ISL3170EIUZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> ISL3170EIUZ

ISL3170EIUZ: DescriptionLINE TRANSCEIVER, PDSO10, ROHS COMPLIANT, PLASTIC, MO-187BA, MSOP-10; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size1MB，20 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance; Related ProductsFound2parts with similar functions to ISL3170EIUZ

Download Datasheet Parametric Compare View All

ISL3170EIUZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ISL3170EIUZ	-	-	View	Buy Now

ISL3170EIUZ Overview

LINE TRANSCEIVER, PDSO10, ROHS COMPLIANT, PLASTIC, MO-187BA, MSOP-10

ISL3170EIUZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	TSSOP
package instruction	ROHS COMPLIANT, PLASTIC, MO-187BA, MSOP-10
Contacts	10
Reach Compliance Code	unknow
Differential output	YES
Number of drives	1
Input properties	DIFFERENTIAL SCHMITT TRIGGER
Interface integrated circuit type	LINE TRANSCEIVER
Interface standards	EIA-422; EIA-485
JESD-30 code	S-PDSO-G10
JESD-609 code	e3
length	3 mm
Humidity sensitivity level	2
Number of functions	1
Number of terminals	10
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	SQUARE
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
Maximum receive delay	120 ns
Number of receiver bits	1
Maximum seat height	1.1 mm
Maximum supply voltage	3.6 V
Minimum supply voltage	3 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
maximum transmission delay	700 ns
width	3 mm
Base Number Matches	1

Preview
