W24010-70LL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > storage> storage> W24010-70LL

W24010-70LL: DescriptionStandard SRAM, 128KX8, 70ns, CMOS, PDIP32, 0.600 INCH, PLASTIC, DIP-32; Categorystorage storage; File Size244KB，12 Pages; ManufacturerWinbond Electronics Corporation; Websitehttp://www.winbond.com.tw

Download Datasheet Parametric Compare View All

W24010-70LL Overview

Standard SRAM, 128KX8, 70ns, CMOS, PDIP32, 0.600 INCH, PLASTIC, DIP-32

W24010-70LL Parametric

Parameter Name	Attribute value
Parts packaging code	DIP
package instruction	DIP,
Contacts	32
Reach Compliance Code	unknow
ECCN code	EAR99
Maximum access time	70 ns
JESD-30 code	R-PDIP-T32
JESD-609 code	e3
length	41.91 mm
memory density	1048576 bi
Memory IC Type	STANDARD SRAM
memory width	8
Number of functions	1
Number of terminals	32
word count	131072 words
character code	128000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	128KX8
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Parallel/Serial	PARALLEL
Certification status	Not Qualified
Maximum seat height	5.33 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	MATTE TIN
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	15.24 mm
Base Number Matches	1

Preview

Download Datasheet

View All

W24010/LL

128K

8 CMOS STATIC RAM

GENERAL DESCRIPTION

The W24010 is a normal-speed, very low-power CMOS static RAM organized as 131072

8 bits that

operates on a single 5-volt power supply. This device is manufactured using Winbond's high

performance CMOS technology.

FEATURES

•

Low power consumption:

−

Active: 350 mW (max.)

−

Standby: 250

µW

(max.)

Access time: 70 nS (max.)

Single 5V power supply

Fully static operation

All inputs and outputs directly TTL compatible

Three-state outputs

•

Battery back-up operation capability

Data retention voltage: 2V (min.)

Packaged in 32-pin 600 mil DIP, 450 mil SOP,

standard type one TSOP (8 mm

20 mm),

reverse type one TSOP (8 mm

20 mm),

small type one TSOP (8 mm

13.4 mm) and

reverse small type one TSOP (8 mm

13.4

mm)

PIN CONFIGURATIONS

A16

A14

A12

I/O1

I/O2

I/O3

A15

CS2

A13

A11

A10

CS1

I/O8

I/O7

I/O6

I/O5

I/O4

BLOCK DIAGRAM

CLK GEN.

A16

A14

A12

I/O1

I/O8

DATA

CNTRL.

CLK

GEN.

CS1

CS2

A15

A13

A8 A1 A0 A11 A10

I/O CKT.

COLUMN DECODER

PRECHARGE CKT.

CORE CELL ARRAY

1024 ROWS

128 X 8 COLUMNS

A11

A13

CS2

A15

A16

A14

A12

32-pin

TSOP

A10

CS1

I/O8

I/O7

I/O6

I/O5

I/O4

I/O3

I/O2

I/O1

PIN DESCRIPTION

SYMBOL

A0−A16

I/O1−I/O8

CS1, CS2

DESCRIPTION

Address Inputs

Data Inputs/Outputs

Chip Select Input

Write Enable Input

Output Enable Input

Power Supply

Ground

No Connection

A12

A14

A16

A15

CS2

A13

A11

32-pin

Reverse

TSOP

I/O1

I/O2

I/O3

I/O4

I/O5

I/O6

I/O7

I/O8

CS1

A10

-1-

Publication Release Date: April 1997

Revision A3

W24010-70LL Related Products

	W24010-70LL	W24010T-70LL	W24010U-70LL	W24010V-70LL	W24010S-70LL
Description	Standard SRAM, 128KX8, 70ns, CMOS, PDIP32, 0.600 INCH, PLASTIC, DIP-32	Standard SRAM, 128KX8, 70ns, CMOS, PDSO32, 8 X 20 MM, TSOP1-32	Standard SRAM, 128KX8, 70ns, CMOS, PDSO32, 8 X 20 MM, REVERSE, TSOP1-32	Standard SRAM, 128KX8, 70ns, CMOS, PDSO32, 8 X 13.4 MM, REVERSE, TSOP1-32	Standard SRAM, 128KX8, 70ns, CMOS, PDSO32, 0.450 INCH, SOP-32
Parts packaging code	DIP	TSOP1	TSOP1	TSOP1	SOIC
package instruction	DIP,	TSOP1,	TSOP1-R,	TSOP1-R,	SOP,
Contacts	32	32	32	32	32
Reach Compliance Code	unknow	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum access time	70 ns	70 ns	70 ns	70 ns	70 ns
JESD-30 code	R-PDIP-T32	R-PDSO-G32	R-PDSO-G32	R-PDSO-G32	R-PDSO-G32
length	41.91 mm	18.4 mm	18.4 mm	11.8 mm	20.45 mm
memory density	1048576 bi	1048576 bit	1048576 bit	1048576 bit	1048576 bit
Memory IC Type	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM	STANDARD SRAM
memory width	8	8	8	8	8
Number of functions	1	1	1	1	1
Number of terminals	32	32	32	32	32
word count	131072 words	131072 words	131072 words	131072 words	131072 words
character code	128000	128000	128000	128000	128000
Operating mode	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C
organize	128KX8	128KX8	128KX8	128KX8	128KX8
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	TSOP1	TSOP1-R	TSOP1-R	SOP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	SMALL OUTLINE, THIN PROFILE	SMALL OUTLINE, THIN PROFILE	SMALL OUTLINE, THIN PROFILE	SMALL OUTLINE
Parallel/Serial	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	5.33 mm	1.2 mm	1.2 mm	1.2 mm	3 mm
Maximum supply voltage (Vsup)	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	5 V	5 V	5 V	5 V
surface mount	NO	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	2.54 mm	0.5 mm	0.5 mm	0.5 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL
width	15.24 mm	8 mm	8 mm	8 mm	11.3 mm
JESD-609 code	e3	e3	-	-	e3
Terminal surface	MATTE TIN	MATTE TIN	-	-	MATTE TIN
Maker	-	-	Winbond Electronics Corporation	Winbond Electronics Corporation	Winbond Electronics Corporation
