FMVTCXS2
SERIES
3.0, 2.5, 1.8 Vdc VCTCXO
Ultra-Miniature, Low Profile
Low Power Consumption
3.0, 2.5, 1.8 Supply Voltages
Clipped Sinewave
CERAMIC SMD 3.2x2.5
SPECIFICATIONS
Issue 1 - 06152012
Parameter
Frequency Range
Frequency Accuracy at +25ºC
Frequency Stability vs. Temp
Frequency Stability vs. Input V. (±5% change)
Frequency Stability vs. Load (±10% change)
Frequency Stability vs. Aging (first year)
at 3.0 Volts
Control Voltage Range
at 2.5 Volts
at 1.8 Volts
Pulling Range
VC Impedance
Storage Temperature
Supply Voltage (Vdd)
10 MHz to 26 MHz
Supply Current (Icc)
26 MHz to 52 MHz
Symmetry (Duty Cycle)
Clipped Sine Wave
Output Level
Output Load
Rise and Fall Time
Start-up Time
100 Hz
Phase Noise (typical)
1kHz
10kHz
All specifications subject to change without notice.
Clipped Sinewave Specification
10 - 52.0 MHz
±2.0 ppm
See Table Below
±0.2 ppm max
±0.2 ppm max
±1.0 ppm max
0.5 min to 2.5V max
0.4 min to 2.4V max
0.3 min to 1.5V max
±5 ppm
500KΩ
-55 to +125°C
+3.0V ±5%, +2.5V ±5%, +1.8V ±5%
2.0 mA max
2.5 mA max
40/60% Std.
0.8 Vp-p
10KΩ//10pF
10 ns max. (5ns typical)
2 mSec
-115 dBc/Hz
-135 dBc/Hz
-148 dBc/Hz
CERAMIC SMD
STANDARD MARKING
FREQ STABILITY vs. TEMP AVAILABLITY TABLE
Frequency Stability
0.5 1.0 1.5 2.0
Temp. Range FM Code 005 010 015 020
0 to 50°C
*
*
*
*
J
-10 to 60°C
*
*
*
*
E
0 to 70°C
*
*
*
*
A
-20 to 70°C
*
*
*
*
B
-30 to 60°C
*
*
*
*
F
-30 to 75°C
*
S
*
*
*
-40 to 85°C
*
C
(±ppm)
2.5 3.0
025 030
*
*
*
*
*
*
*
*
*
*
*
*
*
*
FMI XX.XXX
XX.XXX FREQUENCY in MHz
PIN FUNCTION TABLE
Pin
1
2
3
4
Function
Voltage Control
Ground/Case
Output
Supply Voltage (Vcc)
Dimensions: millimeters
* Denotes Availability
Standard Specifications for product indicated in
color
PART DESCRIPTION SYSTEM
FMVTC X S2
Product Family
Choose Code
3 = 3.0 Vdc VCTCXO
2 = 2.5 Vdc VCTCXO
1 = 1.8 Vdc VCTCXO
Ceramic SMD
MARKING: See Page 52, Format A
SW - XX.XXXXXXM - CM
Temp. Range
A 0 to 70 °C
B -20 to 70 °C
C -40 to 85 °C
E -10 to 60 °C
F -30 to 60 °C
J 0 to 50 °C
S -30 to 75 °C
X Custom
Frequency (MHz)
Options
TR - Tape and Reel
PD - Parameter Data
CM - Custom Mark
BLANK - None Req’d.
050
J
Frequency Stability
Choose FM Code from
Frequency Stability Table
(Code 020=2.0 ppm)
Specification Options
SW - Clipped Sinewave
1-800-800-XTAL
[9825]
www.fmi-inc.com
40
Test/Measurement
