T6K14
TOSHIBA CMOS DIGITAL INTEGRATED CIRCUIT SILICON MONOLITHIC
T6K14
COLUMN ROW DRIVER LSI FOR DOT MATRIX GRAPHIC LCD
The TOSHIBA T6K14 is a driver for a small or medium scale dot
matrix graphic LCD, especially for reflecting color STN LCD.
This LSI incorporate 65 row output, 128 column output and 65 ×
128 × 2 bit bit−map display RAM. It has 4 gray−scale function.
The display RAM of this driver is a 2 port RAM so that the access
from MPU is as same as general SRAM and has no waiting
timing.
It include various power circuit, voltage regulator, voltage divider,
Op−amp. contrast control and DC−DC converter ( ×2, ×3, ×4, ×5 ).
Features
LCD driver output
Built in display RAM
Gray scale
Word length
Duty cycle
: 64 row (common) + 128 column
(segment) + 128 icons
: 65 × 128 × 2 = 16640 bit, 2 port
RAM
: 4 gray scale selectable
: 8 bit / word
: 1 / 2 duty (power save mode)
1 / 35, 1 / 49, 1 / 57, 1 / 65 duty selectable (normal display mode)
000707EBE1
•
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor devices in general
can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical stress. It is the responsibility of the
buyer, when utilizing TOSHIBA products, to comply with the standards of safety in making a safe design for the entire system, and
to avoid situations in which a malfunction or failure of such TOSHIBA products could cause loss of human life, bodily injury or
damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as set forth in the
most recent TOSHIBA products specifications. Also, please keep in mind the precautions and conditions set forth in the “Handling
Guide for Semiconductor Devices,” or “TOSHIBA Semiconductor Reliability Handbook” etc..
•
The TOSHIBA products listed in this document are intended for usage in general electronics applications (computer, personal
equipment, office equipment, measuring equipment, industrial robotics, domestic appliances, etc.). These TOSHIBA products are
neither intended nor warranted for usage in equipment that requires extraordinarily high quality and/or reliability or a malfunction or
failure of which may cause loss of human life or bodily injury (“Unintended Usage”). Unintended Usage include atomic energy
control instruments, airplane or spaceship instruments, transportation instruments, traffic signal instruments, combustion control
instruments, medical instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in this document
shall be made at the customer’s own risk.
•
Polyimide base film is hard and thin. Be careful not to injure yourself on the film or to scratch any other parts with the film. Try to
design and manufacture products so that there is no chance of users touching the film after assembly, or if they do , that there is no
chance of them injuring themselves. When cutting out the film, try to ensure that the film shavings do not cause accidents. After use,
treat the leftover film and reel spacers as industrial waste.
•
Light striking a semiconductor device generates electromotive force due to photoelectric effects. In some cases this can cause the
device to malfunction.
This is especially true for devices in which the surface (back), or side of the chip is exposed. When designing circuits, make sure
that devices are protected against incident light from external sources. Exposure to light both during regular operation and during
inspection must be taken into account.
•
The products described in this document are subject to the foreign exchange and foreign trade laws.
•
The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
TOSHIBA CORPORATION for any infringements of intellectual property or other rights of the third parties which may result from its
use. No license is granted by implication or otherwise under any intellectual property or other rights of TOSHIBA CORPORATION or
others.
•
The information contained herein is subject to change without notice.
2001-03-13
1/45
T6K14
Power management
: Normal mode (Full display)
Power save mode (Icon display)
Stand by mode (Clock stop)
: CR oscillation
Low frequency operation
−82
kHz oscillation for FR frequency 70 Hz (1 / 65 duty)
: Voltage regulator, Voltage divider, Voltage follower Op−amp.
DC−DC converter (×2, ×3, ×4, ×5), Temperature compensation circuit, Contrast
control circuit.
: Interfacing with 68 / 80 series MPU and Serial Interface
: V
DD
= 2.4~3.3 V, V
IN
= 2.7~3.3 V
: V
CC1, 2
= 6.0~16.5 V, if case of used the voltage Regulator, V
CC2
output voltage at
12.5 V or 11.0 V (typ.) Ta = 25°C
: I
SS
= 200 µA (typ.)
: V
DD
= 2.7 V, V
IN
= 2.7 V, using the DC−DC converter (×5), no data access, op−amp
on, f
osc
= 82 kHz (internal clock), no load, 1 / 65 duty, temperature compensation
circuit off.
:
Product
T6K14 (×××, ×××)
JBT6K14-AS
Package
TCP (Tape carrier package)
Gold bump chip
Clock oscillator
Power circuit
CPU interface
Logic operation voltage
LCD operation voltage
CMOS process
Low power consumption
Condition
Package
2001-03-13
2/45
