T97
www.vishay.com
Vishay Sprague
Solid Tantalum Chip Capacitors T
ANTAMOUNT
™,
Hi-Rel COTS, Ultra-Low ESR, Conformal Coated Case
FEATURES
• High reliability; Weibull failure rate grading
available
• Surge current testing per MIL-PRF-55365
options available
• Ultra-low ESR
• Tin / lead (SnPb) termination available
Available
Available
LINKS TO ADDITIONAL RESOURCES
Design Tools
Related
Documents
Calculators
Application
Notes
Technical
Notes
• Moisture sensitivity level 2a
• Mounting: surface mount
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
Did You
Know?
PERFORMANCE / ELECTRICAL CHARACTERISTICS
www.vishay.com/doc?40209
Operating Temperature:
-55 °C to +125 °C
(above 85 °C, voltage derating is required)
Capacitance Range:
10 μF to 2200 μF
Capacitance Tolerance:
± 10 %, ± 20 % standard
Voltage Rating:
4 V
DC
to 75 V
DC
Note
• For recommended voltage derating guidelines see “Typical Performance Characteristics”
ORDERING INFORMATION
T97
TYPE
R
CASE
CODE
227
CAPACITANCE
K
CAPACITANCE
TOLERANCE
020
DC VOLTAGE RATING
AT +85 °C
E
TERMINATION /
PACKAGING
(available options are
series dependent)
E = Sn / Pb solder /
7" (178 mm) reel
L = Sn / Pb solder /
7" (178 mm), 1/2 reel
C = 100 % tin /
7" (178 mm), reel
H = 100 % tin /
7" (178 mm), 1/2 reel
S
RELIABILITY
LEVEL
A
SURGE
CURRENT
See
Ratings
and
Case
Code
table
This is expressed in
pF. The first two
digits are the
significant figures.
The third is the
number of zeros
to follow.
K = ± 10 %
M = ± 20 %
This is expressed in
volts. To complete the
three-digit block,
zeros precede the
voltage rating. A
decimal point is
indicated by an “R”
(6R3 = 6.3 V).
A = 1.0 %
Weibull
B = 0.1 %
Weibull
(1)
C = 0.01 %
Weibull
(1)
S = 40 h
burn-in
Z = non-
established
reliability
A = 10 cycles
at +25 °C
B = 10 cycles
at -55 °C /
+85 °C
S = 3 cycles
at 25 °C
Notes
(1)
Available on select ratings. See “Standard Ratings” table
• We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size.
Low ESR solid tantalum chip capacitors allow delta ESR of 1.25 times the datasheet limits after mounting
Revision: 15-Oct-2021
Document Number: 40092
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T97
www.vishay.com
DIMENSIONS
in inches [millimeters]
J
Tantalum wire
nib identifies
anode (+) terminal
D L
B
A
W
Vishay Sprague
H
CASE CODE
V
D
E
R
F
Z
M
H
N
L (MAX.)
0.299
[7.6]
0.299
[7.6]
0.299
[7.6]
0.299
[7.6]
0.299
[7.6]
0.299
[7.6]
0.315
[8.0]
0.315
[8.0]
0.315
[8.0]
W
0.173 ± 0.016
[4.4 ± 0.4]
0.173 ± 0.016
[4.4 ± 0.4]
0.173 ± 0.016
[4.4 ± 0.4]
0.238 ± 0.016
[6.0 ± 0.4]
0.238 ± 0.016
[6.0 ± 0.4]
0.238 ± 0.016
[6.0 ± 0.4]
0.260 + 0.016 / - 0.024
[6.6 + 0.4 / - 0.6]
0.260 + 0.016 / - 0.024
[6.6 + 0.4 / - 0.6]
0.260 + 0.016 / - 0.024
[6.6 + 0.4 / - 0.6]
H
0.079
[2.0 max.]
0.138
[3.5 max.]
0.157 ± 0.016
[4.0 ± 0.4]
0.142 ± 0.016
[3.6 ± 0.4]
0.185 ± 0.016
[4.7 ± 0.4]
0.236 ± 0.016
[6.0 ± 0.4]
0.142 ± 0.016
[3.6 ± 0.4]
0.205 ± 0.016
[5.2 ± 0.4]
0.252 ± 0.016
[6.4 ± 0.4]
A
0.051 ± 0.012
[1.3 ± 0.3]
0.051 ± 0.012
[1.3 ± 0.3]
0.051 ± 0.012
[1.3 ± 0.3]
0.051 ± 0.012
[1.3 ± 0.3]
0.055 ± 0.016
[1.4 ± 0.4]
0.055 ± 0.016
[1.4 ± 0.4]
0.051 ± 0.012
[1.3 ± 0.3]
0.055 ± 0.016
[1.4 ± 0.4]
0.056 ± 0.017
[1.4 ± 0.4]
B
0.181 ± 0.024
[4.6 ± 0.6]
0.181 ± 0.024
[4.6 ± 0.6]
0.181 ± 0.024
[4.6 ± 0.6]
0.181 ± 0.024
[4.6 ± 0.6]
0.181 ± 0.024
[4.6 ± 0.6]
0.181 ± 0.024
[4.6 ± 0.6]
0.197 ± 0.024
[5.0 ± 0.6]
0.197 ± 0.024
[5.0 ± 0.6]
0.196 ± 0.025
[5.0 ± 0.6]
D (REF.)
0.252
[6.4]
0.252
[6.4]
0.252
[6.4]
0.244
[6.2]
0.244
[6.2]
0.244
[6.2]
0.260
[6.6]
0.260
[6.6]
0.259
[6.6]
J (MAX.)
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
Note
• The anode termination (D less B) will be a minimum of 0.012" [0.3 mm]
RATINGS AND CASE CODES
μF
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
V
E
E/R
R
R
V
E
E
R
F
E
E
R
F
E
F
H
H
R
H/F
H
R
F
F
M
R
F
F/H
H
E/R
R
F
H/Z/N
4V
6.3 V
10 V
16 V
20 V
25 V
35 V
40 V
50 V
63 V
D
R
F
H/Z
75 V
R
R/F
Z/H
Revision: 15-Oct-2021
Document Number: 40092
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T97
www.vishay.com
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
MAX. DF
AT +25 °C
120 Hz
(%)
8
8
6
6
8
8
8
30
30
8
6
6
6
6
6
8
20
30
8
6
10
6
14
8
20
20
8
8
10
10
14
20
MAX. ESR
AT +25 °C
100 kHz
(mΩ)
56
60
30
25
20
18
24
35
35
56
35
30
28
25
28
31
120
35
60
35
100
28
100
35
80
120
60
80
100
100
100
80
MAX.
RIPPLE
100 kHz
I
RMS
(A)
2.0
2.2
2.7
2.9
3.3
3.7
2.9
2.7
2.7
2.0
2.5
2.7
2.8
2.9
3.0
2.8
1.4
2.7
2.3
2.5
1.6
2.8
1.4
3.0
1.8
1.4
2.3
1.8
1.6
1.6
1.4
1.8
AVAILABLE
RELIABILITY
LEVELS
Vishay Sprague
4 V
DC
AT +85 °C; 2.7 V
DC
AT +125 °C
330
470
470
680
1000
1000
1500
1500
2200
330
330
470
470
680
680
1000
1000
1500
220
330
330
470
470
680
680
1000
220
220
330
330
470
680
V
V
E
E
E
R
R
F
R
V
E
E
E
E
R
R
F
F
E
E
F
E
H
R
H
F
E
R
F
H
H
H
T97V337(1)004(2)(7)(5)
T97V477(1)004(2)(7)(5)
T97E477(1)004(2)(7)(5)
T97E687(1)004(2)(7)(5)
T97E108(1)004(2)(4)(5)
T97R108(1)004(2)(7)(5)
T97R158(1)004(2)(4)(5)
T97F158(1)004(2)(7)(5)
T97R228(1)004(2)(4)(5)
T97V337(1)6R3(2)(4)(5)
T97E337(1)6R3(2)(7)(5)
T97E477(1)6R3(2)(4)(5)
T97E477(1)6R3(2)(7)(5)
T97E687(1)6R3(2)(4)(5)
T97R687(1)6R3(2)(7)(5)
T97R108(1)6R3(2)(4)(5)
T97F108(1)6R3(2)(7)(5)
T97F158(1)6R3(2)(4)(5)
T97E227(1)010(2)(7)(5)
T97E337(1)010(2)(7)(5)
T97F337(1)010(2)(7)(5)
T97E477(1)010(2)(4)(5)
T97H477(1)010(2)(7)(5)
T97R687(1)010(2)(6)(5)
T97H687(1)010(2)(7)(5)
T97F108(1)010(2)(3)(5)
T97E227(1)016(2)(4)(5)
T97R227(1)016(2)(7)(5)
T97F337(1)016(2)(7)(5)
T97H337(1)016(2)(7)(5)
T97H477(1)016(2)(4)(5)
T97H687(1)016(2)(4)(5)
13.2
18.8
18.8
27.2
40.0
40.0
60.0
60.0
88.0
20.8
20.8
29.6
29.6
42.8
42.8
63.0
63.0
94.0
22.0
33.0
33.0
47.0
47.0
68.0
68.0
100.0
35.2
35.2
52.8
52.8
75.2
100.0
A, B, C, S, Z
A, B, C, S, Z
A, B, C, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, C, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, C, S, Z
S, Z
A, B, C, S, Z
A, S, Z
A, B, S, Z
A, B, C, S, Z
A, B, C, S, Z
A, B, C, S, Z
A, B, S, Z
A, B, S, Z
6.3 V
DC
AT +85 °C; 4 V
DC
AT +125 °C
10 V
DC
AT +85 °C; 7 V
DC
AT +125 °C
16 V
DC
AT +85 °C; 10 V
DC
AT +125 °C
Note
• Part number definitions:
(1) Capacitance tolerance: K, M
(2) Termination and packaging: C, E, H, L
(3) Reliability level: A, S, Z
(4) Reliability level: A, B, S, Z
(5) Surge current: A, B, S
(6) Reliability level: S, Z
(7) Reliability level: A, B, C, S, Z
Revision: 15-Oct-2021
Document Number: 40092
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
