Technical Data
2122
Effective
June
2017
Supersedes
December 1998
HR
and HM
1/4" x
various length and SFE in-line fuse holder
Part
Number
Amps
Volts AC
Includes Fuse
Wire
HRJ*
SFE-20
__________
____________________
HRI
SFE-14
__________
____________________
HRH
SFE-9
__________
____________________
19∑ of #14
HRE
SFE-7
⁄Ω™
__________
____________________
HRG
SFE-6
__________
____________________
HRF
SFE-4
__________
__________________________________ ____
_
20
32
HMJ**
SFE-20
__________
____________________
HMI
SFE-14
__________
____________________
HMH
SFE-9
__________
____________________
8∑ of #14
HME
SFE-7
⁄Ω™
__________
____________________
HMG
SFE-6
__________
____________________
HMF
SFE-4
*Also available as in-line fuseholder only with lead wire contacts,
HRJ-Less-Fuse.
**Also available as in-line fuseholder only with lead wire contacts,
HMJ-Less-Fuse.
HDJ-A – For
⁄Ω¢∑ ≈ 1⁄Ω¢∑
fuse, no wire or fuse included, accepts #18 - #20 wire.
HDJ-B – For
⁄Ω¢∑ ≈ 1⁄Ω¢∑
fuse, no wire or fuse included, accepts #12 - #16 wire.
HDI-A – For
⁄Ω¢∑ ≈ ‡Ω•∑
fuse, no wire or fuse included, accepts #18 - #20 wire.
HDI-B – For
⁄Ω¢∑ ≈ ‡Ω•∑
fuse, no wire or fuse included, accepts #12 - #16 wire.
HAF-A – For
⁄Ω¢∑ ≈ fiΩ•∑
fuse, no wire or fuse included, accepts #18 - #20 wire.
Product features
•
•
•
•
•
Bayonet type knob
Maximum current rating 20 amps; voltage
rating 32 volts AC
Holders available as complete assembly
consisting of in-line holder with 8" or 14" of
#14 insulated wire and installed fuses
Replacement springs – BK/1A1853
Replacement contacts – 9838 for #18 - #22
wire, 9841 for #12 - #16 wire
Environmental
data:
Temperature Rating (RTI): +140 °C
Agency information:
No agency listing
Dimensions: in (mm):
All dimensions ±0.015"
2.19"
(55.6mm)
0.75"
(19.1mm)
0.69"
(17.5mm)
1.56"
(39.7mm)
0.38"
(9.5mm)
Life Support Policy: Eaton does not authorize the use of any of its products for use in life support devices or systems without the express written
approval of an officer of the Company. Life support systems are devices which support or sustain life, and whose failure to perform, when properly used
in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.
Eaton reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of any products. Eaton also
reserves the right to change or update, without notice, any technical information contained in this bulletin.
