BZD27C........W Series
1 W Surface Mount Zener Diode
SOD123W
Voltage
9.1 to 220 V
Power Dissipation
1W
FEATURE
• Low profile package
• Ideal for automated placement
• Low leakage current
• High surge current and zener capability
• Low differential resistance
• Low forward voltage drop
• Solder dip 260 ºC, 10s
• AEC-Q101 qualified
• Component in accordance to RoHS 2011/65/EU
and WEEE 2002/96/EC
• Meets MSL level 1, per J-STD-020, LF maximum
peak of 260 ºC
MECHANICAL DATA
•
Case:
SOD123W. Epoxy meets UL 94V-0 flammability rating.
•
Polarity:
Color band denotes cathode end.
•
Terminals:
Matte tin plated leads, solderable per MIL-
STD-750 Method 2026, J-STD-002 and JESD22-B102.
Consumer grade, meets JESD 201 class 1A whisker test.
•
HE3 suffix
for high reliability grade, meets JESD 201 class
2 whisker test.
TYPICAL APPLICATIONS
Used for basic regulation functions in most electronic applica-
tions, Zener diodes offer a cheaper altenative to IC solutions.
Maximun Ratings and Electrical Characteristics at 25 °C
SYMBOL
V
F
P
tot
P
ZSM
Power dissipation
TYPE NUMBER
Forward voltage at I
F
= 0.2 A
TL = 80 ºC
TA = 25 ºC
(Note 1)
Non-Repetitive Peak Pulse Power Dissipation
100
ms
square pulse
(Note 2)
Non-Repetitive Peak Pulse Power Dissipation
P
RSM
10/1000
ms
waveform (BZD27-C9V1W to BZD27-C100W)
(Note 2)
VALUE
1.2
2.3
1
300
UNIT
V
W
W
150
W
Non-Repetitive Peak Pulse Power Dissipation
P
RSM
R
JA
R
Jc
T
j
- T
stg
Notes:
10/1000
ms
waveform (BZD27-110W to BZD27-C220W)
(Note 2)
100
180
30
-65 to +150
W
ºC/W
ºC/W
ºC
Thermal Resistance Junction to Ambient Air
(Note 1)
Thermal Resistance Junction to Lead
Operating and Storage Temperature Range
1. Mounted on Epoxy-Glass PCB with 3 x 3 mm Cu pads (≥40 µmthick)
2. T
j
= 25 ºC Prior to surge
www.fagorelectronica.com
Document Name: bzd27cw series
Revision: 6
Version: Dec-18
Page Number: 1 / 6
BZD27C........W Series
1 W Surface Mount Zener Diode
Rating and Characteristics
(Ta 25 ºC unless otherwise noted)
Device
Marking
Code
Working Voltage
(Note 1)
V
Z
@
I
ZT
V
Min.
BZD27C9V1W
BZD27C11W
BZD27C12W
BZD27C13W
BZD27C14W
BZD27C15W
BZD27C16W
BZD27C18W
BZD27C22W
BZD27C24W
BZD27C27W
BZD27C30W
BZD27C33W
BZD27C36W
BZD27C39W
BZD27C43W
BZD27C47W
BZD27C51W
BZD27C62W
BZD27C68W
BZD27C75W
BZD27C82W
BZD27C100W
BZD27C110W
BZD27C120W
BZD27C150W
BZD27C160W
BZD27C180W
BZD27C200W
BZD27C220W
8X
6A
6B
6C
8Y
6D
6E
6F
7A
6G
6H
6I
6J
6K
6L
6M
6N
6O
6P
6O
6R
3Z
6S
6Y
6T
6Z
7B
6U
6V
6X
8.5
10.4
11.4
12.4
13.4
13.8
15.3
16.8
20.8
22.8
25.1
28
31
34
37
40
44
48
58
64
70
77
94
104
114
138
153
168
188
208
Max.
9.6
11.6
12.7
14.1
14.6
15.6
17.1
19.1
23.3
25.6
28.9
32
35
38
41
46
50
54
66
72
79
87
106
116
127
156
171
191
212
233
typ
2.0
4.0
4.0
5.0
5.0
5.0
6.0
6.0
6.0
7.0
7.0
8.0
8.0
21
21
24
24
25
25
25
30
60
60
80
150
150
150
180
350
430
Max.
4.0
7
7
10
10
10
15
15
15
15
15
15
15
40
40
45
45
45
80
80
100
200
200
250
300
300
350
400
750
900
Differential
Resistance
r
Temperature
Coefficient
ALPH
Z
@
I
Z
% / ºC
Min.
0.03
0.05
0.05
0.05
0.05
0.05
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.07
0.07
0.07
0.08
0.08
0.08
0,08
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
Max.
0.08
0.10
0.10
0.10
0.10
0.10
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.12
0.12
0.12
0.13
0.13
0.13
0,13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
Test
Current
I
Reverse Current @
Reverse Voltage
I
R
µA
Max.
10.0
4.0
3.0
2.0
2.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Device
dif
@
I
Z
ZT
V
R
V
5
8.2
9.1
10
11
11
12
13
16
18
20
22
24
27
30
33
36
39
47
51
56
63
75
82
91
110
120
130
150
160
mA
50
50
50
50
50
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
2
5
5
5
5
5
5
5
5
Notes: 1. Pulse test: tp
::
5ms.
•
Electrical characteristics when used as voltage regulator diodes
www.fagorelectronica.com
Document Name: bzd27cw series
Revision: 6
Version: Dec-18
Page Number: 3 / 6
BZD27C........W Series
1 W Surface Mount Zener Diode
Rating and Characteristics
(Ta 25 ºC unless otherwise noted)
Rev. Breakdown
Test Current
Voltage
Device
V(BR)@Itest
V
Min.
BZD27C9V1W
BZD27C11W
BZD27C12W
BZD27C13W
BZD27C14W
BZD27C15W
BZD27C16W
BZD27C18W
BZD27C22W
BZD27C24W
BZD27C27W
BZD27C30W
BZD27C33W
BZD27C36W
BZD27C39W
BZD27C43W
BZD27C47W
BZD27C51W
BZD27C62W
BZD27C68W
BZD27C75W
BZD27C82W
BZD27C100W
BZD27C110W
BZD27C120W
BZD27C150W
BZD27C160W
BZD27C180W
BZD27C200W
BZD27C220W
8.5
10.4
11.4
12.4
13.4
13.8
15.3
16.8
20.8
22.8
25.1
28
31
34
37
40
44
48
58
64
70
77
94
104
114
138
153
168
188
208
50
50
50
50
50
50
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
2
5
5
5
5
5
5
5
5
Itest
mA
typ
0.03
0.05
0.05
0.05
0.05
0.05
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
Temperature Coefficient
ALPH
Z
@ Itest
% / ºc
Max.
0.08
0.10
0.10
0.10
0.10
0.10
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.12
0.12
0.12
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
Clamping Voltage
Vc
V
Max.
13.3
15.7
17
18.9
19.9
20.9
22.9
25.6
31.0
33.8
38.1
42.2
46.2
50.1
54.1
60.7
65.5
70.8
86.5
94.4
103.5
113
139
150
167
187
205
252
278
301
11.3
9.6
8.8
7.9
7.6
7.2
6.6
5.9
4.8
4.4
3.9
3.6
3.2
3
2.8
2.5
2.3
2.1
1.7
1.6
1.5
1.33
1.1
1
0.9
0.73
0.48
0.6
0.54
0.49
@IRSM (Note 1)
A
Reverse Current @ Stand-Off
Voltage
I
R
µA
Max.
10.0
4.0
3.0
2.0
2.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
5
8.2
9.1
10
11
11
12
13
16
18
20
22
24
27
30
33
36
39
47
51
56
63
75
82
91
110
120
130
150
160
@V
WM
V
Notes: 1. Non-repetitive peak reverse current in accordance with “IEC 60-1, Section 8” (10/1000 µs pulse)
• Electrical characteristics when used as protection diodes
www.fagorelectronica.com
Document Name: bzd27cw series
Revision: 6
Version: Dec-18
Page Number: 4 / 6
