216.080XP: Descriptioncartridge fuses .08 amp 250v FA cartridge; CategoryCircuit protection Circuit protection; File Size212KB，2 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com; Environmental Compliance

Download Datasheet Parametric View All

216.080XP Overview

cartridge fuses .08 amp 250v FA cartridge

216.080XP Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
Fusing characteristics	FAST
body height	20 mm
Body length or diameter	5.2 mm
Circuit protection type	ELECTRIC FUSE
JESD-609 code	e3
Joule integral nominal
Installation features	INLINE/HOLDER
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
method of packing	BULK; TAPE AND REEL
physical size	5.2mm x 20mm
Rated breaking capacity	1500 A
Rated current	0.08 A
Rated voltage (AC)	250 V
Guideline	CCC; CE; CSA; IEC; SEMKO; UL
surface mount	NO
Terminal surface	Matte Tin (Sn)
Terminal shape	END CAP
Base Number Matches	1

Preview

Download Datasheet

View All

Axial Lead and Cartridge Fuses

Designed to IEC Standard

RoHS

Pb

5 x 20 mm

Fast-Acting Fuse 216P Series

®

D

V

E

• Designed to International (IEC) Standards for use globally.

• Meets the IEC 60127-2, Sheet 1 specification for Fast Acting Fuses.

• Available in Cartridge and Axial Lead Form.

• Available in ratings of 0.050 to 16 amperes.

• High breaking capacity.

• RoHS compliant and Lead-Free

• Improved I

2

t

ELECTRICAL CHARACTERISTICS:

% of Ampere

Rating

150%

210%

275%

Ampere

Rating

.05 – 6.3

8-16

.05 – 16

.05 – 4

5– 6.3

8-16

.05 – 6.3

8-16

.05 – 6.3

8-16

Opening

Time

60 minutes,

Minimum

30 minutes,

Minimum

30 minutes,

Maximum

0.01 sec.,

Min.;

2 sec.

Max.

0.01 sec.,

Min.;

3 sec.

Max.

0.04 sec.,

Min.;

20 sec.

Max.

.003 sec.,

Min.;

0.3 sec.

Max.

.01 sec.,

Min.;

1.0 sec.

Max.

.02 seconds,

Maximum

.03 seconds,

Maximum

ENVIRONMENTAL SPECIFICATIONS:

Operating temperature:

-55˚C to 125˚C

Thermal Shock:

MIL-STD-202F Method 107G, Test Condition B:

(5 cycles –65°C to +125°C)

400%

1000%

INTERRUPTING RATING:

0.05 - 10A

12.5 - 16A

1500A @ 250 VAC, 0.7-0.8 power factor

750A @ 250 VAC, 1.0 power factor

1000A @ 125 VAC, 1.0 power factor

Vibration:

MIL-STD-202F Method 201A

Humidity:

ORDERING INFORMATION:

Cartridge

Catalog

Number

216.050P

216.063P

216.080P

216.100P

216.125P

216.160P

216.200P

216.250P

216.315P

216.400P

216.500P

216.630P

216.800P

216

001.P

216

1.25P

216

01.6P

216

002.P

216

02.5P

216

3.15P

216

004.P

216

005.P

216

06.3P

216

008.P

216

010.P

216

12.5P

216

015.P

216

016.P

Ampere

Rating

.050

.063

.080

.100

.125

.160

.200

.250

.315

.400

.500

.630

.800

1

1.25

1.6

2

2.5

3.15

4

5

6.3

8

10

12.5

15

16

Voltage

Rating

250

Nominal

Resistance

Cold Ohms

15.90

10.45

7.885

5.793

3.675

5.349

3.350

2.350

1.850

0.907

0.866

0.465

0.295

0.237

0.153

0.111

0.076

0.058

0.037

0.025

0.018

0.014

0.012

0.008

0.00615

0.00445

Nominal

Melting I

2

t

A

2

Sec.

0.00019

0.00054

0.00084

0.00450

0.00545

0.00576

0.00438

0.00891

0.015

0.036

0.169

0.179

0.288

0.180

0.477

1.008

1.870

2.697

6.700

14.966

27.460

56.429

64.316

154.339

158.5

384.0

MIL-STD-202F Method 103B, Test Condition A. high relative humidity

(95%) and elevated temperature (40°C) for 240 hours.

Salt Spray:

MIL-STD-202F Method 101D, Test Condition B

11

AXIAL LEAD AND

CARTRIDGE FUSES

423

PHYSICAL SPECIFICATIONS:

Material:

Body: Ceramic

Cap: Nickel Plated Brass

Leads: Tin Plated Copper

Filler Sand (160mA – 16A)

Terminal Strength:

MIL-STD-202F Method 211A, Test Condition A

Solderability:

Reference IEC 60127 Second Edition 2003-01 Annex A

Product Marking:

Cap 1: current and voltage rating.

Cap 2: Agency approval markings.

Packaging:

Available in Bulk (V=5, H=100, M=1000 pcs/pkg) or on

Tape/Reel (MRET1=1000 pcs/reel).
