Pl tronics, Inc.
.
19013 36th Ave. W, Suite H Lynnwood, WA 98036 USA
Manufacturer of High Quality Frequency Control Products
TV4 TCVCXO Series
Surface Mount or Full Size Metal Thru-Hole Temp. Compensated Voltage Controlled Xtal Oscillator
HCMOS, Clipped Sine Wave or Sine Wave Compatible
Standard Specifications
Operating Temperature Range
vs. Temp
Overall Frequency
vs. Vcc / Load
Stability
Aging
Frequency Adj by Trimmer
Supply Voltage (Vcc)
Output Logic
Output Voltage Levels
Supply Current (Icc)
Output Load (see Test Circuit 7)
Control Voltage Range (CVR)
Pullablity over CVR
Linearity
0 to +50°C to -40 to +85°C available
± 1.0 to ± 15 PPM over Operating Temperature Range available
± 0.5 PPM maximum over Vcc ± 5% / ± 0.3 PPM maximum over Load ± 5%
± 3 PPM first year, ± 1 PPM per year thereafter at 25°C ± 5%
± 3 PPM minimum
5.0 volts and 3.3 volts available
HCMOS
Clipped Sine Wave Sine Wave
Logic “1” 90% of Vcc min
1 volt p-p minimum
Logic “0” 10% of Vcc max
Consult Factory
20 to 40 mA max
2 to 5 mA max
10 TTL Loads or 15pF
10 K // 10 pF
0.5 to 4.5 volts for 5.0 volt Supply; 0.0 to 3.3 volts for 3.3 volt Supply
± 5, 10, 15 PPM. Consult factory for ± 25 PPM.
± 10% (Consult factory for ± 5%)
Part Numbering Guide
Portions of the part number that appear after the frequency may not be marked on part (C of C provided)
Consult factory for
3TV4 6 H 100 A T - 60.0M - XXX
(Internal Code or blank)
available frequencies
and specs. Not all
Model / Supply Voltage
Frequency in MHz
options available
TV4= 5.0 volts ±5%
Frequency Deviation (Pullability) over CVR
for all frequencies.
3TV4= 3.3 volts ±5%
S: ± 5 PPM
Q: ± 15 PPM
A special p/n may
R: ± 10 PPM
T: ± 25 PPM
TCVCXO Package, Max Height
be assigned.
Frequency Stability
is inclusive of
frequency shifts due
to calibration,
temperature, supply
voltage, shock,
vibration and load
10.00 MHz
–
60.00 MHz
On Test Circuit for Clipped Sine Wave only: Add a 20 K resistor from output to ground
6=Thru-Hole, 5.0mm
7=Surface Mount, 5.5mm
8=Surface Mount, 4.0mm
9=Thru-Hole, 8.5mm
Logic
C: Clipped Sine Wave
H: HCMOS
S: Sine Wave
not to scale
Operating Temperature Range {Tightest FS available}
A: 0 to +50
°
C {±1.0 PPM }
D: -20 to +75
°
C {± 2.0 PPM }
B: 0 to +70
°
C {±1.5 PPM }
E: -30 to +75
°
C {± 2.5 PPM }
C: -10 to +70
°
C {± 2.0 PPM } F: -40 to +85
°
C {± 5.0 PPM }
Frequency Stability (FS)
010: ± 1.0 PPM 025: ± 2.5 PPM 100: ± 10.0 PPM
015: ± 1.5 PPM 030: ± 3.0 PPM 150: ± 15.0 PPM
020: ± 2.0 PPM 050: ± 5.0 PPM
Mechanical: inches (mm)
Package 6
Due to part size and factory abilities, part marking may vary from lot to lot and may contain our part number or an internal code.
Package 7
Package 8
Package 9
.492 (12.5) MAX
.600 (15.24)
.300 (7.62)
1
7
Vcon GND
Vcc
14
OUT
8
.600 (15.24)
.740 (18.8) MAX
.858 (21.8) MAX
.17
(4.3)
.12 (3.0)
.66 (16.76)
.100
(2.54)
TYP
.055
(1.4)
.04 x .20
(1.0 x 5.08)
1
Vcc
GND
5
2
3
OUT Vcon
GND
4
0.375 (9.4)
.300 (7.62)
.748 (19.0) MAX
.600 (15.24)
.799 (20.3)
Trimmer hole locations may vary
.110 (2.8)
Jan 2004
Pl tronics, Inc.
(425) 776 -1880, Fax: (425) 776-2760, ple-sales@pletronics.com, www.pletronics.com
.799 (20.3)
Vcc
14
OUT
8
Vcc
Vcon
GND
OUT
GND
.457 (11.6)
1
Vcon
7
GND
.461 (11.7) MAX
.300 (7.62)
Tab
.04 x .10
(1.0 x 2.5)
.197 (5.0)
MAX
.193 (4.9)
MIN
.217 (5.5)
MAX
.600 (15.24)
.157 (4.0)
MAX
.457 (11.6)
.386 (9.8)
.300 (7.62)
.335 (8.5)
MAX
.157 (4.0)
MIN
GND
