LXR
Series
Large Can
Screw Terminal
Long Life
High Ripple
High CV
105 C Maximum
Temperature
The LXR series capacitors are computer grade capacitors designed for use in applications requiring a
very long lifetime with high ripple currents applied. These capacitors have a rated lifetime of 5,000
hours at 105 C with rated ripple current applied. The LXR series capacitors also have very high CV
values making them ideal for use in large power supply filter circuits and inverters.
Summary of Specifications
Screw terminals.
Capacitance range: 2,200 to 15,000µF.
Voltage range: 350 to 450VDC.
Operating temperature range: 25 C to 105 C.
Leakage current: 0.02CV(µA) or 5mA, whichever is smaller, after 5 minutes at
Standard capacitance tolerance: 20%
Nominal case size (D L): 63.5 115mm to 100 250mm.
Rated lifetime: 5,000 hours at 105 C with the rated ripple current applied.
20 C.
L ARGE CAN -105 C
LXR
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
427
LXR Series
LXR Specifications
Item
Operating Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
I
25 to 105 C
350 to 450VDC
2,200 to 15,000 F
20% ( M ) at
20 C, 120Hz
20 C.
Characteristics
0.02CV ( A ) or 5mA, whichever is smaller, after 5 minutes at
Where I = Leakage current ( A ), C = Nominal capacitance ( F ) and V = Rated voltage ( V )
Dissipation Factor ( Tan )
Low Temperature
Characteristics
Ripple Current Multipliers
Refer to Section 4 of the
Mini-Glossary for explanation
of Ripple Current Multipliers.
Insulation Resistance
0.15 maximum at
20 C, 120Hz
25 C shall not be less than 70% of the
Capacitance change at 120Hz: Capacitance at
specified value at 20 C.
Frequency (Hz )
50Hz
0.8
120Hz
1.0
300Hz
1.1
1kHz
1.3
3kHz
1.4
The insulation resistance of the sleeve will measure no less than 100 megohms with a 500VDC
potential between the mounting clamp and the sleeve. The mounting clamp shall be secured
around the sleeve of the capacitor body, and the terminals shall be shorted together.
The insulating sleeve will withstand a voltage of 2,000VAC without electrical breakdown when
the voltage is applied between the mounting clamp and the sleeve. The mounting clamp shall be
secured around the sleeve of the capacitor body, and the terminals shall be shorted together.
The following specifications shall be satisfied when the capacitors are restored to 20 C
after subjecting them to the DC rated voltage for 5,000 hours at 105 C with the rated ripple
current applied. The sum of DC voltage and peak AC voltage must not exceed the full rated
voltage of the capacitors.
Capacitance change:
≤
20% of initial measured value
Tan ( DF )
:
≤
200% of initial specified value
Leakage current
:
≤
initial specified value
Dielectric Strength
Load Life
Shelf Life
The following specifications shall be satisfied when the capacitors are restored to 20 C after
exposing them for 1,000 hours at 105 C without voltage applied. The rated voltage shall be
applied to the capacitors for a minimum of 30 minutes, at least 24 hours and not more than
48 hours before the measurements.
Capacitance change:
≤
20% of initial measured value
Tan ( DF )
:
≤
200% of initial specified value
Leakage current
:
≤
initial specified value
Others
Satisfies characteristic B, class Y, of JIS C5141
Part Numbering System for LXR Series
LXR
400
LG
272
M
63X115
When ordering, always specify complete catalog number for LXR Series.
LL
Terminals: LL is Standard.
Case Code: See Case Sizes in Tables.
Capacitance Tolerance: M = 20%
Capacitance Value: Expressed in Microfarads. The first two digits are
significant figures, and the third digit indicates the number of zeros
for capacitance of 100 F or more. R indicates the decimal point for
capacitance less than 100 F (e.g. R27 = .27 F; 2R7 = 2.7 F;
27R = 27 F; 271 = 270 F; 272 = 2,700 F; 273 = 27,000 F ).
Lead Configuration: LG = Screw Terminals.
L ARGE CAN -105 C
DC Rated Voltage: Expressed in Volts (e.g. 400 = 400WVDC).
Series Name: Indicates Basic Capacitor Design.
LXR
428
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
LXR Series
Diagram of Dimensions
Large Can / Screw Terminals
Unit: mm and inches
Terminal Specifications in Millimeters
Terminal
Code
LL
Thread
M5
Thread
Depth
9.5
J 0.8
Height
6.4
Ø
S 0.25
Diameter
Ø
T 0.25
Diameter
H Max.
Height
L
12
10.0
15.5
F
Vent
S
T
Terminal Specifications in Inches
Terminal
Code
LL
Thread
M5
Thread
Depth
0.375
J 0.032
Height
0.250
Ø
S
0.010
Ø
T 0.010
Diameter Diameter
0.393
0.610
H Max.
Height
L 0.472
J
PVC
Sleeve
L
H
L
'
MAX.
D
D
'
Insulating
Disk
Refer to the Mounting Hardware page at the beginning of the Large Can section for mounting
brackets and accessories.
Dimensions in Millimeters and Inches
Bare Can
Case
*Code*
mm
Ø
D
With Insulating Sleeve
inches
mm
L
0.08
4.528
5.118
6.102
7.480
4.528
5.118
6.102
6.693
6.102
6.693
7.480
7.480
8.661
9.843
Ø
D
'
Terminal Spacing
mm
L
'
Max.
4.685
5.275
6.260
7.638
4.685
5.275
6.260
6.850
6.260
6.850
7.638
7.638
8.819
10.000
F
0.40
inches
F
0.016
inches
L
'
Max.
119
134
159
194
119
134
159
174
159
174
194
194
224
254
Ø
D
'
0.032
1.0
63X115
63X130
63X155
63X190
76X115
76X130
76X155
76X170
89X155
89X170
89X190
100X190
100X220
100X250
L
2.0
115
130
155
190
115
130
155
170
155
170
190
190
220
250
Ø
D
0.04
0.8
63.5
2.500
64.3
2.531
28.0
1.102
76
2.992
76.8
3.024
31.5
1.240
89
3.504
89.8
3.535
31.5
1.240
100
3.937
100.8
3.969
41.5
1.633
*
The case code does not indicate actual size.
L ARGE CAN -105 C
LXR
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
429
