Ball Grid Array
(BGA) Adapters
5 Energy Way, West Warwick, RI 02893 USA Tel: 800-424-9850 / 401-823-5200 Fax: 401-823-8723 E-mail: info@advintcorp.com Internet: www.advintcorp.com
Standard Adapter (A)
• Mates with Standard Socket (S)
Now Available In
0.75mm Pitch
• Adapter size equals BGA device body + .079 in. (2.0mm)
BGA Body + .079/(2.0)
.039/(1.0)
BGA Device
Adapter Features
• Soldering BGA to Adapter subjects
BGA to less thermal stress than
soldering BGA directly to a PCB due
to Adapter’s lower mass.
• Uses same footprint as BGA device.
• Custom Adapters available for heat
sink attachments.
Extraction Slot Adapter (AX)
• Slots allow easy device/Adapter assembly removal from socket with
Advanced
®
Extraction Tool without damaging valuable PCB
• Mates with Extraction Socket (SB) or Guide Post Socket (SG)
• Adapter size equals BGA device body + .157 in. (4.0mm)
BGA Body + .157/(4.0)
.079/(2.0)
Specifications
Terminals:
Brass; Copper Alloy (C36000),
ASTM-B-16
Plating:
G – Gold over Nickel
Body Material:
F – FR-4 Glass Epoxy, U.L. Rated
94V-0
BGA Device
Advanced
®
BGA Adapter Extraction Tools
P/N 5504
Blade Width
Terminals
1.27mm and
1.5mm Pitch
Type -638
P/N 5566
1.0mm Pitch
Type -715
.159
(4.04)
DEVICE PACKAGE SIZE
< 1.024 (26mm) > 1.024 (26mm)
Tool P/N
Blade Width
5566
.373 in.
5504
.675 in.
.182
(4.62)
.011/(0.28)
Dia.
How To Order – BGA Adapters
1
F
G
A
XXXX - 638
G
Footprint Dash#
Terminal Plating
If Applicable*
G - Gold
Body Type
Terminal Type
F - FR-4
See options at left
Pitch
B = .059/(1.5mm)
Number of Positions
G = .050/(1.27mm)
*See BGA Footprint Booklet
H = .039/(1.0mm)
Model Type
or web site
J = .0315/(0.80mm)
A
= Standard Adapter
K = .0295/(0.75mm)
AX
= Extraction Slot Adapter [1.5, 1.27, & 1.0mm Pitch only]
.018/(0.46)
Dia.
0.80mm Pitch
Type -700
.146
(3.71)
0.75mm Pitch
Type -757
.142
(3.61)
.011/(0.28)
Dia.
.008/(0.20)
Dia.
2
REV. 4/01
Products shown covered by patents issued and/or pending. Specifications subject to change without notice. Dimensions shown:
inch/(mm).
