Precision Military and Space
Qualified Chip Resistors
MIL-CHIP Series
•
Now qualified to MIL-PRF-55342 Space Level T
•
Seven industry standard sizes available
•
MIL-PRF-55342 Characteristics E, H, K, and M
•
MIL-PRF-55342 extended reliability levels C, M, P, R, S and T
Electrical Data
Style
Size
Technology
MIL-PRF-55342
Characteristic
Tolerance
Resistance
Range
(Ω)
100R - 30.0K
50
±1%, ±2%, ±5%, ±10%
±0.1%
Style 12
RM0603
Thin Film
(TaNFilm
®
)
E, H, K, M
±1%, ±2%, ±5%, ±10%
±0.1%
Style 06
RM0705
Thin Film
(TaNFilm
®
)
E, H, K, M
±1%, ±2%, ±5%, ±10%
±0.1%
Style 04
RM1505
Thin Film
(TaNFilm
®
)
E, H, K, M
±1%, ±2%, ±5%, ±10%
±0.1%
Style 07
RM1206
Thin Film
(TaNFilm
®
)
E, H, K, M
±1%, ±2%, ±5%, ±10%
Style 07
RM1206
Style 08
RM2010
Style 09
RM2512
10R0- 125K
10R0- 125K
100R - 125K
250
100
C, M, P,
R, S, T
10R0- 125K
Type `B´
100R - 125K
150
125
C, M, P,
R, S, T
Sn/Pb solder
over nickel
barrier
10R0- 59K
100R - 125K
150
50
C, M, P,
R, S, T
10R0 - 30.0K
100R - 59K
100
50
C, M, P,
R, S, T
30
C, M, P,
R, S
Rated
Power
(mW)
Rated
Voltage*
(V)
Reliability
Level
Termination
Type
±0.1%
Style 11
RM0402
Thin Film
(TaNFilm
®
)
E, H, K, M
Thick Film
K, M
±1%, ±2%, ±5%, ±10%
1R00 - 10M
250
100
C, M,
P, R, T
Thick Film
K, M
±1%, ±2%, ±5%, ±10%
1R00 - 15M
800
150
Thick Film
K, M
±1%, ±2%, ±5%, ±10%
1R0 - 15M
1000
200
*Note: Voltage shall not exceed
√P
X R.
General Note
IRC reserves the right to make changes in product specification without notice or liability.
All information is subject to IRC’s own data and is considered accurate at time of going to print.
A subsidiary of
TT electronics plc
MIL-CHIP Series Issue June 2010 Sheet 1 of 3
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
Precision Military Qualified
Chip Resistors
Environmental Data
Environmental Test
MIL-PRF-55342
Thick Film Performance
MIL-PRF-55342
Characteristic K
±0.5%
±0.25%
±0.25%
±0.5%
±0.25%
±0.5%
±2.0%
Typical IRC
ΔR
±0.04%
±0.01%
±0.03%
±0.05%
±0.09%
±0.06%
±0.10%
Thin Film Performance
MIL-PRF-55342
Characteristic H
±0.25%
±0.25%
±0.10%
±0.50%
±0.25%
±0.40%
±2.0%
Typical IRC
ΔR
±0.02%
±0.01%
±0.01%
±0.03%
±0.01%
±0.03%
±0.03%
Thermal Shock
Low Temperature Operation
Short-time Overload
High Temperature Exposure
Resistance to Solder
Moisture Resistance
Life
Physical Data
L
a
TOP
W
BOTTOM
SIDE
b
H
L
0402
0603
0805
1505
1206 (Thin Film)
1206 (Thick Film)
2010
2512
0.040″ ±0.002
0.063″ ±0.004
0.081″ ±0.005
0.155″ ±0.007
0.126″ ±0.006
0.126″ ±0.008
0.209″ ±0.009
0.259″ ±0.009
W
0.021″ ±0.002
0.031″ ±0.004
0.050″ ±0.005
0.050″ ±0.005
0.063″ ±0.005
0.063″ ±0.005
0.098″ ±0.005
0.124″ ±0.005
H
0.012″ ±0.003
0.020″ ±0.004
0.020″ ±0.006
0.025″ ±0.003
0.024″ ±0.004
0.024″ ±0.004
0.028″ ±0.005
0.028″ ±0.005
a
0.008″ ±0.002
0.008″ ±0.004
0.016″ ±0.008
0.015″ ±0.008
0.016″ ±0.008
0.020″+0.005/
-0.010
0.020″ ±0.005
0.020″ ±0.005
b
0.010″ ±0.002
0.008″ ±0.004
0.016″ ±0.008
0.015″ ±0.008
0.016″ ±0.008
0.020″+0.005/
-0.010
0.020″ ±0.005
0.020″ ±0.005
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
MIL-CHIP Series Issue June 2010 Sheet 2 of 3
Precision Military Qualified
Chip Resistors
Ordering Data For Performance Specification MIL-PRF-55342
D55342
Military Designator
M55342 for styles RM0402, RM0603, RM0705(0805), RM1505, RM2010, and RM2512
D55342 for style RM1206
H
07
B
1E00
S
Characteristic
E, H, K and M per MIL-PRF-55342
Specification Number
04 for style RM1505; 06 for style RM0705(0805); 07 for style RM1206
08 for style RM2010; 09 for style RM2512; 11 for Style RM0402, 12 for style RM0603
Termination
Termination B per MIL-PRF-55342
Resistance and Tolerance
Resistance and tolerance code per MIL-PRF-55342
Product Level Designator
Product level C, M, P, R, S and T per MIL-PRF-55342
Packaging
Standard order packaging is 8mm or 12mm tape per EIA 481. Conductive waffle pack packaging is also available.
For additional information or to discuss your specific requirements,
please contact our Applications team using the contact details below.
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
MIL-CHIP Series Issue June 2010 Sheet 3 of 3
