WPPC-A11064AB-TLD: DescriptionAC Input-Transistor Output Optocoupler, 1-Element, 5000V Isolation, SMD, 4 PIN; CategoryLED optoelectronic/LED photoelectric; File Size565KB，2 Pages; ManufacturerWorld Produts Inc.; Websitehttp://www.worldproducts.com; Environmental Compliance

Download Datasheet Parametric View All

WPPC-A11064AB-TLD Overview

AC Input-Transistor Output Optocoupler, 1-Element, 5000V Isolation, SMD, 4 PIN

WPPC-A11064AB-TLD Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1978231022
package instruction	SMD, 4 PIN
Reach Compliance Code	unknown
Coll-Emtr Bkdn Voltage-Min	60 V
Configuration	SINGLE
Nominal current transfer ratio	60%
Maximum dark power	100 nA
Maximum forward current	0.06 A
Maximum insulation voltage	5000 V
Number of components	1
Maximum operating temperature	100 °C
Minimum operating temperature	-30 °C
Optoelectronic device types	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER

Preview

Download Datasheet

View All

High Reliability Photo Coupler

DIP/ SMD /H

..........

WPPC-A11064

Series

USR/CNR Listed (File # 223387)

Features

1. Current transfer ratio.

(CTR: MIN. 60% at I

F

= ±1mA V

CE

= 5V)

2. High isolation voltage between input and output.

(Viso: 5000V

RMS

)

3. Compact dual-in-line package.

4. AC input.

5. Available package types: DIP(shown)/ SMD / H (Page 150).

Outside Dimension: Unit

(mm)

7.62

6.50

4.60

3.00

0.4

Part Numbering System:

Page 2.

Part Marking System:

Page 4.

.

3.50

Applications

0.26

1. Programmable controller applications for low input


couplers

and high V

CEO


couplers.

2. Telephone sets, telephone exchangers.

3. System appliances, limit switches, sensors thermostats, and

transducers, etc.

4. Signal transmission between circuits of different potentials and

impedances.

13.00

0

1.20

2.54

13.00

0

0.5

TOLERANCE :+ 0.2mm

Schematic: Top View

1. Anode, Cathode

2. Anode, Cathode

3. Emitter

4. Collector

Absolute Maximum Ratings

Parameter

Input

Forward current

Peak forward current

Power dissipation

Output

Collector-emitter voltage

Emitter-collector voltage

Collector current

Collector power dissipation

Total power dissipation

Isolation voltage 1 minute

Operating temperature

Storage temperature

Soldering temperature 10 second

Symbol

I

F

I

FM

P

D

V

CEO

V

ECO

I

C

P

C

Ptot

Viso

Topr

Tstg

Tsol

Rating

±60

±1

70

60

6

50

150

200

5000

-30 to +100

-55 to +125

260

ggg

(Ta=25°C)

Unit

mA

A

mW

V

mA

mW

Vrms

°C

Electro-optical Characteristics

Parameter

Input

Forward voltage

Peak forward voltage

Terminal capacitance

Output

Transfer

charac-

teristics

Collector dark current

Current transfer ratio

Collector-emitter saturation voltage

Isolation resistance

Floating capacitance

Cut-off frequency

Response time (Rise)

Response time (Fall)

Symbol

V

F

V

FM

Ct

I

CEO

CTR

V

CE

(sat)

Riso

Cf

fc

tr

tf

Conditions

I

F

=± 20mA

I

FM

=± 0.5A

V=0, f=1kHz

V

CE

=20V, I

F

=0

I

F

=± 1mA, V

CE

=5V

I

F

=± 20mA, I

C

=1mA

DC500V

V=0, f=1MH

Z

V

CC

=5V, I

C

=2mA, R

L

=100ohm

V

CE

=2V, I

C

=2mA, R

L

=100ohm

MIN.

—

60

—

5X10

—

10

(Ta=25°C)

TYP.

1.2

—

30

—

0.1

10

11

MAX.

1.4

3.0

—

0.1

600

0.3

—

1.0

—

20

Unit

V

pF

uA

%

V

ohm

pF

kHz

us

0.6

80

5

4

WORLD PRODUCTS INC.

http://www.worldproducts.com

2.70

P.O. Box 517, 19654 Eighth Street East, Sonoma, CA 95476 USA Phone (707) 996-5201 Fax (707) 996-3380

r031103
