STANDARD RF INDUCTORS - SURFACE MOUNT
CF1008
COMPLIANT
RoHS
Ferrite Wirewound, Open Construction
PART
NUMBER
L
µH
L TEST
FREQ
MHz
Q
MIN
Q
FREQ
MHz
FERRITE CORE
SRF
MHz
MIN
1000
1000
900
850
750
600
650
600
550
525
500
475
380
375
370
330
315
300
270
210
190
170
150
135
120
105
90
80
70
65
60
12
9.8
8.5
7.2
6.5
6.5
6.5
5.8
5.2
4.5
4.5
3.3
DCR
OHMS
MAX
0.15
0.15
0.15
0.16
0.18
0.18
0.18
0.24
0.24
0.26
0.30
0.35
0.35
0.36
0.38
0.40
0.50
0.52
0.70
0.68
0.80
0.98
1.10
1.28
1.46
1.80
2.70
3.50
3.10
3.20
3.60
5.20
7.40
7.90
8.60
9.70
11.0
15.0
20.0
22.0
23.0
26.0
28.0
CURRENT
RATING
mA DC MAX
1086
1086
1086
1051
991
991
991
859
859
825
768
711
711
701
682
665
595
583
503
510
470
425
401
372
348
313
256
225
239
235
222
184
155
150
143
135
127
109
94
90
88
82
79
CF1008-082*
0.082
25
60
100
CF1008-100*
0.100
25
60
100
CF1008-120*
0.120
25
60
100
CF1008-150*
0.150
25
60
100
CF1008-160*
0.160
25
60
100
CF1008-180*
0.180
25
60
100
CF1008-220*
0.220
25
60
100
CF1008-240*
0.240
25
60
100
CF1008-270*
0.270
25
60
100
CF1008-330*
0.330
25
60
100
CF1008-390*
0.390
25
60
100
CF1008-470*
0.470
25
60
100
CF1008-560*
0.560
25
50
100
CF1008-620*
0.620
25
50
100
CF1008-680*
0.680
25
50
100
CF1008-750*
0.750
25
50
100
CF1008-820*
0.820
25
50
100
CF1008-910*
0.910
25
40
100
CF1008-101*
1.0
25
40
50
CF1008-121*
1.2
7.9
35
50
CF1008-151*
1.5
7.9
35
50
CF1008-181*
1.8
7.9
30
50
CF1008-221*
2.2
7.9
30
50
CF1008-271*
2.7
7.9
35
50
CF1008-331*
3.3
7.9
25
50
CF1008-391*
3.9
7.9
25
7.9
CF1008-471*
4.7
7.9
25
7.9
CF1008-561*
5.6
7.9
25
7.9
CF1008-681*
6.8
7.9
22
7.9
CF1008-821*
8.2
7.9
22
7.9
CF1008-102*
10
7.9
22
7.9
CF1008-122*
12
2.5
13
2.5
CF1008-152*
15
2.5
13
2.5
CF1008-182*
18
2.5
13
2.5
CF1008-222*
22
2.5
13
2.5
CF1008-272*
27
2.5
13
2.5
CF1008-332*
33
2.5
13
2.5
CF1008-392*
39
2.5
13
2.5
CF1008-472*
47
2.5
13
2.5
CF1008-562*
56
2.5
13
2.5
CF1008-682*
68
2.5
13
2.5
CF1008-822*
82
2.5
13
2.5
CF1008-103*
100
2.5
13
2.5
* Substitute “J” for 5% tolerance or “K” for 10% tolerance.
Custom designs are available to meet your specific requirements; please contact factory.
70
Typical Q Versus Frequency
CF1008
0.110 (2.8)
MAX
0.115 (2.92)
MAX
0.008 (0.20)
REF
0.090 (2.28)
MAX
60
50
40
Q
30
RECOMMENDED FOOT PRINT
2.2µH
3.3µH
1.5µH
20
NOTES:
• Operating Temperature Range:
-40°C to +125°C
• Current Rating is based on a 35°C
temperature rise at an ambient
temperature of 90°C
• Terminations are Gold OVER Nickel
• Inductance and Q measured using the HP4291A
• SRF measured using the HP8753C
• Suitable for Reflow Soldering
• Flat Top Cover for Pick and Place
• Excellent for high frequency applications
TAPE AND REEL SPECS:
Pcs./Reel maximum
Pitch between parts:
Tape width:
Reel diameter:
2000
4 mm
8 mm
7 in.
10
68µH
27µH
6.8µH
1.8µH
0.68µH 0.1µH
0
1
10
100
Frequency MHz
1000
0.040
(1.016)
0.100
(2.54)
0.090
(2.29)
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
040514
