POWERLINE - DC/DC-Converter
E-Series, 30 Watt, 1.6 kV Isolation & Wide Input Range (Single Output)
Features
●
●
●
●
●
Ideal for Telecom/Networking
Application
2:1 Input Range
Efficiency up to 91%
Six-Sided Shield
On/Off Control
●
●
●
●
Small Package
50.8 x 40.6 x 10.2 mm
Over Current Protection
International Safety Standard
Approvals
UL 1950 Component Recognised
Selection Guide
24V and 48V Input Types
Part Number
RP30-2418SE
RP30-2433SE
RP30-2405SE
RP30-2412SE
RP30-4818SE
RP30-4825SE
RP30-4833SE
RP30-4805SE
RP30-4812SE
RP30-4815SE
Input
Range
18-36 VDC
18-36 VDC
18-36 VDC
18-36 VDC
36-75 VDC
36-75 VDC
36-75 VDC
36-75 VDC
36-75 VDC
36-75 VDC
Output
Voltage
1.8 VDC
3.3 VDC
5 VDC
12 VDC
1.8 VDC
2.5 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
Output
Current
6.00 A
6.00 A
6.00 A
2.50 A
6.00 A
6.00 A
6.00 A
6.00 A
2.50 A
2.00 A
Ripple & noise
50 mVp-p
50 mVp-p
50 mVp-p
75 mVp-p
50 mVp-p
50 mVp-p
50 mVp-p
50 mVp-p
75 mVp-p
75 mVp-p
Efficiency
(%)
82
86
88
91
83
85
87
89
91
91
Maximum Capacitive Load
RP30-xx05SE
RP30-xx1.8SE
RP30-xx3.3SE
RP30-xx05SE
RP30-xx12SE
RP30-xx15SE
10200µF
6500µF
19500µF
10200µF
3300µF
1100µF
PO 58
August 2002
www.recom-international.com
POWERLINE - DC/DC-Converter
E-Series, 30 Watt, 1.6 kV Isolation & Wide Input Range (Single Output)
Specifications
(typical at nominal input and 25°C unless otherwise noted)
Input Voltage Range
Input Filter
Voltage Accuracy
Ripple and Noise, 20MHz BW
Line Regulation, HL-LL
Load Regulation, 100% to 10% Full Load
Efficiency
Temperature Coefficient
Short Circuit Protection
Transient Response Recovery Time, 25% Load Step Change
Transit voltage peak deviation
Control voltage referenced to negativ(-)input Compatibility
On-control
Off-control
Switching frequency
Isolation Voltage
Isolation Resistance
Maximum Case Temperature
Operating Temperature Range
Storage temperature range
Cooling
EMI/RFI
Case Material
Dimensions
MTBF (MIL-HDBK-217F TA = 25°C full load)
24V nominal
48V nominal
18-36VDC
36-75VDC
LC Type
±1%
See Table
±0.2%
See Table
±0.02%/°C
Continuous
400msec
150mV max.
CMOS, TTL
4.8V min. or open
0.4V max. or short
300kHz, typ.
1600VDC min.
10
9
Ω,
min
+100°C
-25°C to +71°C
-55°C to +105°C
Free-air convection
Six-sided Continuos Shield
Nickel-Coated Copper with Non-Conductive Base
50.8 x 40.6 x 10.2 mm
2 x 10
6
Hours
Output Power (%)
80
60
40
20
0
75
62 69
Ambient Temperature
°C
-25 25
50
100
125
Natural
Convection
Cooling
120
100
590
LFM
±0.5%
Package Style and Pinning (mm)
40.60
15.20
10.20
5.10
4
3
2
1
17.80
10.20
Pin Connections
Pin #
1
2
3
4
5
6
7
8
Single
+Vin
-Vin
No Pin
Ctrl
No Pin
+Vout
-Vout
Trim
dia.
1.0
Bottom
View
50.80
45.70
Pin Pitch Tolerance ±0.5 mm
8
7
6
5
10.20
17.80
10.20
12.70
5.6
www.recom-international.com
August 2002
PO 59
