3 SLOTS 5.3L*2.5W
Ø6
15.8 ±
0
0.5
21.5 ±
0.5
0
28.7
15A250V
710W
14
23 ±
0
0.5
29.5 ±
0.5
0
40 ± 0.2
50 ± 0.2
32
Ø3.2
25 ± 0.15
R5
24
4.8
R4 ± 0.15
Ø3.5
19.6
30
2.8X3.3L
7.0
32.5 ± 0.15
40 ± 0.15
4.8
10.0
3
CONTROLLED
2
Soldering PIN Brass Strip t=0.8mm Tin-Plated
Body Insulator PBT Black Color
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
Drawn / Date
B. ZHANG
04-12-02
3
1
NOTES:
MATERIAL:
HOUSING: THERMOPLASTIC
TERMINAL: COPPER ALLOY
RATING:
UL, CSA: 15A 250V AC
VDE: 10A 250V AC
INSULATION RESISTANCE: OVER 100 OHM 500V DC
DIELECTRIC STRENGTH: 2000V AC ONE MINUTE
APPROVALS: UL, CSA, VDE
RoHS COMPLIANT
1
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
710W-00/02
AC RECEPTACLE
UNIT: mm
Checked / Date
04-12-02
REV. C
Approved / Date
JJH / 04-12-02
