ILBB-1210, ILBB-1806, ILBB-1812
www.vishay.com
Vishay Dale
Multilayer Ferrite Beads
FEATURES
• High reliability
• Surface mountable (multiple case sizes)
• Magnetically self shielded
• Nickel barrier plating virtually eliminates silver
migration
• Compliant to RoHS Directive 2011/65/EU
• Halogen-free according to IEC 61249-2-21 definition
ENVIRONMENTAL SPECIFICATIONS
MECHANICAL SPECIFICATIONS
Solderability:
90 % coverage after 5 s dip in 235 °C solder
following 60 s preheat at 120 °C to 150 °C and type R flux dip
Resistance to Solder Heat:
10 s in 260 °C solder, after
preheat and flux per above
Terminal Strength:
1210: 1.0 kg (2.2 lbs), 1806: 1.0 kg
(2.2 lbs), 1812: 1.5 kg (3.3 lbs) for 30 s
Beam Strength:
1210: 2.5 kg (5.5 lbs), 1806: 2.5 kg (5.5 lbs),
1812: 2.5 kg (5.5 lbs)
Operating Temperature:
- 55 °C to + 125 °C
Thermal Shock:
300 cycles, - 40 °C to + 125 °C
Biased Humidity:
85 % RH at 85 °C, 1000 h at full rated
current
DIMENSIONS
in inches [millimeters]
Dimensional Outline
B
STANDARD ELECTRICAL SPECIFICATIONS
PART
NUMBER
Z
± 25 % AT 100 MHz
)
31
ILBB-1210
60
90
80
ILBB-1806
100
150
70
ILBB-1812
120
0.40
200
1812
DCR MAX.
)
0.30
0.30
0.30
0.30
0.30
0.50
0.40
RATED
DC CURRENT
(mA)
400
Ferrite Body
A
400
400
400
300
200
200
1806
D
C
SIZE
1210
A
B
C
D
0.126 ± 0.008 0.098 ± 0.008 0.051 ± 0.008 0.020 ± 0.012
[3.2 ± 0.2]
[2.5 ± 0.2]
[1.3 ± 0.2]
[0.5 ± 0.3]
0.177 ± 0.010 0.063 ± 0.008 0.063 ± 0.008 0.024 ± 0.016
[4.5 ± 0.25]
[1.6 ± 0.2]
[1.6 ± 0.2]
[0.6 ± 0.4]
0.177 ± 0.010 0.126 ± 0.010 0.059 ± 0.010 0.024 ± 0.016
[4.5 ± 0.25]
[3.2 ± 0.25]
[1.5 ± 0.25]
[0.6 ± 0.4]
DESCRIPTION
ILBB
MODEL
1806
SIZE
80
± 25 %
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
IMPEDANCE VALUE IMPEDANCE TOLERANCE
GLOBAL PART NUMBER
I
L
B
B
1
8
SIZE
0
6
E
R
8
0
IMPEDANCE
VALUE
0
V
IMPEDANCE
TOLERANCE
PRODUCT FAMILY
PACKAGE
CODE
Revision: 23-Feb-12
Document Number: 34101
