WORLD PRODUCTS INC.
ELECTRONIC COMPONENT SOLUTIONS
F
ERRITE
I
NDUCTORS
19654 Eighth Street East, Sonoma, CA 95476-0517 USA • Phone (707) 996-5201 • Fax (707) 996-3380 • www.worldproducts.com
Revised 09/16/05
F
ERRITE
I
NDUCTORS
WORLD PRODUCTS INC.
19654 Eighth Street East, Sonoma, CA 95476, Phone (707) 996-5201, Fax (707) 996-3380
www.worldproducts.com
091605 Rev. 16.0
F
ERRITE
I
NDUCTORS
Features
1.
2.
3.
4.
Perfect for high density surface mount applications since magnetic shield eliminates crosstalk.
Highly reliable in wide temperature and humidity range. Superior Q characteristics in wide frequency.
Terminal electrode has excellent solder heat resistance.
RoHS compliant with Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003 on the restriction of the use of
certain hazardous substances in electrical and electronic equipment (RoHS Directive) and comply to a maximum concentration value of
0.1% by weight in homogeneous materials for lead (Pb), mercury, hexavalent chromium, polybrominated biphenyls (PBB) and
polybrominated diphenyl ethers (PBDE) and of 0.01% weight in homogeneous materials for cadmium.
Applications
1. Prevention of electromagnetic interference to signals on the secondary side of electronic equipment.
Ordering Information
WPF - 1608 -
(1)
(2)
680
(3)
K
(4)
T
(5)
(1)
(2)
Series
WPF:
Ferrite Inductors
Dimensions*
The first two digits: length (mm)
The last two digits: width (mm)
Inductance
Tolerance
K:
±10%
M:
±20%
Packaging
B:
Bulk Package
T:
Tape & Reel (Φ 178㎜ [ 7 inch ])
L:
Tape & Reel (Φ 254㎜ [10 inch ])
(3)
(4)
(5)
*1608(mm) is equivalent to 0603(inches).
2012(mm) is equivalent to 0805 (inches).
3216(mm) is equivalent to 1206 (inches).
Shape & Dimensions
Type
WPF-1608
L
1.6±0.15
[.063±.006]
2.0±0.2
[.079±.008]
2.0±0.2
[.079±.008]
3.2±0.2
[.126±.008]
W
0.8±0.15
[.031±.006]
1.25±0.2
[.049±.008]
1.25±0.2
[.049±.008]
1.6±0.2
[.063±.008]
Unit : mm [inches]
T
C
1
0.8±0.15
0.30±0.20
[.031±.006]
[.012±.008]
0.85±0.2
0.50±0.30
[.033±.008]
[.020±.012]
1.25±0.2
0.50±0.30
[.049±.008]
[.020±.012]
1.3±0.2
0.50±0.30
[.051±.008]
[.020±.012]
T
C
1
L
W
WPF-2012
WPF-3216
WORLD PRODUCTS INC.
19654 Eighth Street East, Sonoma, CA 95476, Phone (707) 996-5201, Fax (707) 996-3380
www.worldproducts.com
091605 Rev. 16.0
1
F
ERRITE
I
NDUCTORS
Specifications
1608 S
ERIES
Part No.
WPF-1608-270
WPF-1608-470
WPF-1608-560
WPF-1608-680
WPF-1608-820
WPF-1608-101
WPF-1608-121
WPF-1608-151
WPF-1608-181
WPF-1608-221
WPF-1608-271
WPF-1608-331
WPF-1608-391
WPF-1608-471
WPF-1608-561
WPF-1608-681
WPF-1608-821
WPF-1608-102
WPF-1608-122
WPF-1608-152
WPF-1608-182
WPF-1608-222
WPF-1608-272
* SRF : Self-Resonant Frequency.
Inductance
µH
0.027
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
Tolerance
min.
10
10
10
10
10
15
15
15
15
15
15
15
15
15
15
15
15
35
35
35
35
35
35
Q
typ.
45
45
45
45
45
30
30
30
30
30
30
30
30
30
30
30
30
50
50
50
50
50
50
±10%
±20%
L, Q test
frequency
(MHz)
50
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
SRF(MHz)
min.
260
260
255
250
245
240
205
180
165
150
136
125
110
105
95
80
75
70
60
55
50
45
40
typ.
350
320
300
290
280
270
260
250
220
200
190
180
170
160
150
140
130
95
80
70
70
60
55
DCR(mΩ)
max.
90
150
200
200
250
250
300
350
400
400
500
550
600
700
900
900
1600
500
600
650
750
900
1000
typ.
60
100
90
90
120
140
150
180
190
190
270
280
300
390
500
500
800
250
250
300
350
450
600
Rated
current
(mA) max.
200
200
200
200
200
200
200
200
200
200
200
150
150
150
150
150
100
100
100
50
50
50
50
* DCR : DC Resistance
*
Parts with other Inductance Tolerance(‘J’ ± 5%) can be provided upon request.
WORLD PRODUCTS INC.
19654 Eighth Street East, Sonoma, CA 95476, Phone (707) 996-5201, Fax (707) 996-3380
www.worldproducts.com
091605 Rev. 16.0
2
F
ERRITE
I
NDUCTORS
Specifications
2012 S
ERIES
Inductance
Part No.
µH
WPF-2012-470
WPF-2012-560
WPF-2012-680
WPF-2012-820
WPF-2012-101
WPF-2012-121
WPF-2012-151
WPF-2012-181
WPF-2012-221
WPF-2012-271
WPF-2012-331
WPF-2012-391
WPF-2012-471
WPF-2012-561
WPF-2012-681
WPF-2012-821
WPF-2012-102
WPF-2012-122
WPF-2012-152
WPF-2012-182
WPF-2012-222
WPF-2012-272
WPF-2012-332
WPF-2012-392
WPF-2012-472
WPF-2012-562
WPF-2012-682
WPF-2012-822
WPF-2012-103
WPF-2012-123
WPF-2012-153
WPF-2012-183
WPF-2012-223
WPF-2012-273
WPF-2012-333
* SRF: Self-Resonant Frequency.
Q
min.
20
20
20
20
25
25
25
25
25
25
25
30
30
30
30
30
45
45
45
45
45
45
45
45
45
50
50
50
50
50
30
30
30
30
30
typ.
60
60
60
60
50
50
50
50
50
50
50
50
50
50
50
50
75
75
75
75
80
80
80
80
80
60
60
60
60
60
40
40
40
40
40
Tolerance
L, Q test
frequency
(MHz)
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
4
2
2
1
1
1
1
0.4
SRF(MHz)
min.
320
300
280
255
235
220
200
185
170
150
145
135
125
115
105
100
75
65
60
55
50
45
40
38
35
32
29
26
24
22
19
18
16
14
13
typ.
400
380
350
320
300
280
250
230
220
200
180
170
160
150
135
125
105
95
85
75
70
65
55
50
48
45
40
36
33
30
27
25
22
20
18
DCR(mΩ)
max.
100
150
200
200
200
200
200
200
250
300
300
400
400
400
500
600
300
400
400
400
400
500
500
1000
1400
500
600
700
800
800
1500
1500
700
800
1000
typ.
50
80
80
80
90
65
60
100
100
150
150
190
190
280
300
350
120
140
140
160
200
250
270
500
700
250
330
380
450
470
750
810
350
450
600
Rated
current
(mA) max.
300
300
300
300
250
250
250
250
250
250
250
200
200
150
150
150
100
100
100
100
50
50
50
50
50
50
25
25
25
25
15
15
5
5
5
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
±10%
±20%
* DCR: DC Resistance
* Parts with other Inductance Tolerance(‘J’ ± 5%) can be provided upon request.
WORLD PRODUCTS INC.
19654 Eighth Street East, Sonoma, CA 95476, Phone (707) 996-5201, Fax (707) 996-3380
www.worldproducts.com
091605 Rev. 16.0
3
