DIAMOND
Fiber Optic Components
The unique, user-friendly features of the Diamond E-2000
™
connector,
coupled with its rapid and enthusiastic worldwide acceptance, have
prompted the development of a duplex version of this product.
The E-2000
™
Duplex connector is a natural extension of the current product.
Through the use of a simple clip-bridge and an extended thumb-latch, it offers
the same renowned performance and stability as the single fiber version.
Furthermore, it uses common components and can be terminated using
existing tooling.
Similar to single fibre the E-2000™ Duplex features the following
highlights:
•
•
•
•
•
•
•
•
•
Injection molded housing (UL 94 V0 flammability rating)
Positive latching mechanism with interchangeable, color-coded thumb-
lacht
Spring-loaded shutters
Integrated protective caps
Guiding tracks
Interchangeable color-coded mating adapter frames
Compact, rectangular footprint; push-pull design
Existing components can be upgrated to duplex throgh the use of a simple
clip-bridge and an extended thumb-latch
Two-component ferrule
E-2000
™
DUPLEX
SINGLE MODE /
MULTIMODE
E-2146.6/E-2156.6
SINGLE MODE APC
E-2148.6
SINGLE MODE APC
Type designation:
Ferrule material:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
9/125/900
9/125/900/3000/6500
31,5
E-2148.6
Zirconia/copper-nickel alloy insert (Pilzferrule)
Plastic (green)
8° angled (APC)
Order Number
Unterminated connector
Terminated assembly
- 000 - 001 L 000
- 000 - 004 L 000
1
12
9
56
21,7
- xxx - 001 L xxx
- xxx - 054 L xxx
2
3
4
Thumb-latch
Order No.
green
305
blue
315
black
325
red
335
orange
345
yellow
355
white
365
violet
375
12,7
Connectors for other fiber and cable dimensions available upon request
42
MATING ADAPTER
Type designation:
Mating sleeve:
External parts:
Frame color
Blue
Green
Black
Red
Zirconia
Plastic green
Order Number
Frame color
Orange
Yellow
White
Violet
Order Number
165 - 301 - 905 V 255
165 - 301 - 905 V 266
165 - 301 - 905 V 277
165 - 301 - 905 V 288
13
13
E-2210.2-***
165 - 301 - 905 V 211
165 - 301 - 905 V 222
165 - 301 - 905 V 233
165 - 301 - 905 V 244
21,7
12,7
30
MOUNTING INSTRUCTIONS
Ø 2,2
+0.2
0
12,7
22
±0.2
30
±0.1
Max wall thickness 2 mm
The E-2000™ Duplex connector is available in multimode, single mode
convex polished (PC) and 8° angle polished (APC) version.
DIAMOND SA
Via dei Patrizi 5
CH-6616 LOSONE
Tel. ++41-91/785 45 45
Fax ++41-91/785 45 00
e-mail: info@diamond-fo.com
Specifications subject to change
without notice
002-037-210P002100
4
13,3
±0.2
SPECIFICATIONS
Multimode
Insertion Loss (IL)
Return Loss (RL)
Repeatability of IL
Service life
Operating temperature
Storage temperature
* Measured with high precision reflectometer
CONNECTORS
Single mode
typ 0.2
max 0.4
min 50
max
±0.1
1000 mate/demate cycles
-40 / +85
-40 / +90
°C
°C
May be further limited by cable specifications
Single mode 8° APC Single mode 0.1 dB
typ 0.2
max 0.4
max 0.1
min 85*
-
Units
dB
dB
dB
Test conditions
IEC 1300-3-4;
λ
= 1300/1550nm
IEC 1300-3-6;
λ
= 1300/1550nm
Over service life
31,5
SINGLE MODE
Type designation:
Ferrule material:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
9/125/900
9/125/900/3000/6500
12
typ 0.15
max 0.4
E-2146.6
Zirconia/copper-nickel alloy insert (Pilzferrule)
Plastic (blue)
Convex (PC)
Order Number
Unterminated connector
Terminated assembly
- 000 - 001 L 000
- 000 - 004 L 000
1
typ -40
min 70*
9
56
- xxx - 001 L xxx
- xxx - 054 L xxx
2
3
4
21,7
Thumb-latch
Order No.
blue
303
green
313
black
323
red
333
orange
343
yellow
353
white
363
violet
373
12,7
Connectors for other fiber and cable dimensions available upon request
MULTIMODE
Type designation:
Ferrule material:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
50/125/900
E-2156.6
Zirconia/copper-nickel alloy insert (Pilzferrule)
Plastic (blue)
Convex (PC)
Order Number
Unterminated connector
Terminated assembly
- 000 - 001 L 000
- xxx - 001 L xxx
- 000 - 004 L 000
- 000 - 001 L 000
- 000 - 004 L 000
1
The E-2000
™
permits the user to specify the color of the thumb-latch and the mating adapter frame so that different
line types, uses, destinations and points of origin, etc. can be readily identified.
The thumb-latch and frame are available in eight distinct colors:
1.
2.
3.
4.
Blue
White
Black
Red
(RAL 5015)
(RAL 9010)
(RAL 9005)
(RAL 3020)
5.
6.
7.
8.
Orange
Yellow
Green
Violet
(RAL 2003)
(RAL 1016)
(RAL 6018)
(RAL 4008)
50/125/900/3000/6500
62.5/125/900
62.5/125/900/3000/6500
- xxx - 054 L xxx
- xxx - 001 L xxx
- xxx - 064 L xxx
2
3
4
42
Thumb-latch
Order No.
blue
304
green
314
black
324
red
334
orange
344
yellow
354
white
364
violet
374
13
In addition, colored connector bodies and mating adapter housings are used to identify the ferrule polish. Blue (RAL
5015) is used for connectors with convex polished (PC) ferrules and green (RAL 6018) identifies 8° angle polished
(APC) types.
Connectors for other fiber and cable dimensions available upon request
MATERIALS: CONNECTOR AND MATING ADAPTER
Item
Component
Material
MATING ADAPTER
Type designation:
Mating sleeve:
External parts:
Frame color
E-2210.2-***
Zirconia
Plastic blue
Frame color
Orange
Gelb
Weiss
Violett
Order Number
165 - 301 - 905 V 155
165 - 301 - 905 V 166
165 - 301 - 905 V 177
165 - 301 - 905 V 188
21,7
Order Number
165 - 301 - 905 V 111
165 - 301 - 905 V 122
165 - 301 - 905 V 133
165 - 301 - 905 V 144
12,7
Connector
1
2
3
4
Connector code
Connector code for termination on other end of assembly
- For pigtail:
insert 000
- For patch assemblies:
insert connector code for other connector
Code for fiber or cable
Length in meters
Max wall thickness 2 mm
22
±0.2
30
±0.1
4
13,3
±0.2
Mating adapter
1
2
3
4
5
6
7
A
B
C
D
E
Housing
Protective cap
Cable boot
Thumb-latch
Ferrule Ø 2,5 mm
Ferrule case
Bridge
Outer housing
Coded frame
Shutters
Inner housing
Alignment sleeve
PBT
Metal/Plastic
PUR
PBT
Zirconia/Cu-Ni insert (Pilz)
LCP
POM
PBT
PBT
Metal
LCP
Zirconia
2
5
6
1
7 4
3
Blue
Green
Black
Red
12,7
30
MOUNTING INSTRUCTIONS
C D E
A
B
ORDER NUMBER CODES
Ø 2,2
+0.2
0
13
