IllumInatIon
luXeon coB core range
Uniform, high efficacy and easy to design array
LUXEON CoB represents a new breakthrough for arrays. The efficacies
will be >160 lm/W for 70CRI and 80CRI products. Due to its small Light
Emitting Surface (LES) and industry-leading thermal resistance, LUXEON
CoB is easy to work with, enabling simplified and less expensive luminaire
designs. LUXEON CoBs are hot-tested at 85°C—real world operating
conditions—which means additional testing can be minimized. LUXEON
CoB LEDs are available in 3-step MacAdam ellipse, ensuring uniform
optical performance in a wide range of applications.
Features and BeneFIts
Highest flux densities with industry’s smallest LES
3-step MacAdam ellipse color definition:
Freedom from Binning
for color
consistency from luminaire to luminaire
Up to 4x lower thermal resistance than competition, enabling smaller
heatsinks and higher lumens
Supported by a comprehensive optical, mechanical and electrical ecosystem
PrImary aPPlIcatIons
Spotlights
Track Lights
Downlights
High Bay
Low Bay
Floodlights
More…
18
DS162 LUXEON CoB Core Range Product Datasheet ©2020 Lumileds Holding B.V. All rights reserved.
No. E352519
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Electrical and Thermal Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Spectral Power Distribution Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Forward Current Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Radiation Pattern Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Color Bin Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Packaging and Labeling Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Inner Box.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Outer Box
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
DS162 LUXEON CoB Core Range Product Datasheet 20200726 ©2020 Lumileds Holding B.V. All rights reserved.
i
General Product Information
Product Test Conditions
LUXEON CoB Core Range LEDs are tested and binned with a DC drive current specified below at a junction temperature,
T
j
, of 85°C:
200mA
200mA
300mA
450mA
600mA
900mA
1200mA
1600mA
1200mA
2100mA
2250mA
–
–
–
–
–
–
–
–
–
–
–
LUXEON CoB 1202s
LUXEON CoB 1202
LUXEON CoB 1203
LUXEON CoB 1204
LUXEON CoB 1205
LUXEON CoB 1208
LUXEON CoB 1211
LUXEON CoB 1216
LUXEON CoB 1812
LUXEON CoB 1321
LUXEON CoB 1825
Part Number Nomenclature
Part numbers for LUXEON CoB Core Range follow the convention below:
L 2 C 5 –
A A B B C C C C D E E F F
Where:
A A
B B
C C C C
D
E E
F F
–
–
–
–
–
–
designates nominal CCT (22=2200K, 27=2700K, 30=3000K, 35=3500K, 40=4000K, 50=5000K,
56=5600K, 57=5700K, 65=6500K)
designates minimum CRI (60=60CRI, 70=70CRI, 80=80CRI, 90=90CRI, 95=95CRI)
designates product configuration (example: 1202, 1203, 1204, 1205, 1208, 1211, 1216, 1812, 1321, 1825)
designates options for product specification
designates light emitting surface (LES) size (06=6mm, 09=9mm, 13=13mm, 15=15mm,
19=19mm, 23=23mm, 29=29mm, 32=32mm)
designates options for product specification
Therefore, the following part number is used for a LUXEON CoB 1203, Gen 4, 3000K 80CRI, with a 9mm LES:
L 2 C 5 –
3 0 8 0 1 2 0 3 F 0 9
0 0
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the
long-term performance of this product.
DS162 LUXEON CoB Core Range Product Datasheet 20200726 ©2020 Lumileds Holding B.V. All rights reserved.
2
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON CoB
Core Range is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment,
namely the RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the
following restricted materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or
polybrominated diphenyl ethers (PBDE).
Performance Characteristics
Product Selection Guide
Table 1. Product performance of LUXEON CoB Core Range at specified test current, T
j
=85ºC .
Product
nomInal
cct
2200K
2700K
3000K
3500K
LUXEON
CoB
1202s
4000K
5000K
2200K
[5]
2700K
3000K
3500K
4000K
3000K
3500K
4000K
5000K
5700K
2200K
2700K
LUXEON
CoB
1202
3000K
3500K
4000K
5000K
2200K
[5]
2700K
3000K
3500K
4000K
mInImum
crI
[1, 2, 3]
80
80
80
80
80
80
90
90
90
90
90
70
70
70
70
70
80
80
80
80
80
80
90
90
90
90
90
lumInous FluX
[1]
(lm)
mInImum
675
797
837
854
863
863
589
662
689
725
742
923
923
968
968
942
703
830
876
893
899
899
625
690
729
752
772
tyPIcal
750
886
930
949
959
959
654
736
766
805
824
1026
1026
1075
1075
1047
781
922
973
992
999
999
694
766
810
836
858
tyPIcal
lumInous
eFFIcacy (lm/W)
109
128
135
138
139
139
95
107
111
117
119
149
149
156
156
152
113
134
141
144
145
145
101
111
117
121
124
test
current
(ma)
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
les
[4]
(mm)
6
6
6
6
6
6
6
6
6
6
6
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
Part numBer
L2C5-22801202E0600
L2C5-27801202E0600
L2C5-30801202E0600
L2C5-35801202E0600
L2C5-40801202E0600
L2C5-50801202E0600
L2C5-22901202E0600
L2C5-27901202E0600
L2C5-30901202E0600
L2C5-35901202E0600
L2C5-40901202E0600
L2C5-30701202E0900
L2C5-35701202E0900
L2C5-40701202E0900
L2C5-50701202E0900
L2C5-57701202E0900
L2C5-22801202E0900
L2C5-27801202E0900
L2C5-30801202E0900
L2C5-35801202E0900
L2C5-40801202E0900
L2C5-50801202E0900
L2C5-22901202E0900
L2C5-27901202E0900
L2C5-30901202E0900
L2C5-35901202E0900
L2C5-40901202E0900
Table 1 continued on next page.
1.
Lumileds maintains a tolerance of ±2 on CRI and ±6.5% on luminous flux measurements.
2.
Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is not guaranteed.
3. R9 value of 90CRI products is >50.
4. Light Emitting Surface (LES) is the inner diameter (phosphor area) inside the dam.
5. AtmoSphere Technology creates the ideal ambiance for restaurants and other hospitality venues.
DS162 LUXEON CoB Core Range Product Datasheet 20200726 ©2020 Lumileds Holding B.V. All rights reserved.
3
Table 1. Product performance of LUXEON CoB Core Range at specified test current, T
j
=85ºC (continued) .
Product
nomInal
cct
3000K
3500K
4000K
5000K
5700K
6500K
2200K
2700K
mInImum
crI
[1, 2, 3]
70
70
70
70
70
70
70
70
80
80
80
80
80
80
80
80
80
80
80
80
90
90
90
90
90
90
90
90
90
95
95
95
lumInous FluX
[1]
(lm)
mInImum
1475
1379
1379
1569
1466
1466
1428
1391
1066
1359
1258
1392
1289
1420
1315
1472
1363
1472
1363
1359
929
1170
1045
1210
1080
1258
1140
1251
1170
999
1053
1194
tyPIcal
1639
1532
1532
1743
1629
1629
1587
1546
1184
1510
1398
1547
1432
1578
1461
1635
1514
1635
1514
1510
1032
1300
1161
1344
1200
1398
1267
1390
1301
1110
1170
1327
tyPIcal
lumInous
eFFIcacy (lm/W)
158
148
148
168
157
157
153
149
114
146
135
149
138
152
141
158
146
158
146
146
100
125
112
130
116
134
122
134
126
107
113
128
test
current
(ma)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
les
[4]
(mm)
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
Part numBer
L2C5-30701203F0900
L2C5-30701203E0900
L2C5-35701203E0900
L2C5-40701203F0900
L2C5-40701203E0900
L2C5-50701203E0900
L2C5-57701203E0900
L2C5-65701203E0900
L2C5-22801203E0900
L2C5-27801203F0900
L2C5-27801203E0900
L2C5-30801203F0900
L2C5-30801203E0900
L2C5-35801203F0900
L2C5-35801203E0900
L2C5-40801203F0900
L2C5-40801203E0900
L2C5-50801203F0900
L2C5-50801203E0900
L2C5-57801203E0900
L2C5-22901203E0900
L2C5-27901203F0900
L2C5-27901203E0900
L2C5-30901203F0900
L2C5-30901203E0900
L2C5-35901203F0900
L2C5-35901203E0900
L2C5-40901203F0900
L2C5-40901203E0900
L2C5-27951203F0900
L2C5-30951203F0900
L2C5-40951203F0900
3000K
3500K
LUXEON
CoB
1203
4000K
5000K
5700K
2200K
[5]
2700K
3000K
3500K
4000K
2700K
3000K
4000K
Notes:
1.
Lumileds maintains a tolerance of ±2 on CRI and ±6.5% on luminous flux measurements.
2.
Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is not guaranteed.
3. R9 value of 90CRI products is >50.
4. Light Emitting Surface (LES) is the inner diameter (phosphor area) inside the dam.
5. AtmoSphere Technology creates the ideal ambiance for restaurants and other hospitality venues.
DS162 LUXEON CoB Core Range Product Datasheet 20200726 ©2020 Lumileds Holding B.V. All rights reserved.
4
