TMH
high reliability tantalum chip capacitor
features
•
Excellent heat resistance:
85°C 85/RH storage for 500 hours
65°C 95/RH load for 1000 hours
•
Epoxy molded body, UL94V0 flammability
•
EIA-US compatible sizes
•
Suitable for automotive applications
•
Failure rate: 0.5%/1000 hours
•
Marking: Black body color with white marking
dimensions and construction
Case Size
(Inch Size Code)
capacitance ranges
and case sizes
d
Rated Voltage (VDC)
85°C Surge Voltage (VDC)
Derated Voltage (VDC)
125°C
Surge Voltage (VDC)
Capacitance (µF)
Code
0.1
104
0.15
154
0.22
224
0.33
334
0.47
474
0.68
684
1
105
1.5
155
2.2
225
3.3
335
4.7
475
6.8
685
10
15
22
106
156
226
336
476
686
107
C
C
E
E
4
5
2.5
3.2
0G
7
8
4
5
0J
10
13
6.3
8
1A
16
20
10
13
1C
20
26
13
16
1D
25
32
16
20
1E
35
45
22
28
1V
A
A
A
A
A,B
B
B
B,C
C
C
C,E
E
E
L
Dimensions
inches
(mm)
W1
W2
t
A
(3216)
B
(3528)
C
(6032)
E
(EIA-D)
.126±.008 .063±.008 .047±.008 .063±.008 .028±.012
(3.2±0.2)
(1.6±0.2)
(1.2±0.2)
(1.6±0.2) (0.7±0.3)
.138±.008 .110±.008 .087±.008 .075±.008 .031±.012
(3.5±0.2)
(2.8±0.2)
(2.2±0.2)
(1.9±0.2) (0.8±0.3)
.236±.012 .126±.008 .087±.008 .095±.008 .051±.012
(6.0±0.3)
(3.2±0.2)
(2.5±0.2)
(1.3±0.3)
(2.2±0.2)
.287±.012 .169±.012 .095±.008 .110±.008 .051±.012
(7.3±0.3)
(4.3±0.3)
(2.4±0.2)
(2.8±0.2) (1.3±0.3)
L
W1
t
A
A
B
B
A
A
B
B
A
A
B
B
C
A
A
B
B
C
C
E
E
A
A
B
B
C
C
E
E
A
A
B
B
C
C
E
E
W2
Side
d
Bottom
d
C
C
E
E
C
E
E
End
33
47
68
100
ordering information
New Part #
TMH
Type
1E
Voltage
Code
0G: 4V
0J: 7V
1A: 10V
1C: 16V
1D: 20V
1E: 25V
1V: 35V
C
Case Size
A: 3216
B: 3528
C: 6032
E: EIA-D
T
Termination
Material
T: Sn
L: SnPb
TE
Packaging
TE: 7" embossed
plastic
475
Nominal
Capacitance
Reference
capacitance
ranges and
case sizes
chart
M
Tolerance
K: ±10%
M:±20%
R
Polarity
Orientation
For further information on packaging,
please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
10/05/04
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
