IEC Appliance Inlet C14 with Fuseholder 1- or 2-pole, Line Switch 2-pole and Voltage Selector
KD
Standard or Medical Fuse drawer
C14
70° C
Description
- Panel Mount:
Screw-on version from front or rear side, snap-in version from front
side
- 4 Functions:
Appliance Inlet Protection class I, Line Switch 2-pole, Fuseholder
with interchangeable fuse drawer for Fuse-links 5x20 mm or 6.3x32
mm, with or without voltage selector (step)
- Quick connect terminals 4.8 x 0.8 mm
Characteristics
- All single elements are already wired
- The fuse drawer "Fingergrip" can be removed by hand
For added safety "Extra-Safe" fuse drawers are available
Fuse drawer meets requirements of medical standard IEC/EN 60601-1
The fuse drawer can only be opened with the aid of a tool
The fuseholder is accessible from the equipment front
- Suitable for use in equipment according to IEC/UL 60950
Other versions on request
-
-
-
-
Approvals
-
-
-
-
VDE Certificate Number: 40029908
UL File Number: E93617
CSA File Number: 38456
CCC File Number: 2010010204409773
Line switch, illuminated
Line switch with other rocker marking
Line switch 1-pole
For protection class II
References
Weblinks
Alternative: version with line filter
CD
pdf-datasheet, html-datasheet, General Product Information, Approvals,
CE declaration of conformity, RoHS, CHINA-RoHS, REACH, Mating
Connectors, e-Shop, SCHURTER-Stock-Check, Distributor-Stock-
Check, CAD-Drawings, Accessories, Wire Harnessing, Detailed request
for product
Newly available variants corresponding to V-Lock mating cordset. The connector is equipped with a notch intended for use with the latching cordset.
The cord latching system prevents against accidental removal of the cordset.
Technical Data
Ratings IEC
Ratings UL/CSA
Dielectric Strength
10 A / 250 VAC; 50 Hz
10 A / 125 VAC; 60 Hz
> 3 kVAC between L-N
> 4 kVAC between L/N-PE
(1 min/50 Hz)
-25 °C to 70 °C
from front side IP 40 acc. to IEC 60529
Suitable for appliances with protection
class I acc. to IEC 61140
Quick connect terminals 4.8 x 0.8 mm
, tin-plated
Screw: max 8 mm
Mounting screw torque max 0.5 Nm
Snap-in: 1.5/2/2.5 mm
Thermoplastic, black, UL 94V-0
Appliance Inlet
C14 acc. to IEC 60320,
UL 498, CSA C22.2 no. 42 (for cold
conditions) pin-temperature 70 °C, 10 A,
Protection Class I
1 or 2 pole, Shocksafe category PC2
acc. to IEC 60127-6,
for fuse-links 5 x 20 or 6.3 x 32 mm
5 x 20: 2.5 W (1 pole)/ 2 W (2-pole) per
pole
6.3 x 32: 3.15 W (1 pole)/ 2.5 W (2-pole)
per pole
Admissible power acceptance at higher
ambient temperature see derating cur-
ves
Rocker switch 2-pole, non-illuminated,
acc. to IEC 61058-1
Technical Details
optional, step, 2-4 digits
Fuseholder
Allowable Operation Temp.
Degree of Protection
Protection Class
Terminal
Panel Thickness s
Rated Power Acceptance @
Ta 23 °C
Power Acceptance @ Ta >
23°C
Line Switch
Material: Housing
Voltage Selector
Connectors
1
KD
Dimensions
Screw-on mounting
30
R6
ø 3.2
R 4.5
4.8x0.8
55
Power entry modules without line filter
www.schurter.com/PG05
Snap-in mounting
30
R 4.5
ø 6.3x90˚
4.8x0.8
55
S
±0.1
M3/ø 3.6
230
75.5
±0.15
83.5
75.5
+0.2
230
66.5
0
R 3
-0.2
18
27.5
2
2.2
27.5
+0.2
0
0
66.5
0
66.2
66.2
69
+0.2
R 3
-0.2
18
27.5
2
2.2
27.5
+0.2
0
0
R 3.1
27.2
R 3.1
27.2
Diagrams
without voltage selector
4
without voltage selector
4
7
with voltage selector
6 54 3
with voltage selector
6 54 3
7
1
2
1
2
1
2
1
2
1a
L
E
2a
N
1a
L
E
2a
N
1a
L
E
2a
N
1a
L
E
2a
N
1-pole
2-pole
1-pole
2-pole
Derating Curves
Fuses
5 x 20 mm (1-pole)
2.5
Fuses
5 x 20 mm (2-pole, per pole)
Admissible power acceptance in Watt per
pole
2.0
Admissible power acceptance in Watt
2.0
1.5
1.0
0.5
0.0
0
20
40
60
80
100
I = 1.0 I
n
I = 0.7 I
n
I = << I
n
1.5
I = 1.0 I
n
1.0
I = 0.7 I
n
I = < < I
n
0.5
0.0
0
20
40
60
80
100
Ambient air temperature Ta °C
Ambient air temperature Ta °C
Fuses
6.3 x 32 mm (1-pole)
3.15
Fuses
6.3 x 32 mm (2-pole, per pole)
Admissible power acceptance in Watt per
pole
2.5
2.0
1.5
1.0
0.5
0.0
0
20
40
60
80
100
I = 1.0 I
n
I = 0.7 I
n
I = < < I
n
Admissible power acceptance in Watt
2.5
2.0
1.5
1.0
0.5
0.0
0
20
40
60
80
100
I = 1.0 I
n
I = 0.7 I
n
I = < < I
n
Ambient air temperature Ta °C
Ambient air temperature Ta °C
2
Connectors
KD
Accessories
Power entry modules without line filter
www.schurter.com/PG05
Assorted Covers
Rear Cover
Wire Harness
Wire harness for SCHURTER products
Cord retaining kits
Cord retaining strain relief
Mating Outlets/Connectors
Category / Description
Appliance Outlet Overview complete
IEC Appliance Outlet F, Screw-on Mounting, Front Side, Solder Terminal
IEC Appliance Outlet F, Snap-in Mounting, Front Side, Solder or Quick-connect Terminal
IEC Appliance Outlet F or H, Screw-on Mounting, Front Side, Solder, PCB or Quick-connect Terminal
Appliance Outlet further types to KD
4787
4788
5091
Connector Overview complete
IEC Connector C15A, Rewireable, Straight
IEC Connector C15A, Rewireable, Straight
IEC Connector C15A, Rewireable, Angled
IEC Connector C13, Rewireable, Angled
IEC Connector C13, Rewireable, Straight
Connector further types to KD
0102
0102-G
0112
4012
4022
...
Mating Outlets/Connectors shuttered
Power Cord Overview complete
Overview Power Supply Cord with IEC Connector C13, V-Lock, straight
Power Cord further types to KD
VAC13KS
4
Connectors
