC	SOIC	-	SOIC	SOIC	SOIC	SOIC
Contacts	16	16	16	-	16	16	16	16
Analog Integrated Circuits - Other Types	AUDIO/VIDEO SWITCH	AUDIO/VIDEO SWITCH	-	SINGLE-ENDED MULTIPLEXER	AUDIO/VIDEO SWITCH	-	AUDIO/VIDEO SWITCH	AUDIO/VIDEO SWITCH
JESD-609 code	e2	-	e2	-	e2	e2	e2	e2
length	10 mm	5 mm	10 mm	-	10 mm	10 mm	10 mm	10 mm
Number of channels	2	2	-	2	2	-	2	2
Number of functions	3	1	-	3	3	1	3	3
Maximum operating temperature	85 °C	85 °C	-	85 °C	85 °C	-	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-	-40 °C	-40 °C	-	-40 °C	-40 °C
Encapsulate equivalent code	SOP16,.25	TSSOP16,.25	-	SOP16,.25,32	SOP16,.25	-	SOP16,.25	SOP16,.25
Peak Reflow Temperature (Celsius)	260	NOT SPECIFIED	260	-	260	260	260	260
power supply	5 V	5 V	-	5 V	5 V	-	5 V	5 V
Maximum seat height	1.6 mm	1.25 mm	1.6 mm	-	1.6 mm	1.6 mm	1.6 mm	1.6 mm
Maximum supply current (Isup)	20 mA	17 mA	-	15 mA	20.5 mA	-	17 mA	20 mA
Maximum supply voltage (Vsup)	5.5 V	5.5 V	5 V	-	5.5 V	5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V	5 V	-	4.5 V	5 V	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	5 V	-	5 V	5 V	-	5 V	5 V
technology	BIPOLAR	BIPOLAR	-	BIPOLAR	BIPOLAR	-	BIPOLAR	BIPOLAR
Temperature level	INDUSTRIAL	INDUSTRIAL	-	INDUSTRIAL	INDUSTRIAL	-	INDUSTRIAL	INDUSTRIAL
Terminal surface	Tin/Copper (Sn/Cu)	-	Tin/Copper (Sn/Cu)	-	Tin/Copper (Sn/Cu)	TIN COPPER	TIN COPPER	Tin/Copper (Sn/Cu)
Maximum time at peak reflow temperature	10	NOT SPECIFIED	10	-	10	10	10	10
width	4.4 mm	4.4 mm	4.4 mm	-	4.4 mm	4.4 mm	4.4 mm	4.4 mm
Base Number Matches	-	1	1	1	1	1	-	1
