Bussmann
®
Class G Fuseblocks
For Bussmann SC Fuses
600 Volt, 0 - 20 Amp
480 Volt, 25 - 60 Amp
Dimensional Data
1 to 30A
BG Series
and
G Series
All dimensions (±0.015)
1.53"
1.22"
0.36"
0.425"
0.425"
.360"
3"
(±0.031)
1.5"
.200"
±.003
0.86"
.765"
1.63"
2.38"
.169
≈
.210
TYP. 2"
Catalog Symbol:
BG Series and G Series
Class G Fuseblocks
For use with Class G Fuses (Bussmann SC)
Ampere Rating:
0-20A, 600V
25-60A, 480V
Withstand Rating:
100,000A RMS Sym.
Agency Information:
1-30A: UL Recognized, UL 512, Guide IZLT2, File E14853
35-60A: UL Listed, UL 512, Guide IZLT, File E14853
1-60A CSA Certified, C22.2 No. 39, Class 6225-01; File 47235
Material:
(1-30) Thermoplastic
(35-60) Phenolic
DIN-RAIL Adapters:
DRA-1 and DRA-2
Catalog Data
Terminal Type
Screw with
Pressure Plate
Box
Box Lug
Fig.
Amps
Quick-Connect* w/Quick Connect* Lug
.w/Retaining Clip No.
1
1 BG3011SQ
BG3011PQ
BG3011B
—
1
to
2 BG3012SQ
BG3012PQ
BG3012B
—
2
15
3 BG3013SQ
BG3013PQ
BG3013B
—
3
1 BG3021SQ
BG3021PQ
BG3021B
—
1
20
2 BG3022SQ
BG3022PQ
BG3022B
—
2
3 BG3023SQ
BG3023PQ
BG3023B
—
3
25
1 BG3031S
BG3031P
BG3031B
—
1
to
2 BG3032S
BG3032P
BG3032B
—
2
30
3 BG3033S
BG3033P
BG3033B
—
3
35
1
—
—
—
G30060-1CR 4
to
2
—
—
—
G30060-2CR 5
60
3
——
†G30060-3C G30060-3CR 6
WIRE #10 - #14CU
#10 - #14CU
#6 - #14CU #2 - #14CU
RANGE
Except 60A #2 - #8AL
†#2 - #14CU
#2 - #8AL
* QUICK CONNECT RATED FOR 20A MAXIMUM.
Poles
Figure 1.
Figure 2.
Figure 3.
35 to 60A
1.38"
0.22"
0.5"
0.47"
0.84"
0.29" DIAMETER
0.38" C'BORE
4.25"
2.125"
0.94"
Figure 4.
1.69"
1.78"
Figure 5.
1.41"
0.53"
0.22" DIAMETER
HOLE
3.56"
1.78"
2.75"
Figure 6.
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000Vac, 75-1500Vdc). Refer to Data Sheet: 8002 or contact
Bussmann Application Engineering at 636-527-1270 for more information.
The only controlled copy of this Data Sheet is the electronic read-only version located on the Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin is
intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information con-
tained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
10-4-02
SB02295
Form No. BG Series
Page 1 of 1
Data Sheet: 1106
