+105°C
General Purpose High
Capacitance Miniature
Axial Lead, Aluminum
Electrolytic Capacitors
Features-
•
•
+105°C, Long Life, High Performance
High CV Per Case Size
General Specifications-
Operating Temperature:
-40 to +105°C
Voltage Range:
6.3 – 450 VDC
Capacitance Range:
1µF to 15,000µF
Capacitance Tolerance:
±20% (Std.)
Case Size Range:
6.3 X 13.0mm – 18.0 X 40.0mm
Termination:
20 ga. Axial leads with lead forming
available.
Life Validation Test: 4,000hrs @ +105°C
Δ
CAP
≤
20% From initial measurement.
Δ
ESR
≤
1.5X Initial specified limit.
Δ
DCL
≤
Initial specified limit.
Shelf Test: 1,000hrs @ +105°C
Δ
CAP
≤
20% From initial measurement.
Δ
ESR
≤
1.5X Initial specified limit.
Δ
DCL
≤
2X Initial specified limit.
DC Leakage Current:
For: 3 – 20VDC
For: 25 – 250VDC
Where:
I is in µA
C is in µF
V is in Volts
Ripple Current Multipliers:
Temperature:
Ambient Temp.
Multiplier
Frequency (Hz):
VDC
3-50
51-450
50-60
0.9
0.8
100-120
1.0
1.0
+105°C
0.5
I
=
0.1 CV
+
2
I
=
0.2 CV
+
2
+85°C
1.0
±65°C
2.0
300-400
1.1
1.2
1k-100k
1.4
1.6
PART NUMBER BREAK-DOWN:
30HC 826 M 003 BA 2 A
PACKAGING:
A = BULK PACK (STD.)
T = TAPE AND REEL. (NOT AVAILABLE IN
G
&
L
DIAMETERS)
CASE STYLE:
2 = BLACK P.V.C. SLEEVE (STD.)
3 = MYLAR SLEEVE
5 = BLACK P.V.C. SLEEVE
W
/ EPOXY END SEAL
(REQUIRED FOR EXPOSURE TO HALOGENATED CLEANING SOLVENTS.)
6 = MYLAR SLEEVE
W
/ EPOXY END SEAL
CASE CODE:
(SEE TABLE 1.)
DC VOLTAGE RATING:
EXPRESSED IN VOLTS. THE LETTER “R” SIGNIFIES A DECIMAL POINT.
(ie. 6R3 = 6.3 VOLTS.)
CAPACITANCE TOLERANCE:
M = ±20%
G = -10%/+75%
H = -10%/+100%
CAPACITANCE:
EXPRESSED IN PICOFARADS. THE FIRST TWO DIGITS ARE SIGNIFICANT
FIGURES, THE THIRD IS THE NUMBER OF ZEROS.
BMI TYPE #:
IDENTIFIES THE BASIC CAPACITOR DESIGN.
Axial-Leaded Capacitor Dimensions
CASE STYLES 2 & 3
CASE STYLES 5 & 6
Table 1. Case Dimensions mm(in.)
CASE
CODE
BA
BB
CB
CC
DB
DC
DD
DF
DH
EF
EH
FF
FH
FK
GH
GK
LR
LS
NOMINAL
‘D’
‘L’
6.3 (0.248)
13.0 (0.512)
6.3 (0.248)
17.5 (0.689)
8.0 (0.315)
8.0 (0.315)
9.5
9.5
9.5
9.5
9.5
(0.374)
(0.374)
(0.374)
(0.374)
(0.374)
17.5 (0.689)
20.5 (0.807)
17.5
20.5
24.0
32.0
38.0
(0.689)
(0.807)
(0.945)
(1.260)
(1.496)
STYLES 2& 3
‘D’ MAX.
‘L’ MAX.
7.0 (0.276)
14.4 (0.567)
7.0 (0.276)
19.2 (0.756)
8.6 (0.339)
8.6 (0.339)
10.2
10.2
10.2
10.2
10.2
(0.402)
(0.402)
(0.402)
(0.402)
(0.402)
19.2 (0.756)
22.3 (0.878)
19.2
22.3
25.5
33.5
39.8
(0.756)
(0.878)
(1.004)
(1.319)
(1.567)
STYLES 5 & 6 (w/EPOXY)
‘D’ MAX.
‘L’ MAX.
7.0 (0.276)
15.9 (0.626)
7.0 (0.276)
20.7 (0.815)
8.6 (0.339)
8.6 (0.339)
10.2
10.2
10.2
10.2
10.2
(0.402)
(0.402)
(0.402)
(0.402)
(0.402)
20.7 (0.815)
23.8 (0.937)
20.7
23.8
27.0
35.0
41.3
(0.815)
(0.937)
(1.063)
(1.378)
(1.626)
WIRE GAUGE
‘W’
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
No. 20 AWG (0.032)
11.0 (0.433)
11.0 (0.433)
12.5 (0.492)
12.5 (0.492)
12.5 (0.492)
16.0 (0.630)
16.0 (0.630)
18.0 (0.709)
18.0 (0.709)
32.0 (1.260)
38.0 (1.496)
32.0 (1.260)
38.0 (1.496)
44.5 (1.752)
38.0 (1.496)
44.5 (1.752)
36.0 (1.417)
40.0 (1.575)
11.8 (0.465)
11.8 (0.465)
13.1 (0.516)
13.1 (0.516)
13.1 (0.516)
16.6 (0.654)
16.6 (0.654)
18.7 (0.736)
18.7 (0.736)
33.5 (1.319)
39.8 (1.567)
33.5 (1.319)
39.8 (1.567)
46.5 (1.831)
39.8 (1.567)
46.5 (1.831)
37.8 (1.488)
42.5 (1.673)
11.8 (0.465)
11.8 (0.465)
13.1 (0.516)
13.1 (0.516)
13.1 (0.516)
16.6 (0.654)
16.6 (0.654)
18.7 (0.736)
18.7 (0.736)
35.0 (1.378)
41.3 (1.626)
35.0 (1.378)
41.3 (1.626)
48.0 (1.890)
41.3 (1.626)
48.0 (1.890)
39.0 (1.535)
43.0 (1.693)
STANDARD RATINGS FOR TYPE 30HC
Rated
Nominal Case Size
Capacitance
Catalog Number
DxL
(µF)
(mm)
6.3 VOLTS DC WORKING; 8 VOLTS DC SURGE
150
270
390
560
1,000
1,500
2,200
2,700
4,700
5,600
6,800
10,000
12,000
15,000
220
330
470
820
1,200
1,800
2,200
2,700
3,300
3,900
5,600
6,800
10,000
12,000
120
220
330
470
680
1,000
1,500
1,800
2,700
3,300
3,900
4,700
5,600
8,200
10,000
82
180
220
390
680
30HC157M6R3BA2A
30HC277M6R3BB2A
30HC397M6R3CB2A
30HC567M6R3CC2A
30HC108M6R3DC2A
30HC158M6R3DD2A
30HC228M6R3DF2A
30HC278M6R3DH2A
30HC478M6R3EH2A
30HC568M6R3FH2A
30HC688M6R3FK2A
30HC109M6R3GH2A
30HC129M6R3GK2A
30HC159M6R3LS2A
30HC227M010BB2A
30HC337M010CB2A
30HC477M010CC2A
30HC827M010DC2A
30HC128M010DD2A
30HC188M010DF2A
30HC228M010DH2A
30HC278M010EF2A
30HC338M010EH2A
30HC398M010FH2A
30HC568M010FK2A
30HC688M010GH2A
30HC109M010GK2A
30HC129M010LS2A
30HC127M012BA2A
30HC227M012BB2A
30HC337M012CB2A
30HC477M012CC2A
30HC687M012DC2A
30HC108M012DD2A
30HC158M012DF2A
30HC188M012DH2A
30HC278M012EF2A
30HC338M012EH2A
30HC398M012FH2A
30HC478M012FK2A
30HC568M012GH2A
30HC828M012GK2A
30HC109M012LS2A
30HC826M016BA2A
30HC187M016BB2A
30HC227M016CB2A
30HC397M016CC2A
30HC687M016DC2A
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
Maximum ESR
+25°C 120Hz
(Ω)
2.880
1.600
1.000
0.770
0.600
0.440
0.350
0.240
0.140
0.130
0.120
0.090
0.080
0.070
2.000
1.290
1.000
0.580
0.450
0.270
0.220
0.180
0.150
0.120
0.100
0.090
0.080
0.080
3.600
1.900
1.650
1.000
0.680
0.480
0.320
0.260
0.160
0.130
0.120
0.100
0.098
0.090
0.080
3.900
2.600
1.900
1.270
0.560
Maximum Ripple
Current +85°C 120Hz
(A
rms
)
0.126
0.191
0.245
0.333
0.474
0.602
0.827
0.998
1.423
1.650
1.942
2.399
2.837
3.118
0.186
0.248
0.327
0.466
0.584
0.822
1.029
1.142
1.374
1.589
2.013
2.180
2.898
2.919
0.123
0.199
0.245
0.328
0.456
0.572
0.798
0.958
1.170
1.451
1.645
1.945
2.254
2.696
2.982
0.119
0.174
0.229
0.305
0.462
10 VOLTS DC WORKING; 12 VOLTS DC SURGE
12 VOLTS DC WORKING; 15 VOLTS DC SURGE
16 VOLTS DC WORKING; 20 VOLTS DC SURGE
STANDARD RATINGS FOR TYPE 30HC
Rated
Nominal Case Size Maximum ESR
+25°C 120Hz
Capacitance
Catalog Number
DxL
(µF)
(mm)
(Ω)
16 VOLTS DC WORKING; 20 VOLTS DC SURGE (CONTINUED)
820
1,200
1,800
2,200
3,300
3,900
4,700
6,800
8,200
82
150
220
330
560
680
1,000
1,500
1,800
2,200
2,700
3,300
3,900
5,600
6,800
68
120
150
220
330
470
680
1,000
1,200
1,500
1,800
2,200
2,700
3,900
4,700
56
82
100
150
270
330
560
680
820
30HC827M016DD2A
30HC128M016DF2A
30HC188M016DH2A
30HC228M016EF2A
30HC338M016EH2A
30HC398M016FK2A
30HC478M016GH2A
30HC688M016GK2A
30HC828M016LS2A
30HC826M020BA2A
30HC157M020BB2A
30HC227M020CB2A
30HC337M020CC2A
30HC567M020DC2A
30HC687M020DD2A
30HC108M020DF2A
30HC158M020DH2A
30HC188M020EF2A
30HC228M020EH2A
30HC278M020FH2A
30HC338M020FK2A
30HC398M020GH2A
30HC568M020GK2A
30HC688M020LS2A
30HC686M025BA2A
30HC127M025BB2A
30HC157M025CB2A
30HC227M025CC2A
30HC337M025DC2A
30HC477M025DD2A
30HC687M025DF2A
30HC108M025DH2A
30HC128M025EF2A
30HC158M025EH2A
30HC188M025FH2A
30HC228M025FK2A
30HC278M025GH2A
30HC398M025GK2A
30HC478M025LS2A
30HC566M035BA2A
30HC826M035BB2A
30HC107M035CB2A
30HC157M035CC2A
30HC277M035DC2A
30HC337M035DD2A
30HC567M035DF2A
30HC687M035DH2A
30HC827M035EF2A
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
0.510
0.350
0.240
0.190
0.140
0.114
0.108
0.080
0.080
3.700
2.600
1.220
0.980
0.576
0.490
0.323
0.214
0.190
0.170
0.150
0.180
0.140
0.080
0.070
4.150
2.350
1.880
1.280
0.860
0.600
0.415
0.282
0.235
0.220
0.190
0.190
0.160
0.130
0.130
4.900
3.300
2.700
1.800
1.000
0.820
0.480
0.397
0.330
Maximum Ripple
Current +85°C 120Hz
(A
rms
)
0.554
0.762
0.972
1.109
1.422
1.820
2.125
2.599
2.768
0.118
0.172
0.237
0.307
0.440
0.526
0.737
0.960
1.084
1.256
1.485
1.657
2.069
2.469
2.732
0.119
0.181
0.225
0.299
0.419
0.516
0.700
0.922
0.835
1.161
1.365
1.612
1.713
1.934
2.630
0.092
0.140
0.173
0.233
0.334
0.410
0.584
0.727
0.815
20 VOLTS DC WORKING; 25 VOLTS DC SURGE
25 VOLTS DC WORKING; 35 VOLTS DC SURGE
35 VOLTS DC WORKING; 45 VOLTS DC SURGE
STANDARD RATINGS FOR TYPE 30HC
Rated
Nominal Case Size Maximum ESR
+25°C 120Hz
Capacitance
Catalog Number
DxL
(µF)
(mm)
(Ω)
35 VOLTS DC WORKING; 45 VOLTS DC SURGE (CONTINUED)
1,200
1,500
1,800
2,700
3,300
3,900
39
68
100
150
220
330
470
680
820
1,200
1,500
2,200
2,700
3,300
33
56
68
100
150
220
330
470
560
820
1,000
1,200
1,500
1,800
2,200
22
39
56
82
120
180
270
390
470
560
680
1,000
1,200
30HC128M035EH2A
30HC158M035FH2A
30HC188M035FK2A
30HC278M035GH2A
30HC338M035GK2A
30HC398M035LS2A
30HC396M040BA2A
30HC686M040BB2A
30HC107M040CB2A
30HC157M040CC2A
30HC227M040DC2A
30H337CM040DD2A
30HC477M040DF2A
30HC687M040DH2A
30HC827M040EF2A
30HC128M040EH2A
30HC158M040FK2A
30HC228M040GH2A
30HC278M040GK2A
30HC338M040LS2A
30HC336M050BA2A
30HC566M050BB2A
30HC686M050CB2A
30HC107M050CC2A
30HC157M050DC2A
30HC227M050DD2A
30HC337M050DF2A
30HC477M050DH2A
30HC567M050EF2A
30HC827M050EH2A
30HC108M050FH2A
30HC128M050FK2A
30HC158M050GH2A
30HC188M050GK2A
30HC228M050LS2A
30HC226M063BA2A
30HC396M063BB2A
30HC566M063CB2A
30HC826M063CC2A
30HC127M063DC2A
30HC187M063DD2A
30HC277M063DF2A
30HC397M063DH2A
30HC477M063EF2A
30HC567M063EH2A
30HC687M063FH2A
30HC108M063FK2A
30HC128M063GH2A
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
16.0 x 44.5
18.0 x 40.0
6.3 x 13.0
6.3 x 17.5
8.0 x 17.5
8.0 x 20.5
9.5 x 20.5
9.5 x 24.0
9.5 x 32.0
9.5 x 38.0
11.0 x 32.0
11.0 x 38.0
12.5 x 38.0
12.5 x 44.5
16.0 x 38.0
0.225
0.180
0.180
0.170
0.130
0.120
6.000
4.050
3.200
2.050
1.200
1.140
0.830
0.470
0.360
0.230
0.210
0.170
0.140
0.120
7.880
4.650
3.460
2.600
1.750
1.250
1.100
1.100
0.460
0.317
0.260
0.220
0.180
0.180
0.140
8.890
6.400
4.400
2.920
2.620
1.340
0.880
0.630
0.630
0.420
0.350
0.240
0.200
Maximum Ripple
Current +85°C 120Hz
(A
rms
)
1.056
1.246
1.448
1.658
2.031
2.247
0.086
0.138
0.171
0.233
0.320
0.377
0.513
0.714
0.815
1.056
1.341
1.652
2.108
2.094
0.085
0.129
0.162
0.217
0.285
0.358
0.501
0.650
0.727
0.947
1.128
1.313
1.542
1.770
2.006
0.079
0.114
0.150
0.199
0.268
0.352
0.492
0.642
0.705
0.836
0.991
1.282
1.475
40 VOLTS DC WORKING; 50 VOLTS DC SURGE
50 VOLTS DC WORKING; 65 VOLTS DC SURGE
63 VOLTS DC WORKING; 75 VOLTS DC SURGE
京公网安备 11010802033920号
EEWORLD
