Features
●
●
●
●
●
●
●
●
4:1 Wide Input Voltage Range
20 Watts Output Power
1.6kVDC Isolation
Fixed Operating Frequency
Six-Sided Continuous Shield
UL 1950 Component Recognized
Standard 50.8 x40.6x10.2mm Package
Efficiency to 84%
POWERLINE
DC/DC-Converter
RP20-
S_DEW
Series
20 Watt
Single
&
Dual
Output
Selection Guide
24V and 48V Input Types
Part Number
Input
Range
VDC
9-36
9-36
9-36
9-36
18-75
18-75
18-75
18-75
9-36
9-36
9-36
18-75
18-75
18-75
Output
Voltage
VDC
3.3
5
12
15
3.3
5
12
15
±5
±12
±15
±5
±12
±15
Output
Current
mA
4000
4000
1670
1330
4000
4000
1670
1330
±2000
±833
±666
±2000
±833
±666
Input
(4)
Current
mA
764
1111
1082
1082
377
548
541
541
1111
1082
1068
556
527
521
Efficiency
(5)
%
76
79
81
81
77
80
81
81
79
81
82
79
83
84
Capacitive
(6)
Load max.
µF
13000
6800
2200
755
13000
6800
2200
755
±3400
±680
±450
±3400
±680
±450
RP20-243.3SEW
RP20-2405SEW
RP20-2412SEW
RP20-2415SEW
RP20-483.3SEW
RP20-4805SEW
RP20-4812SEW
RP20-4815SEW
RP20-2405DEW
RP20-2412DEW
RP20-2415DEW
RP20-4805DEW
RP20-4812DEW
RP20-4815DEW
Description
The EW-Series of DC/DC Converters are fully certified to EN 60950: 2000.
This makes them ideal for all
Telecom and safety applications where approved isolation is required.
232
April-2005
www.recom-international.com
POWERLINE
DC/DC-Converter
RP20-S_DEW
Series
RP20-2412SEW With Heat Sink
125
100
Derating-Graph
(Ambient Temperature)
RP20-2412SEW
125
100
75
Output Power (%)
50
25
50 60 70 80 90 100
Ambient Temperature Range (°C)
56°C
0
-40 -25 -10 0
Output Power (%)
Natural Convection
75
50
25
Natural Convection
0
-40 -25 -10 0
50 60 70
80 90 100
65°C
Ambient Temperature Range (°C)
RP20-2412DEW
125
100
75
Output Power (%)
50
25
50 60 70 80 90 100
Ambient Temperature Range (°C)
64°C
0
-40 -25 -10 0
RP20-2412DEW With Heat Sink
125
100
Output Power (%)
Natural Convection
75
50
25
Natural Convection
0
-40 -25 -10 0
50 60 70
80 90 100
71°C
Ambient Temperature Range (°C)
Derating graphes are valid only for the shown part numbers. If you need detailed derating-information about a
part-number not shown here please contact our technical customer service at info@recom-development.at
Specifications
(typical at nominal input and 25°C unless otherwise noted)
Input Voltage Range
Input Filter
Input Surge Voltage (100 ms max.)
Input Reflected Ripple (nominal Vin and full load)
Start Up Time (nominal Vin and constant resistor load)
Remote ON/OFF (see note 7)
Remote OFF input current
Output Power
Output Voltage Accuracy (full Load and nominal Vin)
Voltage Adjustability
Line Regulation (LL-HL at full load)
DC-DC ON
DC-DC OFF
Nominal input
Single & Dual
Auxiliary
Single (W)
Dual (W)
Auxiliary
24V nominal input
48V nominal input
24V Input
48V Input
9-36VDC
18-75VDC
Pi Type
50VDC
100VDC
25mAp-p
20ms typ.
Open or 3.5V < Vr < 12V
Short or 0V < Vr < 1.2V
20mA
20W max.
±2%
±5%
±10%
±0.2%
±0.5%
±5%
10% of FL
continued on next page
www.recom-international.com
April-2005
233
Minimum Load (see Note 1)
POWERLINE
DC/DC-Converter
Specifications
(typical at nominal input and 25°C unless otherwise noted)
Line Regulation (LL-HL at full load)
Single (W)
Dual (W)
Auxiliary
Single
Dual
Auxiliary
Dual
Auxiliary
Single
Dual
Auxiliary
RP20-S_DEW
Series
±0.2%
±0.5%
±5%
±0.5%
±3%
±5%
±5%
±5%
75mVp-p
100mVp-p
1% of Vout
±0.02%/°C, max.
3.3V
5V
12V
15V
500µS
3.9V
6.2V
15V
18V
Hiccup, automatic recovery
see „Selection Guide“ table
1.600VDC min.
10
9
Ω
min.
300pF max.
300kHz typ.
EN60950
-40°C to +85°C(with derating)
+100°C
Natural convection
Natural convection with Heat Sink
-55°C to +105°C
10°C/Watt
8.24°C/Watt
MIL-STD-810D
10-55Hz, 2G, 30 Min. along X, Y and Z
5% to 95% RH
Nickel-Coated copper
Non-conductive black plastic
Epoxy (UL94-V0)
EN55022
EN55022
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
Level A
Level A
Perf. Criteria 2
Perf. Criteria 2
Perf. Criteria 2
Perf. Criteria 2
Perf. Criteria 2
48g
50.8 x 40.6 x 10.2mm
1.928 x 10
6
Hours
Load Regulation (25% to 100% FL)
Cross Regulation (Note 9)
Ripple and Noise (20MHz bandwith)
Temperature Coefficient
Transient Response (25% load step change)
Over Voltage Protection
Zener diode clamp (only single)
Short Circuit Protection
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Operating Frequency
Approved to Safety Standards
Operating Temperature Range
Maximum Case Temperature
Storage Temperature Range
Thermal Impedance
Thermal Shock
Vibration
Relative Humidity
Case Material
Base Material
Potting Material
Conducted Emissions
Radiated Emissions
ESD
Radiated Immunity
Fast Transient
Surge
Conducted Immunity
Weight
Dimensions
MTBF (see note 2)
234
April-2005
www.recom-international.com
POWERLINE
DC/DC-Converter
Notes :
RP20-S_DEW
Series
1. The RP20 series requires a minimum of 10% loading on the output to maintain specified regulation. Operation under
no-load condition will not damage these devices, however they may not meet all listed specification.
2. BELLCORE TR-NWT-000332. Case l: 50% Stress, Temperature at 40°C (Ground fixed and controlled environment).
3. Simulated source impedance of 12uH. 12uH inductor in series with +Vin.
4. Maximum value at nominal input voltage and full load of standard type.
5. Typical value at nominal input voltage and full load.
6. Test by minimum Vin and constant resistor load.
7. The ON/OFF control voltage is reference to negative input.
8. Heat sink is optional and P/N: 7G-0011A. Operation temperature range please see curve.
9. Cross regulation:
Dual output—Asymmetrical load 25% to 100% full load
Triple output – 3.3V / 5V 100% load and one of auxiliary 100% load, other auxiliary load change from 25% to 100% load
10.See application notes for EMI-filtering.
Package Style and Pinning (mm)
3rd angle
projection
50.10
10.20
dia.
1.0
5.6
40.60
Pin Connections
45.70
5
17.80
Bottom View
5.10
15.20
1
2
10.20
6
12.70
Pin #
1
2
4
5
6
7
8
Single
+Vin
-Vin
CTRL
No Pin
+Vout
-Vout
Trim
Dual
+Vin
-Vin
CTRL
+Vout
Com
-Vout
Trim
Pin Pitch Tolerance ±0.35 mm
7
4
10.20
8
17.80
External Output Trimming
Output can be externally trimmed by using the method
shown below.
( ) for dual output trim
7(7)
Trim Up
R
U
8(8)
Trim Down
R
D
8(8)
6(5)
www.recom-international.com
April-2005
235
