2-1618092-3

Description
POWER/SIGNAL RELAY, SPST, MOMENTARY
CategoryMechanical and electronic products    relay
File Size103KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

2-1618092-3 Overview

POWER/SIGNAL RELAY, SPST, MOMENTARY

2-1618092-3 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Objectid1667238127
Reach Compliance Codeunknown
ECCN codeEAR99
Maximum coil voltage (AC)460 V
Coil/Input Power TypeAC
Contact (AC) maximum rated R load5A@120VAC
Maximum contact current (AC)5 A
Maximum contact current (DC)5 A
Maximum contact voltage (AC)120 V
Contact/Output Power TypeAC
Installation featuresPANEL MOUNT
Relay actionMOMENTARY
Relay style1 FORM B
Relay functionSPST
Relay typePOWER/SIGNAL RELAY
surface mountNO
Termination typeSOLDER/QUICK CONNECT
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
723TDX Product Details
Sensors & Protective Relays
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
723TDX
(2-1618092-3)
T E I nternal N umber: 2 - 1 6 1 8 0 9 2 - 3
Product Highlights:
l
Relay Type = Protective Relay
l
700TD Series
l
AC Actuating System
l
Input Voltage = 460 VAC
l
Reverse Power Protection Function
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Additional Product Images:
l
Line Drawing
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
l
Actuating System
= AC
l
Input Voltage (VAC ) = 460
l
Phase
= Three
l
C ontact Rating = 5A Resistive @ 120 VAC
Body Related Features:
l
Series
= 700TD
Contact Related Features:
l
Relay Type
= Protective Relay
Configuration Related Features:
l
C ontact Arrangement
= 1 Form A, SPST-NO, 1 N/O
l
C ontact Arrangement, Additional Output
= 1 Form B, SPST-NC , 1
N/C
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
Operation/Application:
l
Protection Function
= Reverse Power
l
Time Delay
= With
Other:
l
Brand = C II
