MAX5180BEEI+ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> MAX5180BEEI+

MAX5180BEEI+: Descriptiondigital to analog converters - dac 10-bit 2ch high speed dac; CategoryAnalog mixed-signal IC converter; File Size317KB，14 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html; Environmental Compliance

Download Datasheet Parametric Compare View All

MAX5180BEEI+ Overview

digital to analog converters - dac 10-bit 2ch high speed dac

MAX5180BEEI+ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Maxim
Parts packaging code	SOIC
package instruction	SSOP,
Contacts	28
Reach Compliance Code	compli
ECCN code	EAR99
Maximum analog output voltage	0.8 V
Minimum analog output voltage	-0.3 V
Converter type	D/A CONVERTER
Enter bit code	BINARY
Input format	PARALLEL, WORD
JESD-30 code	R-PDSO-G28
JESD-609 code	e3
length	9.89 mm
Maximum linear error (EL)	0.1953%
Humidity sensitivity level	1
Number of digits	10
Number of functions	1
Number of terminals	28
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.73 mm
Nominal settling time (tstl)	0.025 µs
Nominal supply voltage	3 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.9 mm

Preview

Download Datasheet

View All

19-1577; Rev 4; 12/03

Dual, 10-Bit, 40MHz, Current/Voltage

Simultaneous-Output DACs

General Description

The MAX5180 contains two 10-bit, simultaneous-

update, current-output digital-to-analog converters

(DACs) designed for superior performance in communi-

cations systems requiring analog signal reconstruction

with low distortion and low-power operation. The

MAX5183 provides equal specifications, with on-chip

precision resistors for voltage output operation. The

devices are designed for 10pVs glitch operation to min-

imize unwanted spurious signal components at the out-

put. An on-board 1.2V bandgap circuit provides a

well-regulated, low-noise reference that can be dis-

abled for external reference operation.

The MAX5180/MAX5183 are designed to provide a high

level of signal integrity for the least amount of power dis-

sipation. The DACs operate from a single supply of 2.7V

to 3.3V. Additionally, these DACs have three modes of

operation: normal, low-power standby, and complete

shutdown, which provides the lowest possible power dis-

sipation with 1µA (max) shutdown current. A fast wake-

up time (0.5µs) from standby mode to full DAC operation

conserves power by activating the DACs only when

required.

The MAX5180/MAX5183 are packaged in a 28-pin QSOP

and are specified for the extended (-40°C to +85°C)

temperature range. For lower-resolution, dual 8-bit

versions, refer to the MAX5186/MAX5189 data sheet.

Features

♦

2.7V to 3.3V Single-Supply Operation

♦

Wide Spurious-Free Dynamic Range: 70dB

at f

OUT

= 2.2MHz

♦

Fully Differential Outputs for Each DAC

♦

±0.5% FSR Gain Mismatch

♦

±0.2° Phase Mismatch

♦

Low-Current Standby or Full-Shutdown Modes

♦

Internal 1.2V Low-Noise Bandgap Reference

♦

Small 28-Pin QSOP Package

MAX5180/MAX5183

Ordering Information

PART

MAX5180BEEI

MAX5183BEEI

TEMP RANGE

-40°C to +85°C

PIN-PACKAGE

28 QSOP

Pin Configuration

Applications

Signal Reconstruction of I and Q Transmit

Signals

Digital Signal Processing

Arbitrary Waveform Generation (AWG)

Imaging

TOP VIEW

CREF1 1

OUT1P 2

OUT1N 3

AGND 4

DACEN 6

PD 7

CS 8

CLK 9

N.C. 10

REN 11

D0 12

D1 13

D2 14

28 CREF2

27 OUT2P

26 OUT2N

25 REFO

24 REFR

MAX5180

MAX5183

23 DGND

22 DV

21 D9

20 D8

19 D7

18 D6

17 D5

16 D4

15 D3

QSOP

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

MAX5180BEEI+ Related Products

	MAX5180BEEI+	MAX5183BEEI+	MAX5180BEEI+T
Description	digital to analog converters - dac 10-bit 2ch high speed dac	digital to analog converters - dac 10-bit 2ch high speed dac	IC DAC 10BIT PAR 28QSOP
Is it lead-free?	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to
Maker	Maxim	Maxim	Maxim
Parts packaging code	SOIC	SOIC	SOIC
package instruction	SSOP,	SSOP,	SSOP,
Contacts	28	28	28
Reach Compliance Code	compli	compli	compliant
ECCN code	EAR99	EAR99	EAR99
Maximum analog output voltage	0.8 V	0.8 V	0.8 V
Minimum analog output voltage	-0.3 V	-0.3 V	-0.3 V
Converter type	D/A CONVERTER	D/A CONVERTER	D/A CONVERTER
Enter bit code	BINARY	BINARY	BINARY
Input format	PARALLEL, WORD	PARALLEL, WORD	PARALLEL, WORD
JESD-30 code	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28
JESD-609 code	e3	e3	e3
length	9.89 mm	9.89 mm	9.89 mm
Maximum linear error (EL)	0.1953%	0.1953%	0.1953%
Humidity sensitivity level	1	1	1
Number of digits	10	10	10
Number of functions	1	1	1
Number of terminals	28	28	28
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SSOP	SSOP	SSOP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260	260	260
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.73 mm	1.73 mm	1.73 mm
Nominal settling time (tstl)	0.025 µs	0.025 µs	0.025 µs
Nominal supply voltage	3 V	3 V	3 V
surface mount	YES	YES	YES
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.635 mm	0.635 mm	0.635 mm
Terminal location	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
width	3.9 mm	3.9 mm	3.9 mm
Factory Lead Time	-	6 weeks	6 weeks
