TC1N4148M.TB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> TC1N4148M.TB

TC1N4148M.TB: DescriptionRectifier Diode, 1 Element, 0.15A, Silicon, DO-34, HERMETIC SEALED, GLASS, DO-204, 2 PIN; CategoryDiscrete semiconductor diode; File Size153KB，6 Pages; ManufacturerTak Cheong; Websitehttp://www.takcheong.com/; Environmental Compliance

Download Datasheet Parametric View All

TC1N4148M.TB Overview

Rectifier Diode, 1 Element, 0.15A, Silicon, DO-34, HERMETIC SEALED, GLASS, DO-204, 2 PIN

TC1N4148M.TB Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Tak Cheong
Parts packaging code	DO-204
package instruction	O-LALF-W2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1 V
JEDEC-95 code	DO-34
JESD-30 code	O-LALF-W2
JESD-609 code	e3
Maximum non-repetitive peak forward current	2 A
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Maximum output current	0.15 A
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.5 W
Certification status	Not Qualified
Maximum reverse recovery time	0.004 µs
surface mount	NO
Terminal surface	Tin (Sn)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

TAK CHEONG

SEM IC O N DU C TO R

500 mW DO-34 Hermetically

Sealed Glass Fast Switching

Diodes

AXIAL LEAD

DO34

Absolute Maximum Ratings

Symbol

STG

FSURGE

Power Dissipation

= 25°C unless otherwise noted

Value

500

-65 to +200

+175

150

450

Units

°C

DEVICE MARKING DIAGRAM

(TC1N4148M)

Parameter

Storage Temperature Range

Operating Junction Temperature

Working Inverse Voltage

Average Rectified Current

Non-repetitive Peak Forward Current

Peak Forward Surge Current

: Logo

DEVICE MARKING DIAGRAM

(TC1N4448M / TC1N914BM)

These ratings are limiting values above which the serviceability of the diode may be impaired.

Specification Features:

Fast Switching Device (T

<4.0 nS)

DO-34 Package (JEDEC DO-204)

Through-Hole Device Type Mounting

Hermetically Sealed Glass

Compression Bonded Construction

All external surfaces are corrosion resistant and leads are readily solderable

Cathode indicated by polarity band

DEVICE MARKING DIAGRAM

(TC1N4148M)

Cathode

: Logo

Device Code : TC1NxxxxM

L xxxx

Anode

ELECTRICAL SYMBOL

Electrical Characteristics

Symbol

Breakdown Voltage

= 25°C unless otherwise noted

Parameter

Test Condition

=100µA

=5µA

Limits

Min

100

Volts

0.62

0.72

1.0

Volts

µA

Max

Unit

Reverse Leakage Current

=20V

=75V

Forward Voltage

TC1N4448M, TC1N914BM

TC1N4148M,

TC1N4148M

TC1N4448M, TC1N914BM

=5mA

=10mA

=100mA

=10mA, V

=6V

=100Ω

=1mA

Reverse Recovery Time

Capacitance

=0V, f=1M

October 2005 / B

Page 1

TC1N4148M/TC1N4448M/TC1N914BM
