M39006/09/21/22/25/30/31
Vishay
Wet Tantalum Capacitors, Military Established Reliability,
MIL-PRF-39006 Qualified Styles CLR65, 79, 81, 90, 91
FEATURES
•
Hermetically sealed
•
Metal cased
•
Axial lead
•
Tubular
SPECIFICATIONS
Style CLR65, M39006/09
Style CLR69, M39006/21
Style CLR79, M39006/22
Style CLR81, M39006/25
Style CLR90, M39006/30
Style CLR91, M39006/31
Established Reliability Tantalum Capacitors to Military
Specification MIL-PRF-39006:
In accordance with the
Military Specification, MIL-PRF-39006 all capacitors are
marked with the Military Part Number (M39006/xx-xxxx)
rather than the older Style designation (CLRxxxxxxxx) and
should be ordered as such.
For information on the performance characteristics of these
capacitors, please refer to the latest issue of the Military
Specification. MIL-PRF-39006 establishes 1000 h failure
rate levels of 2 %, 1 %, 0.1 %, and 0.01 %. When ordering
these parts, care must be exercised that the correct part
number expressing the appropriate failure level be specified.
Each order for Military Style capacitors requiring government
inspection must state whether inspection is to be at the
destination or at the Vishay Sprague plant. Orders requiring
source inspection cannot be shipped until this has been
accomplished
MILITARY SPECIFICATION MIL-PRF-39006 ORDERING INFORMATION
M39006
BASIC DOCUMENT NUMBER
22
DETAIL SPECIFICATION NUMBER
0660
DASH NUMBER
Indicates the Basic
Specification; in this case
MIL-PRF-39006
Indicates the Detail
Specification of the Basic
Military Specification
Taken from Standard/
Extended Ratings
Tables
Note
The material in this section has been abstracted from MIL-PRF-39006/09/22/25/30/31.
www.vishay.com
58
For technical questions, contact: tantalum@vishay.com
Document Number: 40022
Revision: 12-Nov-07
M39006/09/21/22/25/30/31
Wet Tantalum Capacitors, Military Established Reliability,
MIL-PRF-39006 Qualified Styles CLR65, 79, 81, 90, 91
DIMENSIONS
in inches [millimeters]
Vishay
STYLE CLR65
STYLE CLR69
TERMINAL
WELDED
TO CASE
0.250 [6.35]
MAX.
TANTALUM FEED -
THROUGH 0.078
[1.98] MAX. DIA.
TERM. LOC. WITHIN
0.031 [0.79] R.
OF TRUE POSITION
-
+
D DIA.
0.094 [2.38]
MAX.
E
L
INSULATING SLEEVE
EXTERNAL
WELD
E
0.025 ± 0.002
[0.64 ± 0.05]
CIRCUIT DIAGRAM
GLASS
CASE
CODE
T1
T2
T3
T4
BARE CASE
D
0.188 ± 0.016 [4.78 ± 0.41]
0.281 ± 0.016 [7.14 ± 0.41]
0.375 ± 0.016 [9.53 ± 0.41]
0.375 ± 0.016 [9.53 ± 0.41]
L
0.453 + 0.031 - 0.016 [11.51 + 0.79 - 0.41]
0.641 + 0.031 - 0.016 [16.28 + 0.79 - 0.41]
0.766 + 0.031 - 0.016 [19.46 + 0.79 - 0.41]
1.062 + 0.031 - 0.016 [26.97 + 0.79 - 0.41]
WITH INSULATING
SLEEVE
D (Max.)
L (Max.)
E LEAD LENGTH
WEIGHT
(oz./g)
(Max.)
0.219 [5.56] 0.515 [13.08] 1.500 ± 0.250 [38.10 ± 6.35] 0.07 [2.0]
0.312 [7.92] 0.704 [17.88] 2.250 ± 0.250 [57.15 ± 6.35] 0.18 [5.1]
0.406 [10.31] 0.828 [21.03] 2.250 ± 0.250 [57.15 ± 6.35] 0.36 [10.2]
0.406 [10.31] 1.126 [28.60] 2.250 ± 0.250 [57.15 ± 6.35] 0.49 [13.9]
STYLE CLR79
STYLE CLR81
STYLE CLR90
STYLE CLR91
TERMINAL
WELDED
TO CASE
TANTALUM FEED -
THROUGH 0.078
[1.98] MAX. DIA.
0.250 [6.35]
MAX.
TERM. LOC. WITHIN
0.031 [0.79] R.
OF TRUE POSITION
+
-
D DIA.
0.094 [2.38]
MAX.
E
L
CASE
EXTERNAL
WELD
E
0.025 ± 0.002
[0.64 ± 0.05]
GLASS
CIRCUIT DIAGRAM
INSULATING SLEEVE
CASE
CODE
T1
T2
T3
T4
BARE CASE
D
0.188 ± 0.016 [4.78 ± 0.41]
0.281 ± 0.016 [7.14 ± 0.41]
0.375 ± 0.016 [9.53 ± 0.41]
0.375 ± 0.016 [9.53 ± 0.41]
L
0.453 + 0.031 - 0.016 [11.51 + 0.79 - 0.41]
0.641 + 0.031 - 0.016 [16.28 + 0.79 - 0.41]
0.766 + 0.031 - 0.016 [19.46 + 0.79 - 0.41]
1.062 + 0.031 - 0.016 [26.97 + 0.79 - 0.41]
WITH INSULATING
SLEEVE
D (Max.)
L (Max.)
E LEAD LENGTH
WEIGHT
(oz./g)
(Max.)
0.219 [5.56] 0.515 [13.08] 1.500 ± 0.250 [38.10 ± 6.35] 0.09 [2.6]
0.312 [7.92] 0.704 [17.88] 2.250 ± 0.250 [57.15 ± 6.35] 0.22 [6.2]
0.406 [10.31] 0.828 [21.03] 2.250 ± 0.250 [57.15 ± 6.35] 0.41 [11.6]
0.406 [10.31] 1.126 [28.60] 2.250 ± 0.250 [57.15 ± 6.35] 0.62 [17.7]
Document Number: 40022
Revision: 12-Nov-07
For technical questions, contact: tantalum@vishay.com
www.vishay.com
59
