204-124LPSTR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> switch> 204-124LPSTR

204-124LPSTR: DescriptionSlide Dip Switch, 4 Switches, SPDT, Off-on, Latched, 0.05A, 24VDC, Solder Terminal, Surface Mount-straight, ROHS COMPLIANT; CategoryMechanical and electronic products switch; File Size498KB，4 Pages; ManufacturerCTS; Environmental Compliance

Download Datasheet Parametric View All

204-124LPSTR Overview

Slide Dip Switch, 4 Switches, SPDT, Off-on, Latched, 0.05A, 24VDC, Solder Terminal, Surface Mount-straight, ROHS COMPLIANT

204-124LPSTR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
ECCN code	EAR99
Actuator angle
Actuator color	WHITE
Actuator length	0.035 inch
Actuator type	SLIDE
Other features	LOW PROFILE
body width	9.78 mm
body height	7.62 mm
Body length or diameter	22.5 mm
center contact material	COPPER ALLOY
Center contact plating	GOLD
Maximum contact current (DC)	0.05 A
Contact (DC) maximum rated R load	.05A@24VDC
Contact function	OFF-ON
Contact resistance	0.1 mΩ
Maximum contact voltage (DC)	24 V
Dielectric withstand voltage	500VAC V
Electrical life	10000 Cycle(s)
End contact material	COPPER ALLOY
End contact plating	GOLD
Insulation resistance	1000000000 Ω
JESD-609 code	e3
Manufacturer's serial number	204
Installation features	SURFACE MOUNT-STRAIGHT
Number of positions	4
Number of switching segments	4
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
method of packing	TAPE AND REEL
seal	EPOXY TERMINAL SEALED; TOP TAPE SEALED
Solderability	WAVE
surface mount	NO
Switch action	LATCHED
switch function	SPDT
Switch type	SLIDE DIP SWITCH
Terminal surface	Tin (Sn)
Terminal material	COPPER ALLOY
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

Series 204 SMT

Surface Mount

Multi-Functional

DIP Switch

IR Solderable

Features

Optimized Mechanical Features

• Coplanarity: 0.1mm / .004” max.

• Compatible with SMT assembly including IR and

Vapor-Phase (up to 260°C)

• Enclosed actuators shield contacts from foreign particles

throughout life of switch

• Gull-wing terminal configuration

• Multiple circuit configurations available

• PCB washable with removeable tape seal and bottom

epaxy seal

• Tube or tape and reel packaging available

Optimized Contact System

• Contact wiping action on make and break

• Integral terminal and contact locked into thermoset base

• Available with low profile standard, or extended actuators

• Electrostatic discharge shield rated to 22 KV

Materials

• Gold plated, copper alloy contacts

• High temperature body and actuator materials (UL94V-0)

• RoHS compliant

Switch Function

SPST - 2 through 10 and 12 positions

SPDT&DPST - 1 through 6 positions

DPDT&4PST - 1 through 3 positions

3PST - 1 through 4 positions

Contact Resistance

50 milliohm maximum initial

100 milliohm maximum at end of life

Insulation Resistance

1,000 Meg ohms minimum across open switches

1,000 Meg ohms minimum between adjacent closed switches

Dielectric Strength

500 VAC minimum for 1 minute between

adjacent switches

Nonswitching Rating

100 mA or 50 VDC maximum

Switch Capacitance

5 pF maximum between adjacent closed switches

Operating Temperature

–55°C to +85°C

Actuation Life

Electrical and Mechanical Specifications

Coplanarity

0.1mm/.004" max.

Allowable Solder Time

IR and Vapor Phase - up to 60 seconds at 260°C

Wave - up to 5 seconds at 260°C

Vibration

Per MIL-STD-202F, method 204D, condition B

(.06" or 15 G’s between 10 Hz to 2K Hz) with

no contact inconsistencies greater than 1 microsecond

Shock

Per MIL-STD-202F, method 213B, condition A

(25 G’s) with no contact inconsistencies

greater than 1

microsecond

Sealing

Optional bottom epoxy seal

Optional removable tape seal

Marking

Special side or top marking available - consult CTS

Packaging

Standard : Anti-Static tube packaging

Optional : Tape and Reel packaging

10,000 cycles switching

50 mA @ 24 VDC

1-4

CTS Electronic Components

www.ctscorp.com

3/07/07
