SINGLE PHASE BRIDGE RECTIFIER
RS201 THRU RS207
FEATURES
•
•
•
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
2.0 Ampere
UL recognized under component index, file
Number E127707
High forward surge current capability
High temperature soldering guaranteed:
260
O
C / 10 seconds
MECHANICAL DATA
•
•
•
•
•
Case: Transfer molded plastic
Terminal: Lead solderable per MIL-STD-202E
method 208C
Polarity: Polarity symbols marked on case
Mounting: any
Weight: 0.069 ounce, 1.95 gram
RS-2
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
•
•
•
Ratings at 25
O
C ambient temperature unless otherwise specified
Single Phase, half wave, 60Hz, resistive or inductive load
For capacitive load derate current by 20%
SYMBOLS
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current,
At T
C
= 50
O
C (Note 1)
Peak Forward Surge Current
8.3mS single half sine wave superimposed on
rated load (JEDEC method)
Rating for Fusing (t<8.3mS)
Maximum Instantaneous Forward Voltage drop per
Bridge element 1.0A
Maximum DC Reverse Current at Rated
T
A
= 25
O
C
DC Blocking Voltage per element
T
A
= 100 C
O
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
C
J
R
θJc
T
J
T
STG
RS201 RS202 RS203
50
100
200
35
70
140
50
100
200
RS204 RS205 RS206 RS207
UNIT
400
600
800 1000 Volts
280
420
560
700 Volts
400
600
800 1000 Volts
2.0
50
10
1.0
10
0.5
20
Amps
Amps
A
2
s
Volts
µA
mA
pF
O
Typical Junction Capacitance
(Measured at 1.0MHz and applied reverse voltage of 4.0V)
Typical Thermal Resistance (Note 1)
Operating Junction Temperature Range
Storage Temperature Range
28
(-65 to +150)
(-65 to +150)
C/W
O
C
O
C
Notes:
1.
Unit mounted on PC board with 0.47” x 0.47” (12mm x 12mm) copper pads, 0.375 (9.5mm) lead length.
Sep-03, Rev A
