19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
L
TRUNK CABLE
P/N
OVERALL
LENGTH, L (m)
1.0 +0.2 / -0
3.0 +0.2 / -0
5.0 +0.2 / -0
10.0 +0.2 / -0
15.0 +0.3 / -0
25.0 +0.5 / -0
50.0 +1.0 / -0
100.0 +2.0 / -0
1.0 +0.2 / -0
3.0 +0.2 / -0
5.0 +0.2 / -0
10.0 +0.2 / -0
15.0 +0.3 / -0
25.0 +0.5 / -0
50.0 +1.0 / -0
100.0 +2.0 / -0
1.0 +0.2 / -0
3.0 +0.2 / -0
5.0 +0.2 / -0
10.0 +0.2 / -0
15.0 +0.3 / -0
25.0 +0.5 / -0
50.0 +1.0 / -0
100.0 +2.0 / -0
CABLE TYPE
FIBER TYPE
CONNECTOR/
CABLE COLOR
INSERTION
LOSS
RETURN
LOSS
K
J
H
1062250085
1062250086
1062250087
1062250037
1062250088
1062250038
1062250039
1062250040
1062250089
1062250090
1062250091
1062250041
1062250092
1062250042
1062250043
1062250044
1062250093
1062250094
1062250095
1062250045
1062250096
1062250046
1062250047
1062250048
CONNECTIONS
FROM
TO
P1-1
P2-13
L
THRU THRU
P1-12 P2-24
SINGLE JACKET
MM 50/125 µm
OM3 BIF
RUGGEDIZED
DUAL JACKET
P1-13
THRU
P1-24
P2-1
THRU
P2-12
K
AQUA / AQUA
0.5 dB
@ 850 nm
---
SINGLE JACKET
MM 50/125 µm
OM4 BIF
RUGGEDIZED
DUAL JACKET
J
SINGLE JACKET
SM 9/125 µm OS2
ITU-T G.657.A1 BIF
RUGGEDIZED
DUAL JACKET
YELLOW / YELLOW
0.5 dB
@ 1550 nm
- 50 dB
@ 1550 nm
H
G
MPO FEMALE
CONNECTOR
FLEXIBEND BOOT
(2X)
LABEL (2X)
24 FIBER BARE FIBER
CABLE,
⌀
3.8 mm, PLENUM
G
A
P1
2X
74
2X
25
2X
25
P2
B
L
F
SINGLE JACKET
MPO FEMALE
CONNECTOR
FLEXIBEND BOOT
(2X)
F
⌀
3.8 mm SUBUNIT
LABEL (2X)
24 FIBER RUGGEDIZED CENTRAL
TUBE CABLE,
⌀
5.4 mm, PLENUM
HEAT SHRINK
TUBING (2X)
A
E
P1
2X
74
2X
200
2X
25
2X
35
P2
B
E
L
RUGGEDIZED DUAL JACKET
D
D
NOTES:
C
13
1
MTP KEY
13
1
C
1. ENDCAPS ARE NOT SHOWN BUT INLCUDED.
2. LABEL IS PRINTED WITH MOLEX P/N AND
SERIAL NUMBER.
MTP KEY
B
4. CABLE CONSTRUCTION:
- L < 25 meters - SINGLE JACKET CABLE
- L ≥ 25 meters - RUGGEDIZED CENTRAL TUBE CABLE
5. INSERTION LOSS TEST DATA IS PROVIDED WITH EACH
SHIPMENT.
6. PACKAGING:
- L < 50 meters - INDIVIDUALLY COILED AND BAGGED
- L ≥ 50 meters - SHIPPED ON SPOOLS
VIEW A
SCALE 5:1
BENT BOOT DETAIL
PREFERRED PIN/BEND POSITIONING
VIEW B
SCALE 5:1
2017/11/08
2017/10/30
3. FOR DETAILED PRODUCT SPECIFICATION
SEE DOCUMENT 1062250000 ES.
24
12
24
12
QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
GENERAL
SYMBOLS
TOLERANCES
mm
1:1
=
0
(UNLESS SPECIFIED)
DRWN BY
DATE
=
=
=
=
=
=
0
0
0
EC NO:
167430
DRWN:
IGUMIN
CHK'D:
APPR: IGUMIN
B
ANGULAR TOL ±
°
4 PLACES
3 PLACES
2 PLACES
1 PLACE
0 PLACES
±
±
±
±
±
IGUMIN
CHK'D BY
DATE
2017/03/13
MPO(F) TO MPO(F) TRUNK CABLE,
FLEXIBEND BOOT, 24 FIBER, PLENUM
CHKD BY
APPR BY
DATE
0
0
0
0
PRODUCT CUSTOMER DRAWING
2017/03/21
SERIES
MATERIAL NUMBER
CUSTOMER
IGUMIN
DRAWING SIZE
A
THIRD ANGLE PROJECTION
FORMAT: master-tb-prod-D
REVISION: G
DATE: 2015/12/14
RELEASE STATUS
19
P1
RELEASE DATE
18
08.11.2017
17
18:19:37
C
=
B1
REV
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
106225
DOCUMENT NUMBER
SEE TABLE
DOC TYPE
DOC PART
SHEET NUMBER
A
D
5
4
1062250037
3
PSD
2
000
1 OF 1
1
16
15
14
13
12
11
10
9
8
7
6
