RM75TPM-H / -24 / -2H
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Three-Phase
Diode Bridge Module
150 Amperes / 800-1600 Volts
A
D
E
E
~
~
~
K (2 PLACES)
F
B
G
+
–
L THD
(5 PLACES)
H
C
J
~
LABEL
~
~
Description:
Powerex Three-Phase Diode
Bridge Modules are designed for
use in applications requiring rectifi-
cation of three-phase AC lines into
DC voltage. Each module consists
of six diodes and the interconnect
required to form a complete three-
phase bridge circuit. Each diode is
electrically insulated from the
mounting base plate for easy
mounting on a common heatsink
with other components.
Features:
□
Isolated Mounting
□
Metal Base Plate
□
Low Thermal Impedance
+
–
Applications:
Outline Drawing and Circuit Diagram
Dimensions
A
B
C
D
E
F
G
H
J
K
L
Inches
3.15
1.58
Millimeters
80.0
40.0
□
Motor Control
□
Inverters
□
UPS
Ordering Information:
Example: Select the complete
module number you desire from
the table - i.e. RM75TPM-H is a
800V (V
CES
), 150 Ampere Three-
Phase Diode Bridge Module.
Type
-H
-24
-2H
Current Rating
Amperes
150
150
150
V
CES
Volts
800
1200
1600
0.95 +0.06/+0.02 24.1 +1.5/-0.5
2.68±0.01
0.79
0.41
0.45
1.18
0.32
0.217
M5
68.0±0.25
20.0
10.5
11.5
30.0
8.0
5.5
M5
1
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
RM75TPM-H / -24 / -2H
Three-Phase Diode Bridge Module
150 Amperes / 800-1600 Volts
Absolute Maximum Ratings,
T
j
= 25
°C
unless otherwise specified
Characteristics
Repetitive Peak Reverse Voltage
Non-Repetitive Peak Reverse Voltage
Recommended AC Input Voltage
DC Output Current (Three-Phase Full Wave Rectifying Circuit)
Symbol
V
RRM
V
RSM
E
A
I
DC
I
FSM
I
2
t
T
j
T
stg
–
–
–
V
iso
-H
800
960
220
150
RM75TPM
-24
1200
1350
370
150
-2H
1600
1700
440
150
Units
Volts
Volts
Volts
Amperes
(T
C
=99°C) (T
C
=85°C) (T
C
=85°C)
Surge (Non-Repetitive) Forward Current (One Half Cycle at 60Hz, Peak Value)
I
2
t for Fusing (Value for One Cycle of Surge Current)
Junction Temperature
Storage Temperature
Maximum Mounting Torque M5 Mounting Screw
Maximum Mounting Torque M5 Terminal Screw
Weight
Dielectric Strength (AC 60Hz, 1 minute between terminal and base plate)
1500
9400
-40 ~ +150
-40 ~ +125
17
17
200
2500
Amperes
A
2
sec
°C
°C
in-lb
in-lb
Grams
Volts
Electrical and Thermal Characteristics,
T
j
= 25
°C
unless otherwise specified
Characteristics
Repetitive Reverse Current
Symbol
I
RRM
V
FM
R
th(j-c)
R
th(c-f)
Test Conditions
T
j
= 150°C, V
RM
= V
RRM,
V
RRM
Applied
Forward Voltage Drop
Thermal Resistance
Thermal Resistance
Isolation Resistance (-24, -2H)
T
j
= 25°C, I
FM
= 150A, tw
≤
1ms
Junction to Case
Case to Fin, Conductive Grease Applied
Measured with a 500V Megohommeter
Between Main Terminal and Case
MAXIMUM
FORWARD CHARACTERISTICS
(TYPICAL)
ALLOWABLE SURGE (NON-REPETITIVE)
FORWARD CURRENT
SURGE (NON-REPETITIVE)
FORWARD CURRENT, (A)
Min.
–
Typ.
–
Max.
15
Units
mA
–
–
–
10
–
-
–
–
1.3
0.2
0.06
–
Volts
°C/
W
°C/W
MΩ
10
4
T
j
= 25°C
FORWARD CURRENT, I
FM
, (AMPERES)
1600
TRANSIENT THERMAL IMPEDANCE, (°C/W)
0.16
0.14
0.12
0.10
0.08
0.06
0.04
0.02
TRANSIENT THERMAL
IMPEDANCE CHARACTERISTICS
(JUNCTION TO CASE)
10
0
10
1
1400
1200
1000
800
600
400
200
0
10
0
10
1
CONDUCTIVE TIME, (CYCLES AT 60Hz)
10
3
10
2
10
1
0.8
1.2
1.6
2.0
2.4
2.8
10
2
0
10
-3
10
-2
TIME, (s)
10-
1
10
0
FORWARD VOLTAGE, V
FM
, (VOLTS)
MAXIMUM POWER DISSIPATION
ALLOWABLE CASE TEMPERATURE
VS. DC OUTPUT CURRENT
400
140
130
POWER DISSIPATION, (WATTS)
CASE TEMPERATURE (°C)
300
120
110
100
90
200
100
0
0
20
40
60
80 100 120 140 160
DC OUTPUT CURRENT, (AMPERES)
80
0
20
40
60
80 100 120 140 160
DC OUTPUT CURRENT, (AMPERES)
2
