0.09 0.33
0.11 0.04
0.55
2X 0.12
0.14
0.50
0.30
0.20
2X
0.08
0.08
6
0.16
1
4
5
8
7
3
2
0.26
0.20
0.39
0.49
8X
0.04
0.59
0.30
2X
0.28
1.00
2X 0.02
8X 0.10
8X 0.016
2X 0.11
8X 0.032
0.148
P
R PIN 3
T PIN 2
S
PIN 1
PCB HOLE PATTERN
COMPONENT SIDE
0.10
0.195
0.245
TOP JACK SCHEMATIC
R
RS
T
TS
S
PIN 5
PIN 8
PIN 4
PIN 7
PIN 6
PERFORMANCE SPECIFICATIONS
INSERTION/EXTRACTION FORCES: INITIAL 0.8 TO 6 POUNDS.
DIELECTRIC WITHSTANDING VOLTAGE: 500 VAC
INSULATION RESISTANCE: INITIAL 100 MEGOHMS MINIMUM
CONTACT RESISTANCE PLUG TO JACK: 50 MILLIOHMS MAXIMUM
CONTACT RESISTANCE SHUNTS TO SPRINGS: 30 MILLIOHMS MAXIMUM
MECHANICAL LIFE: 5000 CYCLES MINIMUM
MATERIALS
SPRINGS AND TERMINALS: SILVER PLATED COPPER ALLOY
HOUSING: LCP
NOTES:
1. THIS PRODUCT IS RoHS COMPLIANT.
2. ALL DIMENSIONS REFERENCE ONLY.
UNLESS OTHERWISE SPECIFIED
1. ALL DIMENSIONS IN INCHES
- TWO PLACE DECIMALS
- THREE PLACE DECIMALS
P
N
REV
SIZE
FINISH
BOTTOM JACK SCHEMATIC
CUSTOMER DRAWING
THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED
BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.
WIDTH
MULT
LBS/M
MATERIAL
SPEC No.
TEMPER
0.02
0.005
SPEC No.
FIRST USED ON
DATE DRAWN
BY
CHKD
SCALE
2:1
26432
ECO 21834
REDRAWN
08-28-09
JEB
TJK
BDS
APVD
05-28-97 BDS
DATE
BY
080709
BDS
BDS
080709
BDS
080709
PART No.
APVD
SHEET
1
OF
1
REV
ECO NUMBER
REVISIONS
DO NOT SCALE DRAWING
NAME
3.5 MM DUAL JACK, RoHS
35RAPC7J
P
SolidWorks CAD File
B
