TM8
www.vishay.com
Vishay Sprague
Solid Tantalum Chip Capacitors
M
ICROTAN®
High Reliability, Low DC Leakage, Leadframeless Molded
FEATURES
• High reliability solid surface mount tantalum
capacitors
• Low DC leakage for extended battery life
Available
Available
• Small sizes for space constrained applications
• L-shaped face-down terminations for superior board
mounting
• The molding compound has been selected to meet the
requirements of UL 94 V-0 and outgassing requirements
of ASTM E-595
• Suitable for medical implantable applications with
additional screening
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
PERFORMANCE CHARACTERISTICS
www.vishay.com/doc?40170
Operating Temperature:
-55 °C to +125 °C
(above 85 °C, voltage derating is required)
Capacitance Range:
0.33 μF to 47 μF
Capacitance Tolerance:
± 10 % and ± 20 % standard
Voltage Range:
2 V
DC
to 40 V
DC
ORDERING INFORMATION
TM8
MODEL
R
CASE
CODE
See
Ratings
and
Case
Codes
table
106
CAPACITANCE
This is
expressed in
picofarads.
The first two
digits are the
significant
figures. The
third is the
number of
zeros to
follow.
M
CAPACITANCE
TOLERANCE
K = ± 10 %
M = ± 20 %
016
DC VOLTAGE
RATING AT +85 °C
This is expressed
in volts. To complete
the three-digit block,
zeros precede the
voltage rating.
A decimal point is
indicated by an “R”
(6R3 = 6.3 V).
E
TERMINATION /
PACKAGING
Sn / Pb solder
E
= 7" (178 mm) reels
L
= 7" (178 mm) reels,
½ reel
R
= 7" (178 mm)
300 pcs. qty.
100 % tin
C
= 7" (178 mm) reels
H
= 7" (178 mm) reels,
½ reel
U
= 7" (178 mm)
300 pcs. qty.
Gold
A
= 7" (178 mm) reels
G
= 7" (178 mm) reels,
½ reel
P
= 7" (178 mm)
300 pcs. qty.
B
RELIABILITY
LEVEL
B = 0.1 %
weibull FRL
S = hi-rel std.
(40 h burn-in)
Z = non-
established
reliability
A
SURGE
CURRENT
A = 10 cycles
at 25 °C
B = 10 cycles
at -55 °C /
+85 °C
Z = none
Revision: 29-Apr-2021
Document Number: 40133
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM8
www.vishay.com
Vishay Sprague
DIMENSIONS
in inches [millimeters]
Anode polarity bar
Anode termination
C1
C
W
Cathode termination
H
P1
P2
P1
L
CASE CODE
K
M
G
W
R
P
A
N
T
L
0.045 ± 0.002
[1.14 ± 0.05]
0.063 ± 0.006
[1.60 ± 0.15]
0.063 ± 0.006
[1.60 ± 0.15]
0.081 ± 0.006
[2.06 ± 0.15]
0.081 ± 0.006
[2.06 ± 0.15]
0.096 ± 0.006
[2.45 ± 0.15]
0.126 ± 0.008
[3.2 ± 0.2]
0.138 ± 0.004
[3.5 ± 0.1]
0.138 ± 0.004
[3.5 ± 0.1]
W
0.026 ± 0.002
[0.66 ± 0.05]
0.033 ± 0.006
[0.84 ± 0.15]
0.033 ± 0.006
[0.84 ± 0.15]
0.053 ± 0.006
[1.35 ± 0.15]
0.053 ± 0.006
[1.35 ± 0.15]
0.059 ± 0.006
[1.5 ± 0.15]
0.063 ± 0.008
[1.6 ± 0.2]
0.110 ± 0.004
[2.80 ± 0.1]
0.110 ± 0.004
[2.80 ± 0.10]
H
0.024 max.
[0.61 max.]
0.033 ± 0.006
[0.84 ± 0.15]
0.047 max.
[1.2 max.]
0.047 max.
[1.2 max.]
0.058 ± 0.004
[1.47 ± 0.10]
0.049 max.
[1.25 max.]
0.071 max.
[1.8 max.]
0.047 max.
[1.2 max.]
0.063 max.
[1.57 max.]
P1
0.010 ± 0.004
[0.25 ± 0.1]
0.020 ± 0.004
[0.51 ± 0.1]
0.020 ± 0.004
[0.51 ± 0.1]
0.020 ± 0.004
[0.51 ± 0.1]
0.020 ± 0.004
[0.51 ± 0.1]
0.020 ± 0.004
[0.51 ± 0.1]
0.031 ± 0.004
[0.8 ± 0.1)
0.0335 ± 0.004
[0.85 ± 0.1]
0.0335 ± 0.004
[0.85 ± 0.1]
P2 (MIN.)
0.020
[0.51]
0.026
[0.65]
0.026
[0.65]
0.035
[0.9]
0.035
[0.9]
0.051
[1.3]
0.063
[1.60]
0.065
[1.65]
0.065
[1.65]
C
0.015 ± 0.004
[0.38 ± 0.1]
0.024 ± 0.004
[0.61 ± 0.1]
0.024 ± 0.004
[0.61 ± 0.1]
0.035 ± 0.004
[0.90 ± 0.1]
0.035 ± 0.004
[0.90 ± 0.1]
0.035 ± 0.004
[0.90 ± 0.1]
0.047 ± 0.004
[1.2 ± 0.1]
0.094 ± 0.004
[2.4 ± 0.10]
0.094 ± 0.004
[2.4 ± 0.10]
C1
0.015 ± 0.004
[0.38 ± 0.10]
0.018 ± 0.004
[0.45 ± 0.10]
0.018 ± 0.004
[0.45 ± 0.10]
0.020 ± 0.004
[0.50 ± 0.10]
0.020 ± 0.004
[0.50 ± 0.10]
0.018 ± 0.004
[0.45 ± 0.10]
0.031 ± 0.004
[0.80 ± 0.10]
0.079 ± 0.004
[2.0 ± 0.10]
0.079 ± 0.004
[2.0 ± 0.10]
RATINGS AND CASE CODES
μF
0.33
0.68
1.0
2.2
3.3
4.7
6.8
7.5
10
15
22
33
47
P
P
P
P/T
T
K
M
M
M
M/R
M
M
K
K
M
M
M/G
M
R
W
R
R
A
R/A
R
N
A
M
M
R
R
P
2V
4V
6.3 V
10 V
16 V
20 V
K
M
M/W
R
P
25 V
40 V
Revision: 29-Apr-2021
Document Number: 40133
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM8
www.vishay.com
Vishay Sprague
MARKING
M, G-Case
Polarity bar
Voltage code
P, R, W-Case
Polarity bar
Voltage Capacitance
code
code
K-Case
Polarity bar
A
A-Case
Polarity bar
Voltage
code
Capacitance
code
CW
N, T-Case
Polarity bar Capacitance Voltage
A226
VOLTAGE CODE
V
2
4
6.3
10
16
20
25
40
CODE
e
G
J
A
C
D
E
g
CAP, μF
0.68
1.0
2.2
3.3
4.7
6.8
7.5
10
15
22
47
47 10
2
Vishay marking
(if space allows)
CAPACITANCE CODE
CODE
w
A
J
N
S
W
X
a
e
j
s
STANDARD RATINGS
CAPACITANCE
(μF)
CASE
CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
MAX. DF
AT +25 °C
(%)
MAX. ESR
AT +25 °C
100 kHz STD.
()
20.0
20.0
5.0
5.0
6.0
3.0
AVAILABLE
RELIABILITY
LEVELS
2 V
DC
AT +85 °C; 1.4 V
DC
AT +125 °C
10
1.0
10
15
33
47
K
K
M
M
P
P
TM8K106M002(2)(4)(6)
TM8K105(1)004(2)(3)(6)
TM8M106(1)004(2)(3)(5)
TM8M156(1)004(2)(3)(5)
TM8P336(1)004(2)(3)(5)
TM8P476(1)004(2)(3)(5)
0.50
0.20
0.20
0.30
0.66
0.94
20
8
8
8
30
22
Z
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
4 V
DC
AT +85 °C; 2.7 V
DC
AT +125 °C
Note
• Part number definitions:
(1) Capacitance tolerance: K, M
(2) Termination and packaging: E, L, R, C, H, U, A, G, P
(3) Reliability level: Z, S, B
(4) Reliability level: Z only
(5) Surge current: Z, A, B
(6) Surge current: Z only
Revision: 29-Apr-2021
Document Number: 40133
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM8
www.vishay.com
Vishay Sprague
MAX. ESR
AT +25 °C
100 kHz STD.
()
20.0
6.0
6.0
5.0
5.0
5.0
6.0
3.0
0.5
12.0
10.0
6.0
6.0
6.0
8.0
6.0
6.0
5.0
1.5
1.0
12.0
10.0
8.0
6.0
6.0
3.0
100.0
20.0
12.0
8.0
8.0
6.0
3.0
10.0
6.0
10.0
STANDARD RATINGS
CAPACITANCE
(μF)
CASE
CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
MAX. DF
AT +25 °C
(%)
AVAILABLE
RELIABILITY
LEVELS
6.3 V
DC
AT +85 °C; 4 V
DC
AT +125 °C
1.0
3.3
4.7
10
15
15
33
47
47
1.0
2.2
3.3
4.7
3.3
7.5
6.8
10
15
22
47
1.0
2.2
3.3
6.8
10
10
0.33
0.68
1.0
1.0
3.3
7.5
10
1.0
4.7
1.0
K
M
M
M
M
R
P
P
T
M
M
M
M
G
W
R
R
R
A
T
M
M
R
R
R
A
K
M
M
W
R
N
A
R
P
P
TM8K105(1)6R3(2)(3)(6)
TM8M335(1)6R3(2)(3)(5)
TM8M475(1)6R3(2)(3)(5)
TM8M106(1)6R3(2)(3)(5)
TM8M156(1)6R3(2)(3)(5)
TM8R156(1)6R3(2)(3)(5)
TM8P336(1)6R3(2)(3)(5)
TM8P476(1)6R3(2)(3)(5)
TM8T476(1)6R3(2)(3)(5)
TM8M105(1)010(2)(3)(5)
TM8M225(1)010(2)(3)(5)
TM8M335(1)010(2)(3)(5)
TM8M475(1)010(2)(3)(5)
TM8G335(1)010(2)(3)(5)
TM8W755(1)010(2)(3)(5)
TM8R685(1)010(2)(3)(5)
TM8R106(1)010(2)(3)(5)
TM8R156(1)010(2)(3)(5)
TM8A226(1)010(2)(3)(5)
TM8T476(1)010(2)(3)(5)
TM8M105(1)016(2)(3)(5)
TM8M225(1)016(2)(3)(5)
TM8R335(1)016(2)(3)(5)
TM8R685(1)016(2)(3)(5)
TM8R106(1)016(2)(3)(5)
TM8A106(1)016(2)(3)(5)
TM8K334(1)020(2)(3)(6)
TM8M684(1)020(2)(3)(5)
TM8M105(1)020(2)(3)(5)
TM8W105(1)020(2)(3)(5)
TM8R335(1)020(2)(3)(5)
TM8N755(1)020(2)(3)(5)
TM8A106(1)020(2)(3)(5)
TM8R105(1)025(2)(3)(5)
TM8P475(1)025(2)(3)(5)
TM8P105(1)040(2)(3)(5)
0.20
0.20
0.20
0.32
0.47
0.47
1.00
1.50
1.50
0.20
0.20
0.20
0.24
0.20
0.38
0.34
0.50
0.75
1.10
2.35
0.20
0.20
0.26
0.54
0.80
0.80
0.20
0.20
0.20
0.20
0.33
0.75
1.00
0.20
0.59
0.20
8
8
8
8
8
8
30
22
8
6
10
8
8
8
8
6
8
8
8
8
6
10
8
6
8
8
6
6
6
8
8
8
8
6
6
8
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
Z, S, B
10 V
DC
AT +85 °C; 7 V
DC
AT +125 °C
16 V
DC
AT +85 °C; 10 V
DC
AT +125 °C
20 V
DC
AT +85 °C; 13 V
DC
AT +125 °C
25 V
DC
AT +85 °C; 17 V
DC
AT +125 °C
40 V
DC
AT +85 °C; 27 V
DC
AT +125 °C
Note
• Part number definitions:
(1) Capacitance tolerance: K, M
(2) Termination and packaging: E, L, R, C, H, U, A, G, P
(3) Reliability level: Z, S, B
(4) Reliability level: Z only
(5) Surge current: Z, A, B
(6) Surge current: Z only
Revision: 29-Apr-2021
Document Number: 40133
4
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM8
www.vishay.com
Vishay Sprague
TYPICAL CURVES AT +25 °C, IMPEDANCE AND ESR VS. FREQUENCY
“M” Case
1000
ESR
Impedance
“M” Case
10000
1000
ESR
Impedance
10000
2nd line
Impedance / ESR (Ω)
100
1000
1st line
2nd line
2nd line
Impedance / ESR (Ω)
100
1000
10
4.7 μF, 10 V
10
10 μF, 6 V
100
100
1
1
0.1
1
10
Frequency (kHz)
100
10
1000
0.1
0.1
1
10
Frequency (kHz)
100
10
1000
“M” Case
10 000
ESR
Impedance
“P” Case
10000
1000
ESR
Impedance
10000
1000
100
100
1st line
2nd line
2nd line
Impedance / ESR (Ω)
2nd line
Impedance / ESR (Ω)
1000
100
1000
10
100
1
4.7 μF, 25 V
10
1 μF, 16 V
1
0.1
1
10
Frequency (kHz)
100
10
1000
0.1
0.1
1
10
Frequency (kHz)
100
10
1000
STANDARD PACKAGING QUANTITY
QUANTITY (PCS/REEL)
CASE CODE
7" REEL
K
M
G
W
R
P
A
N
T
5000
4000
3000
2500
2500
3000
2000
2500
2500
½ REEL
2500
2000
1500
1250
1250
1500
1000
1250
1250
PARTIAL REEL
300
300
300
300
300
300
300
300
300
Revision: 29-Apr-2021
Document Number: 40133
5
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
1st line
2nd line
1st line
2nd line
京公网安备 11010802033920号
EEWORLD
