15-11/BHC-AN1P2/2T datasheet, PDF

15-11/BHC-AN1P2/2T: DescriptionSingle Color LED, Blue, Water Clear, 2mm, ROHS COMPLIANT, SMD, 2 PIN; CategoryLED optoelectronic/LED photoelectric; File Size302KB，10 Pages; ManufacturerEVERLIGHT; Websitehttp://www.everlight.com/

Download Datasheet Parametric View All

15-11/BHC-AN1P2/2T Overview

Single Color LED, Blue, Water Clear, 2mm, ROHS COMPLIANT, SMD, 2 PIN

Parameter Name	Attribute value
package instruction	ROHS COMPLIANT, SMD, 2 PIN
Reach Compliance Code	compliant
Is Samacsys	N
color	BLUE
Configuration	SINGLE WITH BUILT-IN ZENER DIODE
Maximum forward current	0.025 A
Lens type	WATER CLEAR
Nominal luminous intensity	50.25 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	1.1 mm
method of packing	TAPE AND REEL 7"
peak wavelength	468 nm
shape	RECTANGULAR
size	2 mm
surface mount	YES
Terminal pitch	3.2 mm
perspective	140 deg
Base Number Matches	1

SMD

15-11/BHC-AN1P2/2T

Features

Package in 8mm tape on 7 diameter reel.

Compatible with automatic placement equipment.

Compatible with infrared and vapor phase reflow solder process.

Mono-color type.

Pb-free.

ESD Production

The product itself will remain within RoHS compliant version.

Description

The 15-11 SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing

density, reduced storage space and finally smaller equipment to be obtained.

Besides, lightweight makes them ideal for miniature applications. etc.

Applications

Backlighting in dashboard and switch.

Telecommunication: indicator and backlighting in telephone and fax.

Flat backlight for LCD, switch and symbol.

General use.

〞

․

Rev3

www.everlight.com
